H3C S6300 Switch Series
DLDP Configuration Examples
Copyright © 2020 New H3C Technologies Co., Ltd. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of
New H3C Technologies Co., Ltd.
Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document
are the property of their respective owners.
The information in this document is subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S6300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for H3C S6300 Series

Summary of Contents for H3C S6300 Series

  • Page 1 No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of New H3C Technologies Co., Ltd. Except for the trademarks of New H3C Technologies Co., Ltd., any trademarks that may be mentioned in this document are the property of their respective owners.

  • Page 2: Table Of Contents

    Contents Introduction ····················································································· 1   Prerequisites ··················································································· 1   Example: Automatically shutting down unidirectional links ························· 1     Network requirements ················································································································· 1   Software version used ················································································································· 1   Configuration restrictions and guidelines ························································································· 1   Configuration procedures ············································································································· 2  ...

  • Page 3: Introduction

    Introduction This document provides DLDP configuration examples. The Device Link Detection Protocol (DLDP) was developed by H3C to detect the status of fiber links or twisted-pair links. When DLDP detects unidirectional links, it can automatically shut down the faulty port to avoid network problems. Alternatively, a user can manually shut down the faulty port.

  • Page 4: Configuration Procedures

    • For DLDP to operate correctly, enable DLDP on both sides and make sure the following settings are consistent: Interval to send Advertisement packets. DLDP authentication mode. Password. Configuration procedures Configure Device A: # Enable DLDP globally. <DeviceA> system-view [DeviceA] dldp global enable # Configure Ten-GigabitEthernet 1/0/1 and Ten-GigabitEthernet 1/0/2 to operate in full duplex mode at 10000 Mbps, and enable DLDP on the interfaces.
  • Page 5 Number of the port’s neighbors: 1 Neighbor MAC address: 0023-8956-3600 Neighbor port index: 1 Neighbor state: Confirmed Neighbor aged time: 11s Interface Ten-GigabitEthernet1/0/2 DLDP port state: Bidirectional Number of the port’s neighbors: 1 Neighbor MAC address: 0023-8956-3600 Neighbor port index: 2 Neighbor state: Confirmed Neighbor aged time: 12s The output shows that the DLDP port status of both Ten-GigabitEthernet 1/0/1 and Ten-...
  • Page 6 Line protocol state: DOWN(DLDP) IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 00e0-fc00-5929 Description: Ten-GigabitEthernet1/0/1 Interface Bandwidth: 10000000kbps Loopback is not set Media type is optical fiber, Port hardware type is 10G_BASE_SR_SFP 10Gbps-speed mode, full-duplex mode Link speed type is autonegotiation, link duplex type is force link Flow-control is not enabled The Maximum Frame Length is 10000 Allow jumbo frame to pass...

  • Page 7: Configuration Files

    DLDP unidirectional-shutdown mode: Auto DLDP delaydown-timer value: 1s Number of enabled ports: 2 Interface Ten-GigabitEthernet1/0/1 DLDP port state: Unidirectional Number of the port’s neighbors: 0 (Maximum number ever detected: 1) Interface Ten-GigabitEthernet1/0/2 DLDP port state: Unidirectional Number of the port’s neighbors: 0 (Maximum number ever detected: 1) The output shows that the DLDP port status of both Ten-GigabitEthernet 1/0/1 and Ten- GigabitEthernet 1/0/2 is Unidirectional.

  • Page 8: Example: Manually Shutting Down Unidirectional Links

    speed 10000 duplex full dldp enable interface Ten-GigabitEthernet1/0/2 speed 10000 duplex full dldp enable • The configuration file for Device B is the same as Device A. (Details not shown.) Example: Manually shutting down unidirectional links Network requirements As shown in Figure 3, Device A and Device B are connected through two fiber pairs.

  • Page 9: Configuration Procedures

    DLDP authentication mode. Password. Configuration procedures Configure Device A: # Enable DLDP globally. <DeviceA> system-view [DeviceA] dldp global enable # Configure Ten-GigabitEthernet 1/0/1 and Ten-GigabitEthernet 1/0/2 to operate in full duplex mode at 10000 Mbps, and enable DLDP on the interfaces. [DeviceA] interface ten-gigabitethernet 1/0/1 [DeviceA-Ten-GigabitEthernet1/0/1] duplex full [DeviceA-Ten-GigabitEthernet1/0/1] speed 10000...
  • Page 10 Neighbor state: Confirmed Neighbor aged time: 11s Interface Ten-GigabitEthernet1/0/2 DLDP port state: Bidirectional Number of the port’s neighbors: 1 Neighbor MAC address: 0023-8956-3600 Neighbor port index: 2 Neighbor state: Confirmed Neighbor aged time: 12s The output shows that the DLDP port status of both Ten-GigabitEthernet 1/0/1 and Ten- GigabitEthernet 1/0/2 is Bidirectional.
  • Page 11 Line protocol state: UP IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 00e0-fc00-5929 Description: Ten-GigabitEthernet1/0/1 Interface Bandwidth: 10000000kbps Loopback is not set Media type is optical fiber, Port hardware type is 10G_BASE_SR_SFP 10Gbps-speed mode, full-duplex mode Link speed type is autonegotiation, link duplex type is force link Flow-control is not enabled The Maximum Frame Length is 10000 Allow jumbo frame to pass...
  • Page 12 DLDP unidirectional-shutdown mode: Manual DLDP delaydown-timer value: 1s Number of enabled ports: 2 Interface Ten-GigabitEthernet1/0/1 DLDP port state: Unidirectional Number of the port’s neighbors: 0 (Maximum number ever detected: 1) Interface Ten-GigabitEthernet1/0/2 DLDP port state: Unidirectional Number of the port’s neighbors: 0 (Maximum number ever detected: 1) The output shows that the DLDP port status of both Ten-GigabitEthernet 1/0/1 and Ten- GigabitEthernet 1/0/2 is Unidirectional.

  • Page 13: Configuration Files

    • The configuration file for Device B is the same as Device A. (Details not shown.) Related documentation • H3C S6300 Switch Series High Availability Configuration Guide-Release 23xx • H3C S6300 Switch Series High Availability Command Reference-Release 23xx...
