Electrical Safety
All products are tted with a detachable power cord (supplied) which connects to
the AC mains and the back panel of the loudspeaker. The power cord has an IEC
female connector on one end and male mains connectors on the other end.
This cord is supplied specially to accommodate the di erent worldwide safety and
electrical code requirements. The power cord supplied with your product has a 3-pin
type plug. Do not cut o or damage the grounding plug.
Like any electrical appliance, your EON powered speakers should not be used in
water or when wet.
Product design and speci cations are subject to change without previous notice.
System Features:
•
Loudspeaker PA System
•
Rugged, Durable & Reliable Sound
•
Bluetooth Wireless Streaming Ability
•
Speaker System: 10'' Woofer, 1.0'' Tweeter
•
Compression Driver with Titanium Diaphragm
•
2-Way Full Range Audio Projection
•
Built-in Ampli er
•
Fully Featured 2-Channel Mixer
•
Aux-In (3.5mm) Input Connector Jack
•
RCA (L/R) Stereo Line Input Connectors
•
Ability to Connect External Devices (Smartphones, MP3 Players, Tablets, etc.)
•
USB Flash & SD Memory Card Readers
•
USB Reader Doubles as Device Charging Port
•
FM Radio
•
Digital LCD Display Screen
•
ID3 Tag Song Readout Info: LCD Displays Song Title/Song Time
•
Touch Button & Rotary Controls
•
Mic Level, Input Level & Volume Control
•
Master Volume, Treble, and Bass Adjustable
•
1/4'' Microphone Input
•
1/4'' Line Output Connector Jack
•
(2) XLR Input Connector Jacks for Microphone/Guitar
•
Convenient Carry Handles
•
35mm Speaker Stand Mount
•
Engineered Heavy Duty ABS Housing
6
www.PyleUSA.com
Wireless BT Connectivity:
•
Instantly Stream Music from Your Wireless BT Devices
•
Works with All of Your Favorite Devices
(iPhone, Android, Smartphone, iPad, Tablet, Computer, etc.)
•
Wireless BT Version: 2.1+EDR
•
Wireless BT Wireless Range: 100'+ Feet
•
Wireless BT Network Name: 'Pyle Speaker'
MP3 Audio Recording Ability:
•
It's Easy: One Button Record Activation
•
Record Audio as Streamed through the Speaker System
•
Ability to Record Vocals via Microphone
•
Can Also Record Audio via Line & Aux Inputs
•
Records to USB Flash & SD Memory Card
•
Audio File Type Created: .WAV
•
Easy Transfer to PC & Mac
Subwoofer:
•
Size: 10'' -inch
•
Material: Stamped Steel Basket
•
Impendence: 8 Ohm
•
Magnet: 40 oz.
•
Voice Coil: 50mm, 2'' -inch
•
Sensitivity: 96dB
•
Frequency Response: 40Hz-22kHz
Technical Specs:
•
Max Power Output: 700 Watt
•
RMS Power Output: 350 Watt
•
Ampli er Class: AB
•
Digital Audio File Compatibility: MP3, WMA
•
Maximum SD/USB Flash Memory Support: 32GB
•
2 XLR and 2 1/4" TS/Unbalanced with RCA
•
T.H.D.:1%
•
S/N Ratio: 72dB
•
Crossover Frequency: 2.2kHz
•
110/220 Voltage Selectable
•
Dimensions (L x W x H): 14.1'' x 11.4'' x 21.2"
Tweeter:
•
Size: 1.0'' -inch
•
Material: Titanium
•
Impendence: 8 Ohm
•
Sensitivity: 110dB
•
Voice Coil: Kapton
•
Frequency Response: 600Hz-20kHz
What's in the Box:
•
10'' Wireless BT PA Speaker
•
Remote Control
•
Power Cable
