- Page 1 Owner’s Manual OLED MONITOR Please read this manual carefully before operating your set and retain it for future reference. 32EP950 www.lg.com Copyright 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered OPEN SOURCE SOFTWARE NOTICE trademarks of HDMI Licensing Administrator, Inc. -
Page 3: Open Source Software Notice
• If you use generic cables not certified by LG, the screen may not display or there may be image noises. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing •... - Page 4 • The power cord provided may differ depending upon the region. Supported Software Power LED You can download and install the latest version from the LGE website (www.lg.com). Joystick Button • Power LED •...
- Page 5 Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or down with your finger.
- Page 6 Installing on a Table CAUTION • • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Avoid touching the monitor screen as much as possible. the wall to ensure sufficient ventilation. - This may result in damage to the screen or some of the pixels used to create images.
- Page 7 Adjusting the Angle CAUTION • Unplug the power cord before moving or installing the monitor. There is risk of electric shock. Place the monitor mounted on the stand base in an upright position. • Make sure to use the power cord that is provided in the product package and connect it to a grounded power Adjust the angle of the screen.
- Page 8 Pivot Feature Raise the monitor up to the maximum height. The pivot feature allows the monitor to rotate 90° clockwise. WARNING • When using the Pivot function, do not rotate the monitor too fast or with excessive force. The table may be scratched by contact with the monitor’...
- Page 9 Rotate the monitor clockwise as shown in the figure. NOTE • Auto Pivot feature of the display is not supported. • The screen can be rotated easily using the screen pivot shortcut key provided with your Windows operating system. Note that some Windows versions and some graphics card drivers may use different settings for the screen pivot key or may not support the pivot key at all.
- Page 10 Using the Kensington Lock Installing on the Wall For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website This monitor meets the specifications for the wall mount plate or other compatible devices. at http://www.kensington.com.
- Page 11 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorised LG wall mount and contact the local dealer or qualified personnel. Wall Mount (mm) 100 x 100 •...
-
Page 12: Using The Monitor
Press the joystick button, go to [Settings] > [Input], and then select the input option. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion. - Page 13 Connecting to a PC DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the feature. NOTE : A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.
- Page 14 Connecting AV Devices Connecting Peripherals HDMI Connection USB Device connection HDMI transmits digital video and audio signals from your AV device to the monitor. The USB port on the product functions as a USB hub. CAUTION NOTE • • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. It is recommended you install all Windows Updates to keep your Windows up-to-date before connecting to the product for use.
-
Page 15: User Settings
USER SETTINGS CAUTION • Cautions when using a USB device. - A USB device with an automatic recognition program installed, or that uses its own driver, may not be NOTE recognised. - Some USB devices may not be supported or may not work properly. •... - Page 16 Main Menu Features Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
- Page 17 [Input] [Picture] [Settings] > [Input] [Settings] > [Picture] • [Input List]: Selects the input mode. • [Picture Mode]: Select the Picture mode that suits the each standard mode; [Custom], [BT.2020], [BT.709], [P3-D65], [(HDR) P3-D65 PQ], [(HDR) BT.2100 PQ], [AdobeRGB], [sRGB], and [Calibration]. •...
- Page 18 [General] • [Six Color]: Meets the user requirements for colours by adjusting the hue and saturation of the six colours (red, green, blue, cyan, magenta, and yellow) and then saving the settings. [Settings] > [General] - Hue: Adjusts the tone of the screen colours. •...
- Page 19 • [USB Selection]: Select the USB upstream cable connection port to use USB hub of the monitor. • [DisplayPort Version]: Set DisplayPort Version to the same version as the connected external device. To use the HDR function, set to [1.4]. •...
- Page 20 Important Information for Preventing Image Retention Recommended Measures for Preventing Image Retention Turn on [Screen Saver] and [Screen Shift] when using the monitor. Unlike regular LED/LCD monitors, pixels in the OLED monitors emit light on their own, achieving a perfect black •...
-
Page 21: Troubleshooting
TROUBLESHOOTING Screen display is unstable and shaky. / Images displayed on the monitor leave shadow trails. • Did you select the appropriate resolution? - If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended resolution. - Page 22 Some features are disabled. 4K resolution is unavailable. • • Are some functions not available when you press the Menu button? Did you check the cable connection? - The OSD is locked. Disable [OSD Lock] in [General]. - Check if the cable is properly connected. - It is recommended to use the accessories supplied with the product.
-
Page 23: Product Specification
PRODUCT SPECIFICATION Dimensions: Monitor Size (Width x Depth x Height) • With Stand (mm): 726.5 x 239.3 x 616.5 • Without Stand (mm): 726.5 x 35.3 x 435.8 Specifications are subject to change without notice. Weight (Without Packaging) The symbol means alternating current, and the symbol means direct current. - Page 24 Support Mode (Preset Mode, DisplayPort / USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2048 x 1080 26.27 23.90 2560 x 1440 88.79 59.95...
- Page 25 (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 67.5 2048 x 1080 26.27 23.90 2560 x 1440 88.79 59.95 3840 x 2160 52.44...
- Page 26 HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480p 31.5 720p 1080p 67.5 2160p...
- Page 28 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
