Battery Backup Pack
for Gate Motors GTR206
Suits the Following Richmond Gate Motors:
GTR064, GTR207 GTR058
Instructions must be read before beginning installation. Please follow these instructions carefully,
incorrect installation could affect gate operation. If you require more information, please contact
your local Richmond Wheel & Castor Co branch.
AU: 1300 474 246
NZ: 0800 61 71 81
International: +613 9551 2233
For installation or troubleshooting assistance visit gatesupport.richmondau.com
GTR206 Installation Manual: Rev 1
1
Advertisement
Table of Contents
Related Manuals for Richmond GTR206
Summary of Contents for Richmond GTR206
- Page 1 Instructions must be read before beginning installation. Please follow these instructions carefully, incorrect installation could affect gate operation. If you require more information, please contact your local Richmond Wheel & Castor Co branch. AU: 1300 474 246 NZ: 0800 61 71 81 International: +613 9551 2233 For installation or troubleshooting assistance visit gatesupport.richmondau.com...
- Page 2 GTR206 Battery Backup Pack: How it Works The GTR206 battery backup pack provides you with a backup power supply to your gate motor if power is lost. While connected, the batteries in the GTR206 will continue to charge, meaning there will be no...
- Page 3 Installing the GTR206 Battery Backup Pack 1. Mount the GTR206 battery backup pack within 1.5m of your gate opener 2. Remove the plastic cover from the battery pack 3. Connect the red jumper wire to the negative and positive battery terminals as shown below: 4.
- Page 4 Motor Connect the pre-stripped black and red wires to the BAT terminal of the GTR064 circuit board and then connect to your GTR206 battery backup pack using the 2-pin plug supplied. positive + negative - GTR206 Installation Manual: Rev 1...
- Page 5 Connect the pre-stripped black and red wires to the BAT terminal of the GTR207 circuit board and then connect to your GTR206 battery backup pack using the 2-pin plug supplied. Lastly connect the solar panel GTR206 Installation Manual: Rev 1...
- Page 6 Connecting to the GTR058 Swing Gate Motor Connect the pre-stripped black and red wires to the BAT + and BAT - terminals of the GTR058 circuit board and then connect to your GTR206 battery backup pack using the 2-pin plug supplied. negative -...
