OWNER'S MANUAL
TOP FREEZER
REFRIGERATOR
Please read this manual carefully before operating
your set and retain it for future reference.
MANUAL DE USUARIO
REFRIGERADOR
CON CONGELADOR SUPERIOR
Lea detenidamente este manual antes
de empezar a utilizar el refrigerador y guárdelo
como referencia para el futuro.
Model Name/Nombre de Modelo**
LTC22350**
P/No. MFL62423825
=color number/número de color
www.lg.com
Advertisement
Table of Contents
Troubleshooting
Related Manuals for LG LTC22350SS
Summary of Contents for LG LTC22350SS
- Page 1 MANUAL DE USUARIO REFRIGERADOR CON CONGELADOR SUPERIOR Lea detenidamente este manual antes de empezar a utilizar el refrigerador y guárdelo como referencia para el futuro. Model Name/Nombre de Modelo** LTC22350** P/No. MFL62423825 =color number/número de color www.lg.com...
-
Page 2: Warranty
Visit our web site http://www.lg.com LG Electronics will repair or at its option replace, without charge, your product which proves to be defective in material or workmanship under normal use during the warranty period listed below from the date of original purchase. -
Page 3: Table Of Contents
Warranty English Version Spanish Version Important Safety Instructions Requirements for Ground Connection Parts and Features Refrigerator Installation Unpacking Installation Installation of Base Grille How to remove and Install the Refrigerator Doors How to reverse and Install the Refrigerator Doors Closing and Aligning the doors Using your Refrigerator Ensuring Proper Air Circulation Adjusting the Controls... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains several important safety notices. Always read and obey all of the following safety messages. This is the safety alert symbol. This symbol is a warning to potential dangers that could cause death, injury or damage to you, others or the product. All safety messages will follow after this warning symbol and the word “DANGER”, “CAUTION”... -
Page 5: Requirements For Ground Connection
The use of an extension cable will increase the amount of space needed behind the refrigerator. REPLACING ELECTRICAL CABLE If the power cord is damaged, it must be replaced by our service center or qualified LG technician to avoid any risk. WARNING... -
Page 6: Parts And Features
Read this section to familiarize yourself with the parts and features of your new refrigerator. NOTE: This guide covers different models. Your refrigerator could have some or all of the features and parts listed below. The location of some of the parts may not correspond to that of your model. Ice Bin Freezer Shelf Digital Sensor Control... - Page 7 Read this section to familiarize yourself with the parts and features of your new refrigerator. NOTE: This guide covers different models. Your refrigerator could have some or all of the features and parts listed below. The location of some of the parts may not correspond to that of your model. Ice Maker Freezer Shelf Digital Sensor Control...
-
Page 8: Parts And Features
Read this section to familiarize yourself with the parts and features of your new refrigerator. NOTE: This guide covers different models. Your refrigerator could have some or all of the features and parts listed below. The location of some of the parts may not correspond to that of your model. Ice Maker Ice Bin Freezer Shelf... -
Page 9: Refrigerator Installation
WARNING EXCESSIVE WEIGHT HAZARD Use the assistance of two or more persons to move or install the refrigerator. Not following these instructions may cause injury to the back and other parts of the body. UNPACKING Before installing your refrigerator, remove any tape or temporary stickers. -
Page 10: How To Remove And Install The Refrigerator Doors
HOW TO REMOVE AND INSTALL THE REFRIGERATOR DOORS If entrance is lees than 35 inches wide, the refrigerator’s door will need to be removed. IMPORTANT: Before starting, turn off and unplug the refrigerator. Remove all food and the racks from the doors. 10 mm 13/32 in 3/8 in... -
Page 11: Refrigerator Doors
Fig. 6 • To replace doors, begin with refrigerator door and then follow with freezer door. 3. Replacing Refrigerator Door • Set door on Bottom Hinge Pin (See Fig. 7). • Place hinge pin of middle bracket inside the hinge pin insert on the top of the door (See Figure 8). Hold the door in place and line up the hinge with the holes in the refrigerator housing. -
Page 12: How To Reverse And Install The Refrigerator Doors
HOW TO REVERSE AND INSTALL THE REFRIGERATOR DOORS You may find it more convenient to have the doors converted from the left opening type (factory installed) to the right opening type. Directions refer to the right side as the side on your right as you face the unit. 10 mm 13/32 in 3/8 in... - Page 13 Fig. 6 • Pry off cover on top refrigerator on left side to uncover screw holes (See Figure 7). • Set freezer door and top hinge parts to the side and remove refrigerator door. Cover (on top of refrigerator) 2. Reversing and Reinstalling Refrigerator Door • Using a 1/4 inch socket wrench, loosen and remove hinge pin from the middle hinge bracket.
- Page 14 Fig. 13 • At this point, remove the Decorative Bolt on bottom on refrigerator housing from the left side of refrigerator (See Figure 14). You will need this hole for the Bottom Hinge. Fig. 14 Decorative Bolt • Move the Bottom Hinge to the left side of housing keeping the same orientation, and reattach with three bolts (Figure 15).
- Page 15 • With flat-head screwdriver, carefully pry off and remove the cover over the screw holes on the left side of refrigerator housing (Figure 20). Fig. 20 • Remove the outer lower Decorative Screw from housing at area between freezer and refrigerator doors (See Figure 21).
-
Page 16: Closing And Aligning The Doors
• Replace cover from left side of refrigerator top onto the right of top to cover the holes. Cover is also force- fitted (Figure 27). Fig. 27 Cover (on top of refrigerator) After changing doors, make sure that the corners of the Door Gaskets are not folded over. -
Page 17: Using Your Refrigerator
ENSURING PROPER AIR CIRCULATION In order to obtain stable temperature, the air must flow between the freezer and refrigerator sections. As shown in the illustration below, the cold air enters through the bottom part and circulates upward. This air returns below the freezer floor and the rest of the air enters the refrigerator section through the top vent. -
Page 18: Adjusting Control Settings
ADJUSTING CONTROL SETTINGS Give the refrigerator time to cool down completely before adding food. It is best to wait 24 hours before adding food to the refrigerator. The mid-settings indicated in the previous section should be correct for normal household refrigerator usage. -
Page 19: Refrigerator Section
Packaging Recommendations: • Use sealed plastic containers. • Use plastic containers with a smooth surface. • Package with aluminum foil of high resistance. • Wrap with paper layered with plastic. • Use water proof plastic. • Use recommended plastic bags to store frozen foods. Follow these packaging or container instructions in order to reach the best freezing Do not use:... -
Page 20: Frozen Meat Compartment (Chef Fresh/Snack Pan)
Sliding Shelves (in some models) You can slide some of the shelves in your refrigerator towards inside or outside like explained below. • To slide the shelf towards the outside: Pull towards you, figure A. • To slide the shelf towards the inside: Push until it stops, figure B. -
Page 21: Door Racks
Replacing the Fixed Refrigerator Rack • Hold the rack’s edge against the door’s inner wall. • Press the rack until it stays in its position. DOOR RACKS The door racks are removable for easy cleaning and adjusting. • To remove the rack, simply lift the rack up and pull straight out (1). • To replace the rack, slide it in above the desired support button and push down until it stops (2). -
Page 22: Refrigerator Care And Cleaning
REFRIGERATOR CARE AND CLEANING WARNING EXPLOSION HAZARD Do not use flammable cleaners. Not following these instructions can cause death, explosion or fire. The refrigerator, as well as the freezer, do their own de-freezing. This process does not prevent the build up of contaminants, therefore it is suggested that you clean both parts once a month;... -
Page 23: Power Interruptions
REFRIGERATOR CARE AND CLEANING Type B POWER INTERRUPTIONS 1. In case of a black out, call your electric company and ask how long it will last. 2. In case of a 24 hour or less black out, do not open the refrigerator;... -
Page 24: About The Automatic Ice Maker
ABOUT THE AUTOMATIC ICE MAKER NOTE: The automatic Ice maker is only included in some models. Check your specifications of your refrigerator. WARNING PERSONAL INJURY HAZARD Avoid contact with any moving parts of the ejector mechanism or with the heater that releases the ice cubes. -
Page 25: Connecting The Water Line
NOTE: It is necessary to have a water source when both water and/or ice dispensers are available in your product. BEFORE START The water source is not guaranteed by the refrigerator manufacturer. Follow instructions carefully in order to reduce damage. Air located inside the water pipes can cause hammering or tapping causing damage to the inner pipes or water spillage in the inside of the refrigerator. - Page 26 3. DRILL A HOLE FOR THE VALVE Drill a 1/4” (6,35 mm) diameter hole water pipeline. Remove jagged edges produces after perforation. Make sure water does not reach the drill. Not performing the 1/4” (6,35 mm) perforation can lead to a low or smaller ice production.
- Page 27 • Remove the ring plug (1) from the valve located at the top of such device. • Place compression nut and the ferule at the end of the pipeline. Insert pipeline into the connection valve as far as possible. Hold tightly while holding pipeline. Tubing Clamp Compression...
-
Page 28: Troubleshooting Guide
UNDERSTANDING SOUNDS YOU MAY HEAR Your new refrigerator might produce certain noises that your previous refrigerator did not. It is normal if you worry. Most of the new sounds you will be hearing are actually normal and expected. Hard surfaces like walls or floor can increase sounds and make them sound louder than they really are. - Page 29 Problem Possible Causes STRANGE SOUNDS • The refrigerator is not correctly OR SNOOZING/ positioned. VIBRATIONS • The refrigerator is plugged. • The light bulbs are loose. THE LIGHT WON’T TURN ON • A light bulb has gone bad. • The replaced refrigerator was an older model. • The room temperature is hotter than usual.
-
Page 30: Troubleshooting Guide
Problem Possible Causes • The ice maker has been installed correctly. • The ice has been on storage too long. THERE IS A WEIRD • The food hasn’t been packed in the TASTE AND SMELL correct way. IN THE ICE • The water supply contains mineral and sulfur. -
Page 31: Spanish Version
LG Customer Information Center 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User 1-888-542-2623 CANADA Register your Product Online! www.lg.com...
