Foundations 100-SSC-SM Installation Instructions

Clad stainless steel changing station

Download this manual

Model

100-SSC-SM

• Failure to follow these warnings and the installation instructions could result in serious injury

or death.

• Read all instructions before installing diaper changing station. Keep these instructions. DO NOT

discard.

Clad Stainless Steel Changing Station

Installation Instructions

(Surface Mount)

IMPORTANT: RETAIN FOR FUTURE

REFERENCE. READ CAREFULLY

WARNING

AVERTISSEMENT

ADVERTENCIA

SI258SM-H

Page 1 (Surface Mount) IMPORTANT: RETAIN FOR FUTURE REFERENCE. READ CAREFULLY Model 100-SSC-SM WARNING • Failure to follow these warnings and the installation instructions could result in serious injury or death. • Read all instructions before installing diaper changing station. Keep these instructions. DO NOT discard.
Page 2 INSTALLATION INSTRUCTIONS ADULT INSTALLATION REQUIRED. TOOLS REQUIRED: Level (A) Measuring tape (B) Power drill with 3/16”, 1/2” and 1/8” masonry bit (C) Power screwdriver with bull nose phillips bit (D) Truss head spanner bit (E) • READ ALL INSTRUCTIONS BEFORE ASSEMBLY OF DIAPER CHANGING STATION. •...
Page 3 INSTALLATION Recommended Blocking: Wood double stud blocking is necessary. Contact an architect complies with building codes (Fig. a). For A. D. A. Compliance 43” (109 cm) 32" (813 mm) on center Fig. a 1. Use #14 Spanner bit to remove and discard Truss Head Spanner screws from unit back (Fig.
Page 4 Using Toggle Anchors (Fig. f) Toggle Wood Stud Anchor 1. Insert metal end of toggle anchor into 1/2” hole. 2. Slide zip strip down snugly against wall. Break-Away 3. Snap off break-away pieces of toggle anchor (Fig. h). 4. Align holes in changing station with toggle anchors and secure top left corner of changing station to wall using machine screws and flat washers.
