NexTraq VT-4225 Manual
  1. Manuals
  2. Brands
  3. NexTraq Manuals
  4. Automobile Accessories
  5. VT-4225
  6. Manual

NexTraq VT-4225 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Notice
This installation guide is published and copyrighted by NexTraq.
Information and specifications contained in this document are subject
to change without notice and do not represent commitments on the part
of NexTraq. Under copyright laws, no part of this installation guide
may be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying and recording, for
any purpose, without the express written permission of NexTraq. This
installation guide does not constitute a warranty as to any product or
service, except to the extent expressly provided in the agreement
under which such a product or service was provided.
Trademarks
NexTraq is trademarked. All other trademarks and service marks
contained within this document are the property of their respective
owners.
Disclaimer
The complete terms and conditions under which NexTraq provides
hardware and services are contained in separate agreements. None of
the information in this document is intended to create additional or
separate warranties or guarantees.
© 2015 NexTraq. All Rights Reserved.
1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319
|
T: 678.762.6800
|
F: 678.762.6805
|
nextraq.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the VT-4225 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NexTraq VT-4225

Summary of Contents for NexTraq VT-4225

  • Page 1 Information and specifications contained in this document are subject to change without notice and do not represent commitments on the part of NexTraq. Under copyright laws, no part of this installation guide may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of NexTraq.
  • Page 2 Introduction Following the purchase of VT-4225, there will be several factors to consider prior to its installation, including placement of the VT-4225 hardware and the selection and placement of the antenna(s). This installation guide is designed to provide instructions for the installation of the VT-4225 hardware for use with the NexTraq™...

  • Page 3: Post-Installation Testing

     Availability of a constant 12-volt power supply The VT-4225 can be secured in any location that will not interfere with the safety of vehicle operation. Avoid placing the VT-4225 near moving parts or next to any vehicle pedals. Always consider the placement of antennas and be sure any cables can reach the desired location of the mobile device and MDT unit.
  • Page 4 VT-4225 and MDT Components VT-4225 MDT Tablet 1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319 T: 678.762.6800 F: 678.762.6805 nextraq.com...
  • Page 5 Final connector installation should look similar to that in Figure 2. Figure 2 1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319 T: 678.762.6800 F: 678.762.6805 nextraq.com...
  • Page 6 AUX2 port. The RJ45 end will be attached to the mounting bracket of the tablet. Installation location of tablet needs to be verified with the customer. 1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319 T: 678.762.6800 F: 678.762.6805 nextraq.com...
  • Page 7 15. Attach the tablet mounting bracket to the tablet. The mounting bracket includes two security screws. Use these screws to secure the tablet to the bracket. 1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319 T: 678.762.6800 F: 678.762.6805 nextraq.com...
  • Page 8 In the event that the VehicleDataServices app is not located on the dashboard you can locate it under All Apps highlighted with the red box in Figure 7. Figure 7 1200 Lake Hearn Drive, Suite 500, Atlanta, GA 30319 T: 678.762.6800 F: 678.762.6805 nextraq.com...
  • Page 9 LMU. An ignition cycle may be required for the MDT to register a connection. See Figure 8. Figure 7 20. Verify with NexTraq Customer Support that the VT-4225 is operational NexTraq Customer Support: 1-800-358-6178 or 678-746-6850 Customer Service Hours:...

  • Page 10: Installation Troubleshooting

    Check wiring on device. Bad constant power sources or grounds can cause rapid power cuts preventing the device from locking COMM and/or GPS.  Be sure to view the correct mobile in the NexTraq Web application.  Check antenna connections and placement.
