Mimitakara UP-6SY Quick Start Manual

Digital Hearing Device

Accessories Listing

Hearing Device Portable Case x 1
Ear Cap (S,M,L x 1) Trial Battery x 2

Operating Diagram

Ear cap
Volume adjustment dial /
Microphone
Battery cap

Removing the Hearing Device from the Case

Open the lid of the case. Remove the hearing device
Pull upwards on the hearing from the case.
device until it is in the vertical Close the battery cap.
position.

To Insert the Hearing Device Battery

Open the battery cap
Adjusting the volume by using another side of cleaning brush.
Cleaning Brush x 1
Volume adjustment dial
Red(High)
Close
Insert hearing device into the
case.
Open
Install a 312(PR41) battery into
the hearing device as shown.
Positive terminal facing outwards,
close the battery cap.

Adjusting the Volume

The volume will be higher when
Black(Off)
you turn the switch clockwise.
And the volume will be lower
Green(Low)
when you turn the switch
counterclockwise.
Place the Hearing Device
Close the case, the battery will
stay automatically isolation .

Usage

1. Turn the power on, and hold 2. Use your finger to grasp the
the body of the hearing device. microphone and block the
hole.
3. Place the hearing device in your ear while you are grasping it.
You will hear a ringing sound if you
put the hearing device into your ear
without holding the microphone.

Replacing the Ear Cap

※ If the ear cap is damaged or wax cannot be removed from it,
you will need to replace it.
1. Remove the old ear cap by pulling it back over the rim and
removing.
2. To replace the new ear cap turn it inside out so that the large
opening is exposed.
3. Place the ear cap onto the brim and roll it back into position
as illustrated. Then return the turnover brim to the original
state.
※ Keep the hearing device away from corroding gas or dust and
do not expose to direct sunlight, high temperatures or humidity.
