Josef Kihlberg JK20V779L

Before all maintenance tasks on the

stapler always first disconnect it from

the air supply.

7.1 CLEANING THE STAPLER

This stapler does not require special servicing. It only

needs regular cleaning with a non-aggressive (non-

corrosive) cleaner agent. Do not remove any parts for

cleaning purposes!

Check the proper functioning of all safety

devices daily. Make especially sure that:

–

the trigger works smoothly, the door stays in place

and the magazine lid does not open itself.

–

all screws and nuts are securely tightened.

–

the stapler is regularly lubricated (refer to chapter

5.2).

7.2 REMOVING JAMMED STAPLES

To remove a staple which has become jammed:

– Pry the door open with a screw driver (Fig. 5/1) .

There are three notches in the door to simplify the

disassembling.

– Remove the door.

– Check the canal for defective staples.

– Insert the door into the rear nozzle plate and push

until it clicks shut.

The three notches at the door must be

assembled to the front.
