Read instructions carefully prior to assembly.
Thank you for purchasing this quality product. Check carefully for small parts which may come loose during
shipment. Remove all components from pack and place top down on soft surface such as carpet or cloth to
prevent scratching the finish. Identify and count all parts as specified below.
It is recommended to use two or more persons during the assembly process.
HARDWARE LIST:
No.
Description
A
Ø1/4*19 Flat Washer
B
Ø1/4*13 Spring Washer
Ø1/4*50 Allen Bolt
C
D
Ø1/4*30 Allen Bolt
4mm Allen Key
E
3
Step 1: Attach the Leg Frame (2) to the Stretcher (3) by using
Flat Washer (A), Spring Washer (B), Allen Bolt (C) and
tighten bolts by using Allen key (E)
Made in Vietnam
ASSEMBLY INSTRUCTIONS
GROUP NO.: A15000001- MODERN DR
ITEM NO.: 15116011 TABLE, DINING TRESTLE, SLIDE-CAFÉ
1
2
A B C
No.
Description
18 Pcs
1
Table Top
18 Pcs
2 Pcs
2
Leg Frame
16 Pcs
1 Pc
3
Stretcher
Step 2: Then attach the Base to the Table Top (1) by using
Flat Washer (A), Spring Washer (B) , Allen Bolt (D), tighten
all bolts by using Allen Key (E). Turn the Table to upright
position. Assembly product is now completed
E
PARTS LIST:
Sketch
E
D
B
A
Qty
1Pc
2Pcs
1Pc
Page: 1/1
