H
ow to use washer
(1)
(1) Button : Power
(2) Dial : Program
(3) Button : Start/Pause
(4) Button : Option
Power
1. Power
• Press the Power button to turn power on and
off.
• To cancel the
Time Delay function, the
Power button should be pressed.
2. Initial Program
• When the Power button is pressed, the
washer is ready for Cotton program. And the
other initial conditions as follows.
• So, if you want to advance into the washing
cycle without changing the program, just
press Start/Pause button and then the
washer will proceed.
■ Initial program
• [WD(M)-1231(0~9)RDK/GL-5112W(T)RD/
WD1231(0~9)RDK]
- Cotton Program / Main wash / Normal Rinse /
1200 rpm / 60˚C
• [WD(M)-1431(0~9)RDK/GL-5114W(T)RD]
- Cotton Program / Main wash / Normal Rinse /
1400 rpm / 60˚C
(2)
(3)
(5) Child lock
(6) Button : Rinse
(7) Button : Spin
(8) Button : Temperature
(4)
(5)
(6)
(9) Button : Dry
(10) Button : Intensive
(11) Button : Time Delay
Program
• 9 programs are available according to the
laundry type.
- Cotton
- Cotton-Eco
- Synthetic
- Delicate
- Wool/Silk
• Lamp will light up to indicate selected program.
• When Start/Pause button is pressed, the
Cotton program is automatically selected.
- By turning the Program dial, the program is
selected in order of "Cotton - Cotton-Eco -
Synthetic - Delicate - Wool/Silk - Hand Wash -
Quick 30 - Duvet - Drain".
Regarding to the laundry type for each program
Please refer to the page 15.
(7)
(8)
(9)
(10)
- Hand Wash
- Quick 30
- Duvet
- Drain
17
(11)
