- Page 1 XAS405-1 INSTRUCTION MANUAL For 13-27" TV If you have any questions along the way, just give us a call 1-800-460-0956 or mail to customerservice@x-mount.com. We’re ready to help!
- Page 2 Before getting started, let’s check below lists to make sur e it is just right for you! MAX:100mm/3.94" (MIN:50mm/1.97") Check your monitor No? This mount is NOT compatible. VESA is within MAX:100mm/3.94" (MIN:50mm/1.97") Min and Max size Yes? Perfect ! CAUTION: DO NOT exceed the maximum weight Does your monitor indicated.
-
Page 3: Front View
FRONT VIEW FRONT VIEW 100mm [3.94in] 93mm [3.66in] 100mm [3.94in] 405mm [15.95in] SIDE VIEW SIDE VIEW SIDE VIEW ±90° +45° ±360° -45°... - Page 4 WARNING:This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. Never use damaged parts! NOTE: Not all hardware included will be used. Parts and Hardware for Monitor Installation Washers TV Screws M4x12mm...
- Page 5 Parts and Hardware for Monitor Arms Assembly -Pole x1 -Pole folder x1 -3mm Wrench x1 -5mm Wrench x1 -M5x15 Bolts x3 -M6x10 Bolts x4 -Base x1 - Support Tube x2...
- Page 6 Pole Unit...
- Page 7 1:Put the pole on the base and use wrench to fasten bolts fully. 2:Install the two support tubes into base by using wrench to fasten the bolts...
- Page 8 3-1 Assemble Monitor Connection with Monitor Choose the suitable bolts and washers according to the diameter of the hole at the back of the monitor . Monitor Connection...
- Page 9 3-2 Connect the Monitor Connection and Fixed Assembly Use the wrench to fasten or loosen the bolt to adjust the height of monitor connection. ① Fully fasten bolt when finish. ① Tighten Monitor...
- Page 10 Tilting (±45°) and leveling ±90° ±45°...
