www.costway.com
USER'S MANUAL
INFLATABLE KAYAK
SP37497
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Follow Costway
Please give us a chance to make it right and do better！
Visit us: www.costway.com
Contact our friendly customer service department for help first.
Replacements for missing or damaged parts will be shipped ASAP!

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP37497 and is the answer not in the manual?

Questions and answers

Related Manuals for Costway SP37497

Summary of Contents for Costway SP37497

  • Page 1 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Follow Costway Please give us a chance to make it right and do better！ Visit us: www.costway.com Contact our friendly customer service department for help first. Replacements for missing or damaged parts will be shipped ASAP!

  • Page 2: Before You Start

    Contact Us! Do NOT return this item. Contact our friendly customer service department for help first. E-mail US: cs.us@costway.com UK: cs.uk@costway.com Before You Start Before You Start Please read all instructions carefully. Retain instructions for future reference. Separate and count all parts and hardware.
  • Page 3 For your own safety and that of your equipment, make sure to take the following precautions. Failure to follow warning notices and instruction may result in property damage, serious injury or death. Inflatable kayak are a great option for camping trips, boating and riders with limited transport/storage space.

  • Page 4: Product Features

    Hull Footrest Air mat floor Seat Air valve PRODUCT FEATURES Model Aluminum Hand Seat Carry Center Fin Repair Kit Model Paddle Pump SP37497 ● ● ● ● ● ● Model Length Width Thickness Max. Max. pressure weight SP37497 330cm 81cm...

  • Page 5: Set-Up Preparation

    SET-UP PREPARATION 1. Unfold the Kayak from the packaging. Choose a smooth and clean surface to unfold the kayak. Roll out the kayak until it is laying flat with top side facing up. 2. Valve operation Follow the instructions below for valve operation and correct inflation and deflation procedures.
  • Page 6 3. Kayak inflation Steps a. Unscrew the valve cap, press down the valve pin to open the valve. Let the air flow naturally into the product to save the time of inflation, and then press down the valve pin again to close the valve (in “UP”...
  • Page 7 6. Fin installation Once the kayak is inflated, slide in the middle fin to the base and insert the fixed pin. 7. Inflation tips and precautions DO NOT use an air compressor. Damage to your kayak caused by over inflation from an air compressor is not covered by our warranty.
  • Page 8 ALU telescopic ISUP paddle FUNCTION A (Suitable for SUP): To build the paddle, hold the button in while sliding the pieces together until they click into place. The last section(top) of the paddle is adjustable. To find the ideal height for your paddle, start by building the paddle so it is 6 inches taller than your own height.
  • Page 9 LEAK DETECTION AND REPAIR Air Leak Detection If the kayak is losing air pressure, not caused by colder temperatures, check the kayak for leaks, starting with the valves. Valve leakage is rare, but if you do find a leak we can send you a replacement valve. To locate a leak , we recommend mixing soap and water in a spray bottle, and spraying around the valve.
  • Page 10 ● Apply three coats of adhesive to the patch and the kayak. Wait 5 minutes in between each coat. ● Place the patch over the tear/rip. The adhesive will react quickly, so make sure the positioning is precise/accurate. Use the roller to ensure the patch lays flat and even.

  • Page 11: For Your Safety

    FOR YOUR SAFETY No protection against drowning Design working pressure 8 Psi/0.5Bar Swimmers only Always supervise children in water Do not use in white water Do not use in breaking waves Do not use in offshore current Do not use in offshore wind...
  • Page 12 Welcome to visit our website and purchase our quality products! With your inspiring rating, COSTWAY will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! US office: Fontana, California UK office: Ipswich Reward Points...
