- Page 1 CF-3461-3 3-TIER DUMBBELL RACK Note: Both Serial Number and Model Number are Required when Ordering Parts Customer Service RECORD SERIAL NUMBER HERE (800) 548-5438 (858) 578-7676 CATALOG NUMBER LOT CODE 0507 - 003 (858) 578-9558...
-
Page 2: Table Of Contents
OWNER'S MANUAL CONTENTS INSTRUCTIONS ..............FRAME ASSEMBLY .............. DECAL PLACEMENT............. DECAL REFERENCE............. PART LIST................ABBREVIATIONS..............BOLT SIZING CHART............WASHER SIZING CHART............MAINTENANCE SCHEDULE..........GENERAL MAINTENANCE INFORMATION......WEIGHT TRAINING TIPS............EXERCISE LOG..............LIMITED WARRANTY............CF-3461-3 ASSEMBLY PAGE 01... -
Page 3: Instructions
OWN ER'S MAN UAL INSTRUCTIONS Before beginning assembly please take the time to read instructions thoroughly. Please use the various lists in this manual to make sure that all parts have been included in your shipment. When ordering, use part number and description from the lists. - Page 4 OWN ER'S MAN UAL ***THIS PAGE WAS INTENTIONALLY LEFT BLANK*** CF-3461-3 ASSEMBLY PAGE 03...
-
Page 5: Frame Assembly
OWNER'S MANUAL FRAME ASSEMBLY PAGE 04 CF-3461-3 ASSEMBLY... - Page 6 OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. CF-3461-3 ASSEMBLY PAGE 05...
- Page 7 OWNER'S MANUAL FRAME ASSEMBLY NOTE: - WRENCH TIGHTEN HARDWARE. PAGE 06 CF-3461-3 ASSEMBLY...
-
Page 8: Decal Placement
OWNER'S MANUAL DECAL PLACEMENT PAGE 07 CF-3461-3 ASSEMBLY... -
Page 9: Decal Reference
OWNER'S MANUAL DECAL REFERENCE SERIAL # DECAL 021-0003341 021-0003347 021-0003008 021-0003135 021-0003627 021-0003221 CF-3461-3 ASSEMBLY PAGE 08... -
Page 10: Part List
OWNER'S MANUAL PART LIST NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED ITEM NO. PART NUMBER DESCRIPTION QTY. 026-01X5221 SIDE FRAME ASSEMBLY 026-01X3209 UPPER TIER ASSEMBLY 026-01X3208 LOWER TIER ASSEMBLY 026-01M2276 END CAP DOMED 026-01P3552 SIDE PLATE 026-01PL2211-B RUBBER FOOT 026-01PL2449 DUMBBELL SADDLE (THRU HOLE) 011-0101026... -
Page 11: Abbreviations
OWNER'S MANUAL ABBREVIATIONS BZ = Black Zinc WZ = White Zinc HHB = Hex Head Bolt FHCS = Flat Head Cap Screw BHCS = Button Head Cap Screw SHCS = Socket Head Cap Screw SHSS = Socket Head Shoulder Screw CF-3461-3 ASSEMBLY PAGE 10... -
Page 12: Bolt Sizing Chart
OWNER'S MANUAL BOLT SIZING CHART 1 3/4" 2 3/4" 3 3/4" 4 3/4" 5/16" HHB 1 1/4" 2 1/4" 3 1/4" 4 1/4" 5 1/4" 1 1/2" 2 1/2" 3 1/2" 4 1/2" 5 1/2" 1" 2" 3" 4" 5" 0"... - Page 13 OWNER'S MANUAL BOLT SIZING CHART (CONTINUED) 3/8" FHCS 3/4" 1 3/4" 2 3/4" 2 1/4" 1 1/4" 1 1/2" 2 1/2" 1" 2" 3" 0" 3/8" BHCS 3/8" SHCS 3/4" 3/4" 1" 0" 0" 1/4" HHB 1/2" FHCS 3/4" 3/4" 1 1/4"...
-
Page 14: Washer Sizing Chart
OWNER'S MANUAL WASHER SIZING CHART 013-0102026 013-0102004 013-0002004 013-0402005 013-0102003 013-0002003 1/2" 1/4" 5/16" 3/8" 3/8" 1/2" FLAT WASHER FLAT WASHER FLAT WASHER FLAT WASHER FLAT WASHER FLAT WASHER LARGE, USS, 34mm SMALL, SAE, 13mm LARGE, USS, 22mm SMALL, SAE, 21mm LARGE, USS, 25mm SMALL, SAE, 27mm 013-0402007... - Page 15 OWNER'S MANUAL WASHER SIZING CHART (CONTINUED) 026-01M0211 026-01M0760 026-01M0198 1/4" LONG 1/2" LONG HEAVY 1/2" LONG FLANGED SPACER FLANGED SPACER FLANGED SPACER 026-01M211T 026-01M0532 026-01M0551 1/4" LONG HEAVY 11/16" LONG HEAVY 1" LONG HEAVY FLANGED SPACER FLANGED SPACER FLANGED SPACER 026-01M0780 026-01M0788 026-01M0761...
-
Page 16: Maintenance Schedule
OWNER'S MANUAL MAINTENANCE SCHEDULE COMMERCIAL HOME ROUTINE LATEST DATE ENTRY MAINTENANCE MAINTENANCE Inspect; Links, Pull Pins, Snap Locks, DAILY WEEKLY Swivels, Weight Stack Pins Clean; DAILY WEEKLY Upholstery Inspect; Cables or Belts and their DAILY WEEKLY tension Inspect; WEEKLY 3 MONTHS Accessory Bars, and Handles Inspect;... -
Page 17: General Maintenance Information
OWNER'S MANUAL HOIST FITNESS SYSTEMS GENERAL MAINTENANCE INFORMATION Links, Pull-Pins, Snap Hooks, Swivels, Weight Stack Pins: *Check all pieces for signs of visible wear or damage. *Check springs in snap hooks and pull-pins for proper tension and alignment. *If the spring sticks or has lost its rigidity, replace it immediately. -
Page 18: Weight Training Tips
OWNER'S MANUAL WEIGHT TRAINING TIPS Use this manual to guide you through the basic exercises you can perform on your CF-3461-3 HOIST® Fitness System. To gain maximum results and avoid possible injury, consult a fitness professional to develop your complete exercise program. -
Page 19: Exercise Log
OWN ER'S MAN UAL CF-3461-3 ASSEMBLY PAGE 18... -
Page 20: Limited Warranty
Hoist Fitness Systems sole responsibility shall be to repair or replace the component within the terms stated above. Hoist Fitness Systems shall not be liable for any loss or damage of any kind including any incidental or consequential damages resulting, directly or indirectly from any warranty expressed or implied or any other failure of this product.
