NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
AquaSense
Connected EZ Gear Hardwire
Powered Sensor Faucets
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
LIMITED WARRANTY
®
Z6915-XL-W1
Advertisement
Related Manuals for ZURN plumbSMART AquaSense Z6913-XL-W1
Summary of Contents for ZURN plumbSMART AquaSense Z6913-XL-W1
- Page 1 AquaSense ® Connected EZ Gear Hardwire Powered Sensor Faucets Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending Z6913-XL-W1 Z6915-XL-W1 Sensor-Operated Lavatory Faucets with Smart Connected Features WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov LIMITED WARRANTY All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the...
- Page 2 This Page Intentionally Left Blank...
-
Page 3: Required Tools
AquaSense® Package Contents Z6913-XL-W1 Z6915-XL-W1 Spout Assembly Aerator Spout Assembly Aerator and Key and Key Base Gasket Base Gasket Shank Shank Mounting Kit Mounting Kit Electronics Box Electronics Box with Ceramic with Ceramic Valve Valve Filter Filter Endpoint Y-Cable DC Adapter Required Tools Smooth Jawed Phillips Head... -
Page 4: Specifications
Unit is furnished with a standard 1.5 GPM aerator, and mounting hardware. Zurn Lead Free products (-XL) are designed and manufactured to comply with Section 1417 of the Safe Drinking Water Act (SDWA) which mandates the weighted average lead content of no more than 0.25% of the wetted surface... - Page 5 Cover Plate Installation Instructions 1. (For faucets with -CP4 or -CP8 suffix). Remove adhesive backing from gasket and then pass sensor connector wire and shank through gasket. Align gasket with faucet bottom and press firmly together. Pass sensor connector and shank through cover plate and fasten to the faucet with the provided screws.
- Page 6 Endpoint & Electronic Module Installation Instructions 1.a. Install endpoint on wall surface within 2 feet radius of faucet 2. Tighten electronics module assembly to shank and connect with dry wall anchors & screws or doubled sided VHB tape water line(s). 1.b.
-
Page 7: Care And Cleaning Instructions
5.c. 6. Ensure that sink is clear of tools/debris and is in normal MJ unit (sold separately) operating condition, and remove protective film from sensor lens has been removed. Note: Do not connect more than 3 boxes to a single transformer 7. - Page 8 Install Zurn Gateway per the Gateway Instructions Manual Request plumbSMART Administrator Account at 844-987-6737 Zurn creates your Enterprise Account for you! (You will be required to identify your building location, number of floors, and number of rooms.) Log in to plumbsmart.zurn.com Register each Connected Product in plumbSMART (Watch How-To Videos to Get Started.
- Page 9 If not, install washer. If a bles to the faucet shank. washer is damaged, replace with new. For further assistance with troubleshooting visit http://www.zurn.com FV740 Rev. C 04/06/21 Page 7...
- Page 10 Details tab listed as “Activated” NETWORK: Senet SUBSCRIPTION STATUS: Activated LAST HEARD FROM: 07/14/2020, 04:29 PM CDT If listed as “Deactivated”, contact Zurn Custom Service at 1.855. ONE.ZURN (1.855.663.9876) for assistance. Step 1 “Status – Good” posted in plumbSMART and faucet not actuating Verify LoRa Monitor’s cables are connected to IR sensor...
- Page 11 If LORA LED does not turn ON solid and ethernet cable connected, contact facility IT administrator to modify port rules to allow Zurn gateway to access the internet via local router. If gateway model is ETH/LTE, visually verify SIM card is installed in designated slot on the side of gateway.
- Page 12 Verify product image and model number from plumbSMART product page “Details” tab against model number cited on product literature and packaging. If incorrect, contact Zurn Custom Service at 1.855.ONE.ZURN (1.855.663.9876) for assistance. “High Daily Faucet Activate Rate” posted in plumbSMART Step 1 Verify faucet is not falsely triggering.
- Page 13 Filter and Mixing Valve Installation Control Box Attach adapter here with -MV P6900-120BC, Filter in standard faucet installation P6900-12BC Filter P6900-MV-ADAP [Supplied Adapter] with -MV Option To Control Box Supplied Adapter 3/8 Copper Mixing Valve Tube (By Others) For use with -MV Option FV740 Rev.
- Page 14 Z6913-XL-W1 & Z6915-XL-W1 Parts List Description Product No. Description Product No. Z6915 Spout Assembly with Sensor, Item 1A P6915-XL-2 Filter Kit, Item 9 P6900-120BC Z6913 Spout Assembly with Sensor, Item 1B P6913-XL-2 Filter Screen, Item 10 P6900-MV-7 Z6915 Base Plate Gasket, Item 2A P6915-42-WEDGE Mixing Valve with Filter, Item 11 P6900-XL-MV...
- Page 15 This Page Intentionally Left Blank...
- Page 16 ZURN INDUSTRIES, LLC W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 ZURN.COM Rev. C Date: 04/06/21 C.N. No. 143637 Prod.
