MODEL PA10SDG SERIES
10'' SINGLE-HEAD FLOOR GRINDER
OWNER'S/OPERATOR'S MANUAL
SERIAL
NUMBER -
You should record the Serial Number of your Floor Grinder on this
Owner's/Operator's Manual and on the Warranty Card. The Warranty
Card must be sent back with all the required pertinent information for
the warranty to take effect.
Caution!
Read Safety and General Instructions carefully before using saw for the first time.
REV. 1
Made in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Pearl PA10SDG Series
Summary of Contents for Pearl PA10SDG Series
- Page 1 MODEL PA10SDG SERIES 10'' SINGLE-HEAD FLOOR GRINDER OWNER'S/OPERATOR'S MANUAL SERIAL NUMBER - You should record the Serial Number of your Floor Grinder on this Owner's/Operator's Manual and on the Warranty Card. The Warranty Card must be sent back with all the required pertinent information for the warranty to take effect.
- Page 2 INTRODUCTION Congratulations on your purchase of a PA10SDG Grinder. We are certain that you will be pleased with your purchase. PEARL takes pride in producing the finest construction power tools and diamond blades in the industry. Operated correctly, your PA10SDG Grinder should provide you with years of service. In order to help you, we have included this manual.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY Safety Messages Damage Prevention Message General Safety Precautions and Hazard Symbols Rules for Safe Operation California Proposition 65 Message Hazard Symbols Electrical Requirements 8-10 Safety Label Locations Product Specifications UNPACKING and TRANSPORT Unpacking Contents Transport ASSEMBLY and OPERATION Handlebar Adjustment Grinding Discs Installation Gasoline Engine Unit... -
Page 4: Safety Messages
PA10SDG SAFETY Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. SAFETY MESSAGES A safety message alerts you to potential hazards that could hurt you or others. -
Page 5: Rules For Safe Operation
PA10SDG SAFETY MAKE THE WORKSHOP KID PROOF Make the workshops kid proof by using padlocks, master switches or by removing starter keys. DO NOT FORCE THE TOOL A power tool will do a job better and safer operating at the rate for which it was designed. USE THE RIGHT TOOL DO NOT force a tool or an attachment, to do a job that it was not designed to do. -
Page 6: California Proposition 65 Message
PA10SDG SAFETY USE RECOMMENDED ACCESSORIES Consult the owner’s manual for recommended accessories. Using improper accessories may increase the risk of personal or by-stander injury. NEVER STAND ON THE TOOL Serious injury could occur if a power tool is tipped, or if a cutting tool is unintentionally contacted. -
Page 7: Hazard Symbols
PA10SDG SAFETY HAZARD SYMBOLS ELECTRICAL SHOCK NEVER touch electrical wires or components while the engine is running. They can be sources of electrical shock which could cause severe injury or burns. ROTATING PARTS Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never operate the motor with covers, shrouds, or guards removed. -
Page 8: Electrical Requirements
PA10SDG SAFETY ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! WARNING In case of a malfunction or breakdown, grounding provides a path of least resistance for electric cur- rent to reduce the risk of electric shock. - Page 9 PA10SDG SAFETY WARNING To avoid the possibility of the appliance plug or receptacle getting wet, position the machine to one side of a wall mounted receptacle. This will prevent water from dripping onto the receptacle or plug. A “drip loop,” shown in the picture below, should be arranged by the user to properly position the power cord relative to the power source.
- Page 10 Use of under sized extension cords result in low voltage to the motor that can result in motor burnout and premature failure. PEARL warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords will be repaired or replaced totally at the customer's expense.
-
Page 11: Safety Label Locations
PA10SDG SAFETY OPERATION & SAFETY DECALS The PA10SDG is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. Should any of these operation or safety decals become unread- able, replacements can be obtained by calling (800) 969-5561. CAUTION WARNING DO NOT... -
Page 12: Product Specifications
PA10SDG PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS The PA10SDG is a versatile unit. Operated and used according to this manual, the PA10SDG will provide years of dependable service. FEATURES • Uses either a 10 or 20 segment 10" diameter diamond grinding discs to level, smooth or clean the top surface of concrete slabs. -
Page 13: Unpacking
PA10SDG UNPACKING & TRANSPORTATION CONTENTS Use proper lifting techniques when lifting the PA10SDG. CAUTION If not already done, remove the PA10SDG, accessory box from the carton. In your container, you will find One (1) Motor Manual One (1) PA10SDG One (1) warranty card One (1) PA10SDG Owners Manual MK DiaMonD Warranty CarD Name... -
Page 14: Handlebar Adjustment
PA10SDG ASSEMBLY ASSEMBLY Follow the diagram below to prepare your PA10SDG for operation. HANDLEBAR ADJUSTMENT Adjust the Handlebar, as shown in the figure to the right, for ease of operation and comfort of the user. GRINDING DISCS INSTALLATION You need to install the grinding discs before operation of the PA10SDG The figure to the left shows the components needed to install the discs. -
Page 15: Gasoline Engine Unit
PA10SDG OPERATION FOR GASOLINE ENGINE BEFORE STARTING 1. Use correct diamond wheel for grinding conditions. 2. Ensure wheel mountings are clean and bolts are tightened securely. 3. Check water jet for adequate flow. 4. Place grinding wheels on surface. 5. Start and warm up engine. Refer to engine owners manual for details. 6. -
Page 16: Cleanup
PA10SDG CLEANUP CLEAN UP CAUTION Engine parts are extremely hot following use. Allow engine to cool 1/2 hour before cleaning. Use care during cleanup to avoid injury. 1. To extend operating life, the PA10SDG should be cleaned following every use. NOTE: 2. - Page 17 PA10SDG EXPLODED VIEW Gas Engine...
- Page 18 PA10SDG EXPLODED VIEW Gas Engine...
-
Page 19: Exploded View
PA10SDG3 EXPLODED VIEW Electric Engine GD13 GD15 GD16 GD14 GD17 GD18 GD19 GD20 GD21 GD22 GD23 GD24 GD23 GD25 GD27 GD28 GD26 GD32 GD33 GD20 GD32 GD33 GD29 GD33 GD34 GD35 GD10 GD12... -
Page 20: Parts List
PA10SDG PARTS LIST Item Description Part No. Assembly, Accessory Pack Grinding Wheels 10” (Reference only) Reference Pallet (not shown) PA58259 Carton, SDG-11 Grinder (not shown) PA58272 Tube, Owner’s Manual (not shown) PA55419 Manual, Owner’s (not shown) PA58273 Bolt, Hex HD, 3/8-24 x 1 Grinding Disk, Mounting PA57803 Washer, 3/8 Split Lock PA50925... - Page 21 PA10SDG PARTS LIST Washer, Lock, Split 1/2 PA53524 Washer, Flat SAE 1/2 PA50924 Shaft, 1” Dia Large Gear PA57302 Flexible Mount, Morflex (Morse 402 Insert) PA57411 Mount, Grinding Wheel PA57407 Screw, Hex HD Cap 3/8-16 x 2 1/2 PA56030 Screw, Flt. HD. Sc. 3/8-16 x 2 1/2 PA57562 Nut, 3/8-16, Hex Nylock PA52505...
- Page 22 PA10SDG PARTS LIST GD17 Gasket, 30A Switch Box PA59491 GD18 Seal, Level, 30A Switch Box PA59492 GD19 Lever, On/Off, 30A Switch Box PA59490 GD20 Washer, #10 SAE Flat PA54369 GD21 Washer, Lock, IT, #10 PA58336 GD22 Screw, Pan Head #10-24 x 5/16 PA59494 GD23 Screw, Flat Head 6-32 X 5/16...
-
Page 23: Accessories
PA10SDG ACCESSORIES ACCESSORIES ITEM NUMBER DESCRIPTION 10 Segments HEX1GHP10 10" x 3/4 arbor, 4 holes 20 Segments HEX1GHP20 10" x 3/4 arbor, 4 holes... -
Page 24: Ordering Information
• The Part Description for the part(s) being ordered NOTE: There is a $25.00 minimum order when ordering direct from PEARL. A $5.00 charge will be added to orders having a net billing value under $50.00. All purchases must be made using VISA, MasterCard or American Express. - Page 25 The parts involved or the unit in question should be returned to PEARL or to a point designated by us, transportation prepaid.
- Page 28 6210 SOUTH GARFIELD AVENUE, COMMERCE, CA 90040-0031 TEL 562-927-5561 • FAX 562-928-3857 800-969-5561 www.pearlabrasive.com GEORGIA • USA ONTARIO • CANADA 4963 SOUTH ROYAL ATLANTA DRIVE 375 PIDO ROAD TUCKER, GA 30084-3006 PETERBOROUGH, ONTARIO K9J-6X7 ©2012 PEARL ABRASIVE CO., COMMERCE CA 90040 PA10SDGMANV1...
