Summary of Contents for Tow Tuff TMD-1000HSD
- Page 1 Hard-Surface Trailer Dolly OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Model # TMD-1000HSD 05142020...
- Page 2 Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only.
- Page 3 WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a Hard-Surface Trailer Dolly. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
- Page 4 ASSEMBLY 1. Install two 5” Fix Casters (#15) onto Cross Bar (#14) with Bolt (#12) and Nylon Nut (#3). 2. Attach Tube (#7) to Cross Bar (#14) with Bolt (#6) and Nylon Nut (#3). 3. Then install 5” Caster (#16) on Tube (#7) with Bolt (#12) and Nylon Nut (#3). 4.
- Page 5 DIAGRAM & PARTS LIST Part# Description Qty. Part# Description Qty. Handle Grip Clip Outside Upper Handle I Tube Nylon Nut M10 Bolt M10X20 Bolt M10X50 End Cap Handle II Cross Bar Bolt M10X70 5”Fixed Caster Tube 5”Caster Inside Upper Tube Ball Pin 5/8"...
- Page 6 WARRANTY One-year limited parts warranty PO BOX 203 Miltona, MN 56354 Page of 6...
