Summary of Contents for Centurion Scientific PrO-Eazy

  • Page 1 Scientific Limited Instruction manual...
  • Page 2 Read before using Check the Centrifuge and the Packaging for any shipping damage. • Inform the shipping company and Centurion Scientific immediately Check the order for completeness, if not contact Centurion Scientific • Location The Centrifuge should only be operated indoors.
  • Page 3 Fixing of rotor Fixing for micro and fixed angle rotors BRK5401. BRK54XXseries. BRK53XX series. BRK52XX series Locate 3 pins of fixing, into 3 holes at the top of the rotor Push down firmly into holes. Lift and fit rotor onto the motor shaft. Fit the Screw and spring washer, screw down tight with the supplied tool.
  • Page 4: Very Important

    Rotor balancing. Very Important Balancing of tubes for Micro and Fixed angle rotors Tare (zero) your scales first Weigh a tube , note its weight Weigh another and match its weight to within 0.1 gram Swing out rotor, buckets. Balancing Place all your required tubes in all 4 buckets.
  • Page 5 Tube placement micro rotors Haematocrit Rotor Always fit the lid supplied, as shown to the left ✔ ✘ ✘ ALWAYS load your tubes opposite to each other ALWAYS weigh samples to within 0.1 Gram. For best separations. (see page 4) ALWAYS fit the lid supplied CHECK...
  • Page 6 Tube placement Fixed angle rotors Small fixed angle Rotors Always fit the lid supplied, as shown to the left ✘ ✔ ✘ ALWAYS load your tubes opposite to each other ALWAYS weigh samples to within 0.1 Gram. For best separations. (see page 4) CHECK The rotor screw fixing tightness regularly ....................................
  • Page 7 Tube & bucket placements Swing out rotors Small Swing out rotor ✘ ✔ ✘ ALWAYS load your tubes opposite to each other ALWAYS weigh samples to within 0.1 Gram. For best separations ALWAYS fit ALL the Tube Holders and any supports CHECK The rotor screw fixing tightness regularly ....................................
  • Page 8 Tube placements Swing out rotor Wrong Wrong This is not balanced! ven though there are two samples in two buckets opposite to each other it is not balanced. NEVER run swing out rotors with only two buckets All four buckets must be used at all times Always use the same size tubes as in A per bucket.
  • Page 9 Tube placement Cytology & Cell wash rotors Cytology Rotors Always fit the lid supplied, as shown below ✘ ✔ ✘ ALWAYS load your holders opposite to each other ALWAYS weigh samples to within 0.5 Gram. For best separations ALWAYS fit the lid supplied Check the two top Gaskets and replace regularly (Part Number 8055) CHECK the rotor screw fixing tightness regularly...
  • Page 10 Index. Instruction manuals for. Micro's Haematocrit Centrifuge. EZ913 Complete with BRK5401 rotor 24 x Capillary tubes & 12 x 2ml tubes EZ904 Swing out Rotor Centrifuge. Complete with BRK5508S rotor 8 x 5ml Blood tubes EZ915 Micro tube Centrifuge. Complete with BRK5424 (A), BRK5436 (B), BRK5448 (C), BRK5494 (D) EZ 906 Fixed angle rotor Centrifuge.
  • Page 11: Instructions Of Use

    Instructions of use Program Fault Lid open Imbalance None revolve Inverter Start. Stop Function Lid open ....................................See following pages for analysis methods per model Program By pressing Function button you select any One of four programs, each light up accordingly Actual details are shown in this manual per model Once running, your selected program will flash When the run is finished it will flash faster...
  • Page 12: Fault Codes

    Fault codes How to turn the Buzzer off. Press Function and Start stop. Top Fault LID will flash when Buzzer is enabled Bottom fault LID will flash when disabled Fault Codes. Orange coloured displays Fault Lid open. Close lid firmly (check that nothing is fouling closure) If problem persists contact Service Imbalance An imbalance has occurred, load samples opposite and evenly...
  • Page 13 Programs per Model. Micro's EZ913 Program Serum 1 Serum 2 Urine Speed (Rpm) 13,000 6,000 5,000 2,100 Time (Seconds) Accelleration Deceleration Rcf (g) 15,870 3380 2348 Rotor. BRK5401 Haematocrit/ 12 x 2ml EZ904 Program Serum 1 Serum 2 Urine Sperm Speed (Rpm) 4,000 4,000...
  • Page 14 Programs per Model Small EZ704 Program Speed Serum fast Faeces Urine Sperm 2700 4,000 1480 1700 (Rpm) Time (Seconds) Accelleration Deceleration 1020 Rcf(g) 2235 Rotor BRK5506 & 1 set of adaptors EZ706 Program Serum 1 Faeces Urine Sperm 1700 Speed (Rpm) 6,000 1950 3100...
  • Page 15 Programs per Model Medium EZ504 Program Serum Faeces Urine Sperm Speed(Rpm) 4,000 1400 1600 2,500 Time (Seconds) Accelleration Deceleration Rcf (g) 2611 1020 Rotor BRK1001, B5250 buckets & 1 set of adaptors EZ506 Program Serum Faeces Urine Sperm Speed(Rpm) 5,000 1,500 1,750 2,750...
  • Page 16 Fault codes Prime and Dual models only. Ambient Fault codes are shown in the Speed section of the LED display (shown on previous page The following List show what each Code means and what to do. F A 5 0 Inverter Drive Look at the Obround viewing port (Rear) Note the Code shown in the inverter display.
  • Page 17: Emergency Lid Release

    Emergency Lid release Mechanical Emergency Door release During a power failure, you will not be able to open the Centrifuge lid via the Display button Mechanical override is provided to allow sample recovery However this is for Emergency use only This should Not be used for normal use.
  • Page 18 Do not site the unit in sunlight Always ensure that lids and accessories are correctly tightened before running the unit. Use only official Centurion Scientific Ltd accessories with your centrifuge. It is recommended that regular maintenance and cleaning of the unit and accessories is carried out.
  • Page 19 Care & maintenance. Rotor Always check rotors for cracks and damage, if found replace your rotor. DO NOT USE as dangerous Autoclave for the maximum number of times shown in the sales literature. In brackets( 20) Rotors have a Seven year lifespan and must be replaced . DO NOT USE beyond their Lifespan It is recommended that regular maintenance and cleaning of the rotor and accessories is carried out.
  • Page 20 PrO-Care Service, Warranty & Maintenance pakages The lifespan of a centrifuge depends upon how well it is looked after and maintained. Many of our centrifuges have lived a life of over 15 years. This is not only due to our stringent manufacturing process and high quality components but also to a yearly servicing package.
