- Page 1 Product Code: 1891T OWNER’S MANUAL PRODUCT CODE: 1891T 680kg ENGINE STAND Maximum Width Height Length Weight Capacity 680kg 800mm 895mm 870mm 30kg Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au...
-
Page 2: Table Of Contents
Product Code: 1891T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and safe place for future reference. -
Page 3: Safety Instructions
Product Code: 1891T SAFETY INSTRUCTIONS SAFETY OPERATING INSTRUCTIONS Before using the stand ensure it is in sound condition, and good working order. ü Replace or repair damaged parts. Use recommended parts only. Non-authorised ü parts may be dangerous and will invalidate the warranty. Keep the stand clean for best and safest performance. ü Locate the stand in an adequate working area for its function, keep area clean and ü tidy and free from unrelated materials, and ensure there is adequate lighting. Use on a firm, level surface capable of sustaining the stand and the load. ü Maintain correct balance and footing. Ensure the floor is not slippery and wear non- ü slip shoes. Ensure all non-essential persons keep a safe distance whilst the stand is in use. ü Lock mounting plate in position before fixing a load, and ensure the load is centred ü and securely mounted on the locking plate. Ensure the Stand and the load is stable. ü To move a loaded stand, push it from the load side, above the two fixed wheels. DO ü NOT move the stand from the castor end and never pull the stand towards yourself. Also ensure surface over which the stand is to travel is strong enough to take the stand load and that it is not cracked, uneven or obstructed. -
Page 4: Assembly, Operation, Preventitive Maintenance
Product Code: 1891T ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The 1891T Tradequip Engine Stand accepts a wide variety of engines and transmissions. The head swivels 360º for accessibility to all parts of the engine. It has fully adjustable mounting arms. Ball bearing swivel castors provide excellent manoeuvrability. 2. ASSEMBLY Bolt the two 390mm castor wheels (17) to the front legs (14) using bolts (15) and nuts (18). Attach two 75mm castors (11) to the rear of legs (14), using nuts (13), and lock washers (20). - Page 5 Product Code: 1891T 5. MAINTENANCE Replace or repair damaged parts. Use recommended parts only. Non-authorised parts may be dangerous and will invalidate the warranty. Keep the stand clean for best and safest performance. 6. SERVICE & REPAIR Any Engine Stand found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment. Annual inspection of the engine stand is recommended and can...
-
Page 6: Parts Diagram
Product Code: 1891T PARTS DIAGRAM Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 6... -
Page 7: Parts List
Product Code: 1891T PARTS LIST Part Description Qty Part Description Qty Pin 75mm Castor Handle Flat Washer ˚12 Main Post Nut M12 Nut M14 Leg Flat Washer ˚14 Bolt M8x20 Turning Plate Lock Washer ˚8 Shifting Stand 90mm Castor Bolt M14x65 Nut M8 Bolt M12x80 Bolt M12x90 Rear Beam Lock Washer ˚12 Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 7... -
Page 8: Warranty
Product Code: 1891T WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
