- Page 1 Product Code: 1894T OWNER’S MANUAL PRODUCT CODE: 1894T 500kg ENGINE STAND Maximum Gearbox Wheel Length Height Width Weight Capacity Ratio Size 500kg 40:1 1190mm 1230mm 850mm 90mm 54kg Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au...
-
Page 2: Table Of Contents
Product Code: 1894T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and safe place for future reference. -
Page 3: Safety Instructions
Product Code: 1894T SAFETY INSTRUCTIONS SAFETY OPERATING INSTRUCTIONS Before using the engine stand ensure it is in sound condition, and good working ü order. Replace or repair damaged parts. Use recommended parts only. Non-authorised ü parts may be dangerous and will invalidate the warranty. Keep the stand clean for best and safest performance. ü Locate the stand in an adequate working area for its function, keep area clean and ü tidy and free from unrelated materials, and ensure there is adequate lighting. Use on a firm, level surface capable of sustaining the stand and the load. ü... -
Page 4: Assembly, Operation, Preventitive Maintenance
Product Code: 1894T ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The Tradequip 1894T Engine Stand accepts a wide variety of engines and transmissions. The head easily swivels 360º via the 40:1 ratio gear box for convenient accessibility to all parts of the engine. It has fully adjustable mounting arms and heavy duty swivel castors provide excellent manoeuvrability. 2. ASSEMBLY Assemble all parts and check to see you can identify each part Attach Column (2) to Base (1) using Bolt (15), Washer (17) and Nut (16) Secure Support (20) to the Base (1) using Bolt (25), Washer (26) and Nut (27) and Column (2) using Bolt (21), Washer (22) and Nut (23) Mount Gearbox Bracket (11) to Column (2) using Bolt (8), Washer (9) and Nut (10) Attach Gearbox (4) to Gearbox Bracket (11) using Bolt (12), Washer (13) and Nut (14) Mount Turntable (3) through Column (2) and onto the Gearbox (4) using Nut (18) Loosely attach Fingers (1) to Turntable (2) using Bolt (12) and Washer (13) Attach Handle (19) to the Gearbox (4) on the side of the gearbox using Bolt (23), Washer (22) and Flat Washer (21) 3. - Page 5 Product Code: 1894T this manual intact and in a convenient location for all to see and read. If the manual is lost or not legible, contact TQB Brands Pty Ltd for a free replacement. 4. OPERATING THE ENGINE STAND 1. Consult the vehicle or engine manufacturer for the engine’s centre of gravity. The engine’s centre of gravity will have to be aligned with the rotational axis of the engine stand’s mounting head assembly. 2. Remove the clutch bell housing from the engine and secure any other engine parts that might be loose or hanging from the engine. 3. Remove the adjustment knob from the side of the engine stand and extend the “T” base so that it is about 150mm farther than the engine when the engine is mounted to the stand. Fasten the four engine adaptor fingers to the engine using the proper bolt thread size and length. Remember to use grade 5, metric 8.8 bolts or better. Do not tighten the bolts. 4. Align the rotational axis of the mounting plate assembly as close as possible to the engine’s centre of gravity. Tighten the four bolts that secure the engine adaptor arms to the engine and the bolts, flat washers and nuts that connect the other end of the engine adaptor arms to the mounting plate assembly. 5. Attach an engine lifting bar or sling to the engine and raise the engine with a workshop crane or lifting device with a load capacity that can adequately handle the engine weight. Once the engine is lifted to the desired height, slowly push the engine with the mounting plate assembly pointing toward the drive shaft of the engine stand. Insert the stand’s drive shaft into the receiver on the mounting plate. Turn the stand’s gear box handle wheel until the threaded holes in the drive shaft align with the holes in the mounting plate receiver. Once aligned, secure with the bolts and lock washers provided. 6. Make sure the setup is stable and then, slowly and carefully remove the workshop crane or engine lifting device. REMOVING ENGINES 1. Attach an engine lifting bar or sling to the engine. Connect the bar or sling to a workshop crane or lifting device and slowly lift the engine just enough to take pressure off the engine stand. 2. Remove the bolts and lock washers that secure the mounting plate to the stand’s drive shaft. Slide the drive shaft out of the mounting plate receiver and slowly and carefully manoeuvre the engine away from the stand. 3. Unscrew the four bolts that secure the adapter arms to the engine. Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 5...
- Page 6 Product Code: 1894T 5. STORAGE This Engine Stand should always be stored in a dry location on a level surface. 6. MAINTENANCE Replace or repair damaged parts. Use recommended parts only. Non-authorised parts may be dangerous and will invalidate the warranty. Keep the stand clean for best and safest performance. 7. SERVICE & REPAIR Any Engine Stand found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be...
-
Page 7: Parts Diagram
Product Code: 1894T PARTS DIAGRAM Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 7... -
Page 8: Parts List
Product Code: 1894T PARTS LIST Part Description Qty Part Description Qty Base Bolt M14x80 Column Nut M14 Turntable Spring Washer Ø14 Gearbox Nut Finger Handle Washer Support Bracket Bolt M14x60 Bolt M10x90 Bolt M10x25 Spring Washer Ø10 Spring Washer Ø8 Nut M10 Nut M10 Castor Wheel Gearbox Bracket Bolt M10x75 Bolt M8x35 Spring Washer Ø10 Spring Washer Ø8 Nut M10 Nut M8 Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 8... -
Page 9: Warranty
Product Code: 1894T WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
