- Page 1 ARU-200 Radio signal repeater Firmware version 1.00 aru-200_en 09/21 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.eu...
- Page 2 The device meets the technical regulations of the Eurasian Customs Union. Protection class II (protective insulation). SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
- Page 3 CONTENTS Features ........................... 2 Electronics board ......................3 Installation and start-up ....................3 Specifications ........................5...
- Page 4 ARU-200 SATEL The ARU-200 radio signal repeater receives transmissions from wireless ABAX 2 system devices and retransmits them. This manual applies to the repeater supported by the ACU-220 and ACU-280 controllers with firmware version 6.03 (or newer). The repeater does not support the ABAX wireless devices.
- Page 5 SATEL ARU-200 2. Electronics board RS-232 (TTL) port. battery. tamper switch (NC). battery connector. bicolor LED indicator of the repeater status: normal operation – ON in green; communication with the controller – flash in red; 230 VAC power trouble – flashing in green.
- Page 6 ARU-200 SATEL Prior to installation you should plan the arrangement of all ABAX 2 system wireless devices, whose signals are to be retransmitted. Select the place of installation so that the repeater is located within the operating range of the devices and, at the same time, the ABAX 2 controller is located within the operating range of the repeater.
- Page 7 SATEL ARU-200 The ARF-200 tester makes it possible to check the radio signal strength at the place of future installation without having to put the repeater there. 8. Power down the repeater. 9. Remove the cover and disconnect the temporary power supply.
- Page 8 ARU-200 SATEL Standby current consumption .................... 8 mA Maximum current consumption ..................15 mA Battery (lithium-ion) ..................3.7 V / 1800 mAh Environmental class according to EN 50130-5 ................ II Operating temperature range ................-10°C...+55°C Maximum humidity ......................93±3% Electronics board dimensions ................87 x 104 mm Enclosure dimensions .................
