- Page 1 PRO-DPA Installation and Setup Guide with PRO-AS7 Issue: 001...
- Page 2 Copyright 2021 Entrotec Limited. All rights reserved. Installation Specification It is the responsibility of the installer to follow Entrotec’s installation and cable specification as well as ALL relevant wiring regulations. Failure to comply with Entrotec’s installation and cable specification may result in erratic operation of equipment and could invalidate any warranty.
-
Page 3: Table Of Contents
PRO-DPA (Call Point) ....................... 6 Connections ........................7 Factory Default Settings ..................... 8 Provision ........................... 8 Provisioning One Way Systems (without an Entrotec Connect Server)......8 Provisioning Systems with an Entrotec Connect Server ..........13 Configure ........................17 Video and Audio Settings ....................17... -
Page 4: Cable Specification
Cable Specification 1 Cable Specification The cabling system is based on Unshielded Twisted Pair Category 5e (Cat5e) or Category 6 (Cat6). The cable must be annealed pure copper, meeting or exceeding the requirements defined in the standard ANSI/TIA 568 C.2. Failure to comply with this cable specification may result in erratic operation of equipment. - Page 5 Contents 1.1.2 ePRO Door Entry System with Entrotec Connect Server The specification below shows the minimum cable requirements, allow for extra cabling if redundancy is required. Connection Cable Door controller with PSU to 2x Cat5e or Cat6. each Call Point: Lock Relay to locks: 2x 1.5mm²...
-
Page 6: Overview
Overview 2 Overview PRO-DPA (Call Point) 2.1.1 Front View 2.1.2 Back View FIGURE 2-1 FIGURE 2-2 Microphone Tamper Switch Panel Camera Network, Power and Data Connections Call Button Speaker... -
Page 7: Connections
Connections 3 Connections FIGURE 3-1 Connection Cable Type Detail RS485 to Door Controller 1 Pair UTP - RS485A+RS485B (1+2) 1x Cat5e or Cat6 12VDC from Door Controller / 1 Pair UTP - 12v (Red) 2 Pair UTP - 0v (Black) Ethernet to Door Controller 1x Cat5e or Cat6 RJ45 - T568B... -
Page 8: Factory Default Settings
PRO-AS7 during initialisation. 5.1.1 Quick Configuration Connect the PRO-DPA to the PRO-AS7 and power them on. Follow the steps below to initialise the devices and configure a one-way system: Tap One Way on the PRO-AS7 on the first initialisation screen, then tap OK. - Page 9 Provision Enter and confirm the password. The Email address is used for password recovery (default: support@entrotec.co.uk). Tap OK. FIGURE 5-2 iii. A list of the devices connected to the network will be displayed. VTO references to PRO- DPA, Local identifies the apartment station you are operating. Select the VTO in the list by tapping on it, then start the initialisation process by tapping Initialise.
- Page 10 Provision Enter and confirm the password for the PRO-DPA. The Email address is used for password recovery (default: support@entrotec.co.uk). Tap OK. FIGURE 5-4 The PRO-DPA will now show on the list as Initialised. Tap Next. FIGURE 5-5...
- Page 11 Provision Select the PRO-DPA and tap Edit. FIGURE 5-6 vii. Make sure the Call Point is set a Main. Press OK. FIGURE 5-7...
- Page 12 Provision viii. Edit the PRO-AS7. Enter a new IP address and tap OK. FIGURE 5-8 Tap Quick Config. This will apply the new settings to the Call Point and the Apartment Station. FIGURE 5-9...
-
Page 13: Provisioning Systems With An Entrotec Connect Server
Provisioning Systems with an Entrotec Connect Server When an Entrotec Connect Server is installed, calls from a Call Point to an apartment station will be managed by the server. To configure the Call Point for synchronisation with the server, follow the steps in the sections below. - Page 14 Provision Enter a recovery email address (optional) and press Next. FIGURE 5-12 Click Ok. FIGURE 5-13 5.2.2 Login to the Call Point Connect a laptop or PC to the same network as the Call Point. Assign the laptop/PC an IPv4 address from the same range used by the door entry system. iii.
- Page 15 Uncheck Enable; this disables the internal device SIP Server which is on by default. iii. For Sever Type select Entrotec Connect. Enter the Entrotec Connect Server IP Address, Change Port to 5080. Optional - enter the Domain VDP, SIP Server Username and SIP Server Password.
- Page 16 FIGURE 5-17 DEVICE REGISTRATION To register the Call Point and the Apartment Station with the SIP server, please refer to the Entrotec Connect Quick Setup Guide. 5.2.6 Destination SIP ID Navigate to Local Settings > Basic. Enable and set the Block No to match that of the Apartment Station to be called when the Call Button is pressed.
-
Page 17: Configure
Configure 6 Configure Video and Audio Settings Login to the Call Point as described in section 5.2.2. Navigate to Local Settings > Video & Audio. iii. These settings are application specific dependant on the location of the Call Point. FIGURE 6-1 NOTE The maximum resolution is 720P. - Page 18 Configure Navigate to Local Settings > Access Control > RS485. Set the Unlock Response Interval and Unlock Time, for the desired lock release time. vii. Press Save - these settings update the parameters for the remote lock relay in the connected Door Controller.
- Page 19 Notes...
- Page 20 Entrotec Ltd 5 Ashwood Court Oakbank Livingston EH53 0TL Telephone: 01506 886 230 Support: 01506 886 235 www.entrotec.com...
