- Page 1 PRO-DC1/2 Installation and Setup Guide Issue: 002...
- Page 2 Copyright 2021 Entrotec Limited. All rights reserved. Installation Specification It is the responsibility of the installer to follow Entrotec’s installation and cable specification as well as ALL relevant wiring regulations. Failure to comply with Entrotec’s installation and cable specification may result in erratic operation of equipment and could invalidate any warranty.
-
Page 3: Table Of Contents
Contents Contents Cable Specification ......................4 Typical Configuration ...................... 4 Overview ........................... 5 Power Supply ........................6 Mains Supply Connections ....................6 Secure Lock Relay ......................7 Input + Exit Switch Connections ..................7 Fail Open Lock Connection ..................... 7 Fail Closed Lock Connection ................... -
Page 4: Cable Specification
Cable Specification 1 Cable Specification The cabling system is based on Unshielded Twisted Pair Category 5e (Cat5e) or Category 6 (Cat6). The cable must be annealed pure copper, meeting or exceeding the requirements defined in the standard ANSI/TIA 568 C.2. Failure to comply with this cable specification may result in erratic operation of equipment. -
Page 5: Overview
Overview 2 Overview FIGURE 2-1 Item Connection Detail Power Supply Unit (PSU) Section 3 - Page 6 Secure Lock Relay Section 4 - Page 7 Secure Lock Relay (PRO-DC2 only) Call Panel Splitter Section 5 - Page 8 Network Switch Section 6 - Page 8... -
Page 6: Power Supply
Power Supply 3 Power Supply Fused Terminal Block Earth Point Pre-Wired 12V to Internal Devices Backup Battery Connections for Sealed Lead Acid Battery Output Voltage Adjustment SYSTEM VOLTAGE 13.8VDC Always test the output voltage. Only adjust if required. FIGURE 3-1 Mains Supply Connections Fuse Holder Mains Supply Cable from... -
Page 7: Secure Lock Relay
Lock Relay FIGURE 4-4 - 1N4007 DIODE FITTED AT LOCK Entrotec recommend locks with built in suppression. If such a lock is not being used it is ESSENTIAL to fit suitable suppression, as close to the lock as possible. This prevents back EMF and spikes from damaging equipment and causing erratic operation. -
Page 8: Call Panel Splitter
Call Panel Splitter 5 Call Panel Splitter 12VDC Connections to Call Panel 12v, 0v RS485 Data to Call Panel FS1-FS4 - Call Panel Supply Fuses (1.25 Amp Fast Acting) PL5 - Not Used PL1-PL4 - Call Panel Connection Plugs FIGURE 5-1 6 Call Panel Connections FIGURE 6-1 Connection... -
Page 9: Pairing Secure Lock Relay With Call Panel
Pairing Secure Lock Relay with Call Panel 7 Pairing Secure Lock Relay with Call Panel Confirm Door No. of Call Panel Connect a laptop or PC to the same network as the Call Panel. Use a web browser and enter the IP address of the Call Panel in to the address bar. iii. -
Page 10: Device List
Device List 8 Device List IP Address Block ID SIP ID Type Description 192.168.1.111 8001 Call Panel Ashwood Court, Front Door... - Page 11 Notes...
- Page 12 Entrotec Ltd 5 Ashwood Court Oakbank Livingston EH53 0TL Telephone: 01506 886 230 Support: 01506 886 235 www.entrotec.com...
