Wooden Chair Pair
Assembly Instructions
We care about your comments. Please call us!
1-800-284-3948
www.MelissaAndDoug.com
c
2013 Melissa & Doug, LLC, P.O. Box 590, Westport, CT 06881
WARNING:
!
!
CAUTION:
Holds up to 150 lbs
CHOKING HAZARD -
Small parts.
Adult assembly required.
Not for children under 3 years.
ITEM #8789
Advertisement
Table of Contents
Related Manuals for Melissa & Doug 8789
Summary of Contents for Melissa & Doug 8789
- Page 1 We care about your comments. Please call us! 1-800-284-3948 www.MelissaAndDoug.com 2013 Melissa & Doug, LLC, P.O. Box 590, Westport, CT 06881 WARNING: CAUTION: Holds up to 150 lbs CHOKING HAZARD - Small parts. Adult assembly required. Not for children under 3 years. ITEM #8789...
- Page 2 Wooden Chair Pair PARTS Parts on this page can assemble 2 complete chairs. Short Screw x20 Long Screw x8...
- Page 3 Wooden Chair Pair STEP 1 Parts Needed: First Side Frame (C) Back Slats (D,E,F,G) CHAIRS 3 Short Screws Arrange Back Slats (D,E,F,G) to the right of First Side Frame (C) as shown below. Attach the slats to the frame using Short Screws as needed.
- Page 4 Wooden Chair Pair STEP 2 Parts Needed: Second Side Frame (H) 3 Short Screws CHAIRS Attach Second Side Frame (H) using 3 Short Screws. (Make sure the dowels align with the holes on the frame.) Set aside until final assembly in Step 5. Finished Assembly...
- Page 5 Wooden Chair Pair STEP 3 Parts Needed: Seat (I) Front Leg Assembly (J) CHAIRS 2 Short Screws With the Seat (I) in the position shown below, fit the Front Leg Assembly (J) to the seat. Insert 2 Short Screws and tighten. Finished Assembly...
- Page 6 Wooden Chair Pair STEP 4 Parts Needed: Side Struts (K,L) 2 Short Screws CHAIRS Assemble the Side Struts (K) and (L) as shown here with 2 Short Screws. Finished Assembly...
- Page 7 Wooden Chair Pair STEP 5 Parts Needed: 4 Long Screws CHAIRS Attach the completed Back (from Step 2) to the Seat Bottom using 4 Long Screws. Repeat Steps 1 through 5 to complete the second chair. Finished Assembly...
