Bard CMA-43 Supplemental Instructions

SUPPLEMENTAL INSTRUCTIONS
CMA-43 Outdoor Thermostat Kit (A/C)
The CMA-43 is a field-installable outdoor thermostat
suitable for use as a compressor cutoff thermostat. This
thermostat stops the compressor operation below the
selected temperature (ºF). The thermostat is adjustable
from 0ºF to 50ºF. Default setting is 10ºF.
The CMA-43 kit is for use with Bard models W42AC,
W48AC, W60AC and W72AC air conditioners.
The CMA-43 kit consists of:
• 7960-858 Supplemental Instructions
• 910-2110 Outdoor Thermostat
• 7950-020 Vinyl Covered Clamp (2)
• 1012-065 Phillips Head Screws (2)
• 1012-085 Hex Head Screws (3)
• 7961-312-0515 CMA-43 Unit I.D. Label
Field-supplied tools needed:
• Appropriate personal protection equipment,
including gloves and safety glasses
• 5/16" nut driver
• Phillips head screwdriver
• Small flat head screwdriver for securing wire in
terminal blocks
• Multimeter for troubleshooting
Bard Manufacturing Company, Inc.
Bryan, Ohio 43506
www.bardhvac.com
WARNING
!
Electrical shock hazard.
Disconnect the remote electric power
supply or supplies before servicing.
Failure to do so can result in serious injury
or death.
WARNING
!
Exposed moving parts.
Disconnect all electrical power before
servicing.
Failure to do so can result in severe injury
or amputation.
CAUTION
!
Sharp metallic edges.
Take care and wear appropriate protective
devices to avoid accidental contact with
sharp edges.
Failure to do so can result in personal
injury.
Manual:
Supersedes: NEW
Date:
7960-858
9-24-19
Page 1 of 3
