TE31/TE32 Series
Induction Motor Speed Controller
User's Mannual
Wire connection Panel, Easy wiring, Easy Controlling
Slow Start(SS) Slow Down(SD) Instantaneous Brake
Internal and external speed control
DIN rail installation of European standard
Scan to view online
1
Advertisement
Related Manuals for Troy-Bilt TE31 Series
Summary of Contents for Troy-Bilt TE31 Series
- Page 1 TE31/TE32 Series Induction Motor Speed Controller User’s Mannual Scan to view online Wire connection Panel, Easy wiring, Easy Controlling Slow Start(SS) Slow Down(SD) Instantaneous Brake Internal and external speed control DIN rail installation of European standard...
- Page 2 Specs Type TE31 TE32 Power Input (V) Single phase AC100-115 Single phase AC200-230 Power frequency (Hz) Current (A) Motor power Max. <90W Range of speed controlling 70~1400 70~1700 70~1400 70~1700 Functions Temperature environment 0 +40°C Humidity environment Max. <85% 104(L ) 65 (W) 44 (H ) Dimension (mm) 160g Weight...
- Page 3 It may cause electric shock, trouble, Do not stand/sit on product or put heavy article on it. damage Ensure that wiring has been correctly done. Prevent injury trouble, damage Please dealing according to industry littering as discarding the product. ATTENTION May cause injury or product damage.
- Page 4 Dimension 4.25 POWER SPEED1 SPEED2 INT-VR STOP SPEED CONTROLLER BRAKE EXT-VR WARNING Risk of injury and electric shock. Read the manual and follow the safety Instructions before use. Wait to touch an electronic device for 1 minute after disconnecting power supply. Ensure proper earth connection.
- Page 5 35mm Using DIN rail in 35mm size Using two screws (M4 : No attachment, Min> 15mm) fastening to installing hole of two sides of controller...
-
Page 6: Sequence Diagram
Sequence diagram Below is diagram for switching two speed. Setting high speed internally, and low speed externally. SLOW START SLOW DOWN RUN BRAKE Low speed CW(Clockwise) Motor Operation (Counterclockwise) Low speed Power O F F RUN/STOP STOP STOP O F F BRAKE BRAKE RUN/BRAKE... -
Page 7: Function Instruction
Function Instruction Example of Instruction Instruction Instruction Slow Start/Slow Down Internal Speed control Speed range: It will have effect on start time It will have effect on stop time 60Hz - 90~1700r/min (unload)and two parts of speed (unload)and two parts of speed No Slow Start/Slow Down 50Hz - 90~1400r/min control(low to high speed) - Page 8 POWER SPEED1 SPEED2 INT-VR STOP SPEED CONTROLLER BRAKE EXT-VR E F G H I J K L M Terminal Instruction Link to Generator wire(blue) Link to Motor(clockwise) Frame ground Y W B SW1 SWITCH type AC250V 10A Link to Motor(counterclockwise) POWER Capacitance W Y B...
- Page 9 Wiring for control Speed Control - External Speed Control - Internal (Variable Resistance) One Part Speed Control Two Parts Speed Control Two Parts Speed Control One Part Speed Control (SW3) BRAKE BRAKE BRAKE BRAKE (SW2) STOP STOP STOP STOP POWER SPEED1 POWER SPEED1...
- Page 10 Rotating Direction - Rotating Direction - One direction Counterclockwise/Clockwise Switching Below wiring example is clockwise. Black Black Yellow Yellow White Blue White Blue Blue Blue Capacitance POWER Capacitance POWER Power Filter Fuse Power Filter Fuse...
- Page 11 Important Notice Don’t control RUN/STOP by power switch(SW1) immediately but using SW2. Avoid powering on and rotating at the same time. Two parts speed switching will be affected by SS and SD. It can rotate oppositely in a flash with Reversible Motor as 6R 8R 9R series. It must be stopped before changing the rotating direction with Induction Motor as 6I 8I 9I series.
