Models
Descriptions
ENS 100V
Electric Needle Scaler, 110V-1ph
ENS 200V
Electric Needle Scaler, 220V-1ph
Read this manual carefully before installing, operating or servicing this equipment. It's the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
This document is issued with Product Serial No
Operation and Maintenance Guide
ENS 100V / ENS 200V
IMPA Code
59 12 01
59 12 03
Advertisement
Table of Contents
Related Manuals for Teryair ENS 100V
Summary of Contents for Teryair ENS 100V
- Page 1 Operation and Maintenance Guide ENS 100V / ENS 200V Models Descriptions IMPA Code ENS 100V Electric Needle Scaler, 110V-1ph 59 12 01 ENS 200V Electric Needle Scaler, 220V-1ph 59 12 03 Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi- bility of the employer to ensure this manual is read by the operator.
-
Page 2: Table Of Contents
Page 2 Table of Contents Introduction Technical Data Safety Instructions Operating Instructions Diassembly and Re-assembly for ENS 100V & ENS 200V Bill of Materials for ENS 100V & ENS 200V Exploded View for ENS 100V & ENS 200V Test Certificate Of Materials, Performance 11 Eu Declaration Of Conformity 12... -
Page 3: Introduction
Page 3 Introduction Teryair Electric Needle Guns are rugged tools. Designed to be easy to use and maintain. they are ideal for removing layers of paint, corrosion and chemical coatings from surfaces. Rotating handle can be fixed at any position to make operation easier. -
Page 4: Operating Instructions
Caution flying debris such as flakes of the removed layer. Use only genuine Teryair or Teryair approved accessories. Warning Suitable gloves must be worn at all times during operation. Safety Shoes with toe cap Warning protection are a must during operation. - Page 5 Operation and Maintenance Guide Electric Needle Scalers Page 5 • Now remove the two screws as shown to remove the rear cover of female plug to see the terminals. • Insert the cable from the back of the cover through the holder and terminate the respective wire.
-
Page 6: Diassembly And Re-Assembly For Ens 100V & Ens 200V
Page 6 Diassembly and Re-assembly for ENS 100V & ENS 200V Disconnect the plug & switch off power supply from the source. Needle Replacement • First remove the Lock (14). • Now rotate the front cover (4) counter clockwise. •... - Page 7 Operation and Maintenance Guide Electric Needle Scalers Page 7 Carbon Brush Replacement • Remove the screws (26) from the bottom to disassemble the cover(25). • Now remove the cap (22) and pull the carbon brush (21). • Replace with new one and assemble in a reverse manner.
-
Page 8: Bill Of Materials For Ens 100V & Ens 200V
Page 8 Bill of Materials for ENS 100V & ENS 200V Illustration Part Number Description ENS 100V ENS 200V Number 655 91 01 MAIN HOUSING-100V 655 91 02 MAIN HOUSING-200V 655 21 01 ANVIL 655 21 02 STRIKER 655 21 03... -
Page 9: Exploded View For Ens 100V & Ens 200V
Operation and Maintenance Guide Electric Needle Scalers Page 9 Exploded View for ENS 100V & ENS 200V FF-MM-319-REV - 02... -
Page 10: Test Certificate Of Materials, Performance
Page 10 TEST CERTIFICATE OF MATERIALS, PERFORMANCE Date : Model number : Part description & s.No. : We hereby certify that the above referenced product has tested and inspected in accordance with our standard test proce- dures and meets the specifications for material and performance values as published in our literature. We further certify that the product has been given our standard factory test and meets all quality and performance standards established by the company.This product is certified to be produced in our factory, and is of current production. -
Page 11: Eu Declaration Of Conformity
Palghar – 401208, Maharashtra, India. CE certification registration no – C E 16831 Issued by – BMQR Certifications Pvt Ltd. www.cemarking-india.com Valid Till – 03/11/2021 Signed for and on behalf of TERYAIR EQUIPMENT PVT. LTD. Place of Issue: Date: FF-MM-319-REV - 02... -
Page 12: Warranty Certificate
Teryair; (vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any design, specification or other specific requirement of Dealer/End User;... - Page 13 Operation and Maintenance Guide Electric Needle Scalers Page 13 This page is intentionally Left blank. FF-MM-319-REV - 02...
