Assemble Nipple in the control body (20) (supplied separately). MAINTENANCE: To disassemble SN29PG Needle Scaler- Disconnect air supply and loosen socket head bolt(18) on the front tube(06) and slide out front tube(06) from intermediate tube(07). Unscrew socket head bolt(18) on intermediate tube(07) and unscrew it and remove.
Page 3
Needle Scaler SN29PG Exploded View FF - MM - 123 REV - 2 Sheet 3 of 5...
Page 4
100 21 22 Needle Holder (ø 2mm)(Optional) 100 21 23 Needle Holder (ø 4mm)(Optional) 100 40 18 Plastic Plug Note : Always use genuine TERYAIR spares part for best performance. Sheet 4 of 5 FF - MM - 123 REV - 2...
Needle Scaler SN29PG Operation & Maintenance Guide INTENDED USE Needle scalers are used for surface preparation work involving the cleaning or removal of paint, rust, dirt, or weld slag from metal & non - metal surfaces. These tools also work well on irregular surfaces such as crevices &...
