Rear side
1
Remove
10
WIRELESS KIT
port label
# Description
1 Power socket
2 HDMI connector
5V DC output connector (firmware
3
upgrade functions)
4 PC analog signal/HDTV/component
video input connector
5 Kensington™ lock port
Note 1: Functions vary depending on model definition.
Note 2: wifi dongle no support hot plug
6 7
2 3 4 5
#
6
7
8
9
10
8 9
Description
RS232 connector
S/PDIF connector
Audio in connector
Audio out connector
USB connector (for wifi dongle)
