Summary of Contents for SPAccessories Cover Classic Lifter
- Page 1 Cover Classic Installation & Use Manual SPAccessories, LLC. Youtube Video: SPAccessories Cover Classic https://www.youtube.com/ watch?v=n7j1jv7XM7A WWW.888SPALIFT.COM • 1-888-SPA-LIFT (772-5438) WWW.888SPALIFT.COM • 1-888-SPA-LIFT (772-5438)
- Page 2 99” in width. When assembled it forms a rectangular shape. The Cover Classic Lifter attaches to the back of the spa cabinet, either on the back wall of the cabinet or on the pedestal base. The Bridge Arms (B) lies across the spa cover parallel to the seam (hinge) of the cover and is “captured”...
- Page 3 Parts List ref # description Corner Piece Bridge Arm Mounting Block Retaining Chain Chain Bracket Metal Screw #10 x ” Wood Screw #8 x ” Wood Screw #8 x 1¼” Towel Holder Screw End Caps...
- Page 4 Cover Classic Installation & Use 1. Lay out the components in the shape of a rectangle as shown below (Fig A). There are 4 Corner Pieces (A). They have been drilled so that the holes on the top and bottom of the corner pieces are facing at a 45 degree angle on the pole when laying flat on the ground.
- Page 5 Figure B 1.5” clearance between spa and inBridge Arm of Classic Cover Lifter Mounting Blocks Figure B 5. Next connect these two assembled pieces together with the last two Bridge Arms (B) by sliding the Arms into each of the four Corner Pieces as shown in Fig.
- Page 6 Figure D Classic Lifter tubing. Screw in one #10 x ” selfdrilling metal screw just to the outside of each Mounting Block to lock Cover Classic Lifter into this position and prevent it from moving side to side. See Figure B.
- Page 7 FREE of charge, FREIGHT PAID. FIVe YeArS - Limited SPAccessories™ is confident in the quality of our products and dealers. If a SPAccessories™ Authorized Dealer can validate and/or verify that a component failure was the direct result of an unusual FACTORY DEFECT, SPAccessories™...
- Page 8 ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ ______________________________________________________________ SPAccessories, LLC. 11900 N. La Canada Dr. #69792 Tucson, AZ 85737 www.888SPALIFT.com...
