TCL MS82B Series Service Manual page 42

T8-32B3310-FC1 T8-32B3310-FC1Z
T8-32B3310-FC1Z 55-464690-0HX9A
T8-32B3310-FC1Z 56-959000-0HQ6Q
T8-32B3310-FC1Z 56-956280-0HH21
T8-32B3310-FC1 89-604792-JZW
T8-32B3310-FC1 89-604792-JZW
T8-32B3310-LPM1 71-W32CST-LED9C
T8-32B3310-LPM1 T8-32C727V-IR1
T8-32C727V-IR1 02-IRR002-X12T
T8-32C727V-IR1 12-BT3904-0BX
T8-32C727V-IR1 14-LED03R-XX1
T8-32C727V-IR1 19-AB0101-JTX
T8-32C727V-IR1 19-AB0101-JTX
T8-32C727V-IR1 19-AB0122-JTX
T8-32C727V-IR1 19-AB0152-JTX
T8-32C727V-IR1 28-AB0104-ZFX
T8-32C727V-IR1 28-AB0101-JCX
T8-32C727V-IR1 28-AC0105-ZFX
T8-32C727V-IR1 28-AC0105-ZFX
T8-32C727V-IR1 46-GHSR01-05SG
T8-32C727V-IR1 40-42C720-IRD2LG PCB IR 125*180MM 22PC DOUBLESIDED 1.6MM
T8-32B3310-LPM1 63-B30060-BF4G
T8-32B3310-LPM1 46-FM060L-05P01G WIRE KEY LINE 600MM 4 A2008 A2008 2.0MM
T8-32B3310-LPM1 T8-CS32TTL-LC7
T8-CS32TTL-LC7 T8-32F3380-MC1
T8-32F3380-MC1 59-935430-000
T8-32F3380-MC1 59-935440-000
T8-32F3380-MC1 59-935450-000
T8-32F3380-MC1 67-M93409-0E0
T8-32F3380-MC1 62-725190-3UF
T8-32F3380-MC1 62-725210-3UF
T8-32F3380-MC1 62-725220-3UF
T8-32F3380-MC1 62-725200-3UF
T8-CS32TTL-LC7 T8-32LEDEM-BL8
T8-32LEDEM-BL8 62-725470-0UK
T8-32LEDEM-BL8 63-B30060-BF4G
T8-32LEDEM-BL8 89-BX8915-JZ0U
T8-32LEDEM-BL8 59-946020-000
T8-32LEDEM-BL8 4C-PF320T-JF6
T8-32LEDEM-BL8 4C-PF320T-SH5
T8-32LEDEM-BL8 4C-RF320T-TX2
T8-32LEDEM-BL8 4C-LB320T-YH1
T8-32LEDEM-BL8 46-ZZ091T-10PG
T8-32LEDEM-BL8 T8-32LEDEM-BL8Z
T8-32LEDEM-BL8Z 55-464710-0KL6R
T8-32LEDEM-BL8 67-725170-4G0
ASS'Y - FRONT CABINET ART
DEC FRONTPANEL D10 01 8G 00 R=N
DEC KEY L32D12 -- 01 6M 00 R=N
DEC KEY CLUSTER 29M76S -- 01 6M 00 R=N
SUNDRIES-FILM SELF ADHESIVE FILM
SUNDRIES-FILM SELF ADHESIVE FILM
PRI LABEL -- --- R=Y
ASS'Y - IR BD
IR RECEIVER 37.9KHZ 5V HM238
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
LED RED Φ 3MM FO203
RES SMD 100 OHM 1/10W 0603
RES SMD 100 OHM 1/10W 0603
SMD. RES 1.2K OHM 1/10W +/-5% 0603
R-SMD 1K5OHM 5% 1/10W 0603 -
CAP.CER,SMD 100N0F 50V DCV 0603 -
CAP.CER,SMD 100PF 50.0V 0603 -
SMD. CAP 1 UF 16VDC +80%/-20%
SMD. CAP 1 UF 16VDC +80%/-20%
CONN SMT 5 1.25MM FEMALE W ST
SCREW
LVW320CSTT E3--32B3310 TOT背光 搭配华星
ASS'Y - MIDDLE CABINET
RAW BUFFER 32E5300 0 0 R=Y
RAW BUFFER 32E5300 0 0 R=Y
RAW BUFFER 32E5300 0 0 R=Y
TV RAW SPRING CLUTCH R=Y
RAW SUPPORT CRT 32F3300B -- 3UF JIAOKUAN
RAW SUPPORT CRT 32F3300B -- 3UF JIAOKUAN
RAW SUPPORT CRT 32F3300B -- 3UF JIAOKUAN
RAW SUPPORT CRT 32F3300B -- 3UF JIAOKUAN
L32F3380 B/L PARTS
RAW SUPPORT CRT 32F3300B -- 0UK 00 00 R=
SCREW
SUNDRIES-TAPE ADHESIVE 18MMX55M --
RAW BUFFER SOURCE BOARD 0 0 R=Y
FILM PRISM 32INCH 0.225MM 704MM 402MM R=
FILM PRISM 32INCH 0.225MM 704MM 402MM R=
FILM REFLECTOR 32INCH 0.215MM 725.6MM 42
LIGHTBAR SIDE IN 32INCH 25W 27LEDS R=Y
WIRE LED DRIVER CONVERTER CABLE 910,670,
L32F3380 B/L ART PARTS
DEC BACKCOVER 32E330_S_RC -- 00 00 00 R=
RAW SHIELDING CRT 32F3300B HEATSINK SHEE
STICK ON F.CAB R/L
SIDES
STICK ON F.CAB TOP
IR1
Q1
D1
R1
R2
R3
R4
C3
C2
C4
C1
P1
MTG IR BD
FOR IR.BD P1 TO
M.BD P203A
STICK ON GLUE
FRAME.UP/DOWN
STICK ON GLUE
FRAME.R/L
STICK ON GLUE FRAME
CORNER
MTG GLUE
FRAME&F.CAB
FIX ON HEATSINK
BOARD
MTG LIGHT
BAR,HEATSINK
BOARD,BACKBOARD
FIX FOR WIRES
MTG SOURCE BD
FOR LIGHT BAR TO
POWER CN201
