Bom - TCL MS82B Series Service Manual

H7-HB331N7V-EG0
LED32B3310/MS82D-AP/CS1/TT E3 V3
parent child
H7-HB331N7V-EG0 T6-520W37-BAJ0X
T6-520W37-BAJ0X 06-520W37-B000X
H7-HB331N7V-EG0 81-PBE032-PW2
H7-HB331N7V-EG0 T8-32AP7V-MA8
T8-32AP7V-MA8 09-00SR34-STX
T8-32AP7V-MA8 09-0BAV99-ATX
T8-32AP7V-MA8 09-LL4148-ATX
T8-32AP7V-MA8 09-LL4148-ATX
T8-32AP7V-MA8 09-LL4148-ATX
T8-32AP7V-MA8 09-LL4148-ATX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3904-0BX
T8-32AP7V-MA8 12-BT3906-0BX
T8-32AP7V-MA8 12-BT3906-0BX
T8-32AP7V-MA8 12-BT3906-0BX
T8-32AP7V-MA8 12-C124ET-0BX
T8-32AP7V-MA8 12-MV65XP-0BX
T8-32AP7V-MA8 13-AP2111-25B
T8-32AP7V-MA8 13-AS1117-18B
T8-32AP7V-MA8 13-DC1582-ENB33
T8-32AP7V-MA8 13-MP1494-DJB
T8-32AP7V-MA8 13-MP1494-DJB
T8-32AP7V-MA8 13-MP1494-DJB
T8-32AP7V-MA8 13-MST6M1-82BVG
T8-32AP7V-MA8 13-SH9010-LFB
T8-32AP7V-MA8 19-AB0000-FTX
T8-32AP7V-MA8 19-AB0000-JTX
T8-32AP7V-MA8 19-AB0000-JTX
T8-32AP7V-MA8 19-AB0000-JTX
T8-32AP7V-MA8 19-AB0000-JTX
T8-32AP7V-MA8 19-AB0000-JTX
T8-32AP7V-MA8 19-AB0100-JTX
T8-32AP7V-MA8 19-AB0100-JTX
T8-32AP7V-MA8 19-AB0100-JTX
T8-32AP7V-MA8 19-AB0100-JTX
T8-32AP7V-MA8 19-AB0101-JTX
T8-32AP7V-MA8 19-AB0101-JTX
T8-32AP7V-MA8 19-AB0102-JTX
T8-32AP7V-MA8 19-AB0102-JTX
T8-32AP7V-MA8 19-AB0102-JTX
T8-32AP7V-MA8 19-AB0103-JTX
T8-32AP7V-MA8 19-AB0103-JTX
T8-32AP7V-MA8 19-AB0103-JTX
T8-32AP7V-MA8 19-AB0103-JTX
T8-32AP7V-MA8 19-AB0103-JTX
T8-32AP7V-MA8 19-AB0103-JTX
description
REMOTE FOR JAC
RCT OR BLACK 3.0V 300MA 3UA 0
PSU 54W SHG3203A-101H
ASS'Y - MAIN BD
D-BR,SMD 40V 3A 0.5V DO-214AA SR34
D,SMD 70.0V 200MI0_A 855MI0V 4N 0.25W SO
SMD. SWITCHING DIODE LL4148
SMD. SWITCHING DIODE LL4148
SMD. SWITCHING DIODE LL4148
SMD. SWITCHING DIODE LL4148
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2
TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S
TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S
TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S
TR-SMD NPN 50VV 100MA_A 80HZ 0.25W SOT23
MOSFET-SMD P 20V 3.9A 1.92W SOT23 PMV65X
IC LDO AP2111-2.5
ICSOT-223 AS1117-18CX
IC DC-DC STEP-DOWN CONVERTER MP1582
IC DC-DC CONTROL MP1494DJ
IC DC-DC CONTROL MP1494DJ
IC DC-DC CONTROL MP1494DJ
IC A SINGLE CHIP SUPORT MULTIMEDIA TV SO
IC CLASS D MSH9010-LF
SMD.RES 0 OHM 1/10W +/-1% 0603
RES SMD 0 OHM 1/10W +/-5% 0603
RES SMD 0 OHM 1/10W +/-5% 0603
RES SMD 0 OHM 1/10W +/-5% 0603
RES SMD 0 OHM 1/10W +/-5% 0603
RES SMD 0 OHM 1/10W +/-5% 0603
RES SMD 10 OHM 1/10W +/-5%
RES SMD 10 OHM 1/10W +/-5%
RES SMD 10 OHM 1/10W +/-5%
RES SMD 10 OHM 1/10W +/-5%
RES SMD 100 OHM 1/10W 0603
RES SMD 100 OHM 1/10W 0603
RES SMD 1K OHM 1/10W 0603
RES SMD 1K OHM 1/10W 0603
RES SMD 1K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
RES SMD 10K OHM 1/10W 0603
BOM text
D806
D100
D811
D604
D602
D600
Q808
Q702
Q604
Q601
Q501
Q603
Q806
Q701
Q602
Q101
Q210
Q813
U801
U803
U800
U806
U805
U807
U101
U600
R518
R856
R169
R858
R854
R633
R670
R671
R672
R673
R868
R631
R772
R849
R851
R641
R665
R632
R637
R658
R650
