SURE SHOT
PORTABLE COURT SYSTEM
MODEL 514
ASSEMBLY INSTRUCTIONS
YOUR BEST SHOT !
FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE
ASSEMBLY COULD RESULT IN SERIOUS INJURY !!!
BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS
COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE
INCLUDED USING THE PARTS LIST PROVIDED.
WARNING !!!
TO PREVENT THE PORTABLE COURT
SYSTEM FROM TIPPING. DO NOT ATTEMPT
TO STAND THE UNIT UP WITHOUT FIRST
FILLING THE BASE WITH SAND.
THE UNIT COULD FALL OVER WITHOUT SAND
IN THE BASE THIS COULD CAUSE DAMAGE
OR INJURY
DO NOT ALLOW CHILDREN TO ADJUST.
CLIMB ON OR HANG FROM ANY PART
OF UNIT.
DO NOT PERFORM SLAM - DUNK PLAY
ON THIS UNIT
THE PORTABLE UNITS ARE NOT DESIGNED
FOR THIS TYPE OF EXTREME USE.
DO NOT USE THE UNIT DURING WINDY
CONDITIONS
Advertisement
Related Manuals for SureShot 514
Summary of Contents for SureShot 514
- Page 1 SURE SHOT PORTABLE COURT SYSTEM MODEL 514 ASSEMBLY INSTRUCTIONS YOUR BEST SHOT ! FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE ASSEMBLY COULD RESULT IN SERIOUS INJURY !!! BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE INCLUDED USING THE PARTS LIST PROVIDED.
-
