- Page 1 HOT SHOT ASSEMBLY INSTRUCTIONS WARNING !!! YOUR BEST SHOT ! To be assembled and dismantled by an adult must always be used in presence of an adult do not leave in the open in windy conditions.
- Page 2 PART LIST P3 - Net white - 12 Loops P1- Size 90x59x1.5Cms P2 - Size 45Cmsx45Cmsx0.9mm 1 Nos. 1Nos. 1Nos. P4 - Size 100Cmsx35mmx35mm - 1Nos. P5 - Size 100Cmsx31mmx31mm - 1Nos. P7 - Size 71x41x8Cms 1Nos. P6 - Size 100Cmsx27mmx27mm - 1Nos. P8 - Size 730x20x3mm - 2Nos.
- Page 3 STEP -1 STEP -2 Attach spring loaded pole (P4) with base (P7) and tighten the tightening screw attached with base. Fill the Blast (P7) with sand or water STEP -3 Attach support steel strip (P8) with base (P7) using nut and bolt (P10) and the same time attach upper part with pole (P4) using nut &...
- Page 4 STEP -5 Attach support strip (P9) with basketball board (P1) using nut & bolt (P12) and tighten it with the help of spanner (P14). STEP -6 STEP -7 Attach net (P3) loops with ring (P2) Attach ring (P2) and board (P1) with pole (P6) and support strip (P9) using nut &...
