SURE SHOT
PORTABLE COURT SYSTEM
MODEL 510
ASSEMBLY INSTRUCTIONS
YOUR BEST SHOT !
FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE
ASSEMBLY COULD RESULT IN SERIOUS INJURY !!!
BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS
COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE
INCLUDED USING THE PARTS LIST PROVIDED.
WARNING !!!
TO PREVENT THE PORTABLE COURT
SYSTEM FROM TIPPING. DO NOT ATTEMPT
TO STAND THE UNIT UP WITHOUT FIRST
FILLING THE BASE WITH SAND.
THE UNIT COULD FALL OVER WITHOUT SAND
IN THE BASE THIS COULD CAUSE DAMAGE
OR INJURY
DO NOT ALLOW CHILDREN TO ADJUST.
CLIMB ON OR HANG FROM ANY PART
OF UNIT.
DO NOT PERFORM SLAM - DUNK PLAY
ON THIS UNIT
THE PORTABLE UNITS ARE NOT DESIGNED
FOR THIS TYPE OF EXTREME USE.
DO NOT USE THE UNIT DURING WINDY
CONDITIONS
Advertisement
Table of Contents
Related Manuals for SureShot 510
Summary of Contents for SureShot 510
- Page 1 SURE SHOT PORTABLE COURT SYSTEM MODEL 510 ASSEMBLY INSTRUCTIONS YOUR BEST SHOT ! FAILURE TO READ INSTRUCTIONS COMPLETELY BEFORE ASSEMBLY COULD RESULT IN SERIOUS INJURY !!! BEFORE BEGINNING ASSEMBLY READ INSTRUCTIONS COMPLETELY AND CHECK TO SEE IF ALL PARTS WERE INCLUDED USING THE PARTS LIST PROVIDED.
- Page 2 PART LIST Angle Bracket 38×33×4mm 45×8mm 25×8mm 38×8mm 8mm U-Bolt Plastic Cap for nut 110×8mm Qty. 8 Nos. Pipe Top Cap Steel Strip Ground Anchor Ground Anchor Sleeve Steel Strip with one hole 125×8mm with two holes 45×35mm 45×35mm Qty.- 4 Nos. Qty.
- Page 3 POLE INSTRUCTIONS BE SURE TO CORRECTLY IDENTIFY THE POLE SECTIONS BEFORE BEGINNING ASSEMBLY TOP POLE SECTION MID POLE SECTION BOTTOM POLE THREE ROUND HOLES AT THE BOTTOM AND TWO ROUND HOLE AT THE MID POINT Page-3...
- Page 4 Required Material and Tools 1. 8×25kg sand bags 4. 13mm Wrench/socket 2. Adjustable wrench 5. Large screwdriver 3. Hammer 6. 2 block wood approx. 10×10×3cm NOTE : Bolt kit check list is included in the bolt kit. Be sure to check contents prior to assembly.
- Page 5 BEFORE CONTINUING ASSEMBLY Backboard and goal should be assembled at ground level. Assembly at top of pole could result in injury. STEP-5 Insert bolt (C) through top holes of back board to attach angle bracket (P9) at the back side of the back board. STEP-6 Insert 8mm U-bolt (E) through (P8) and back board.
- Page 6 STEP-9 Bring down the pole to insert U-bolt (E) with top pole and tighten the nut with the help of spanner of the U-bolt attached with ring. STEP-10 Attach support strip (P5) with lower pole attached to (P1) using nut & bolt (D) and tighten it with the help of spanner. STEP-11 FOR ADDITIONAL STABILITY Locate the unit at desired playing location.
- Page 7 Use the large loops of the net install onto the ring "no-ties" Cover the top pole with plastic cap (G ) cover all the nuts with plastic cap (F) before pole is in playing potion Page-7...
- Page 8 POLE MAINTENANCE Periodically wipe down pole with a damp cloth to remove dirt, pesticides, herbicides, etc. This routing will prolong the life of your pole. If your pole becomes scratched and rust begins to appear, repair by using rust proof gloss black paint ( follow instructions on paint can). THANK YOU FOR BUYING SURE SHOT !!! Page-8...
