THULI TABLES
300 Elevation Owner's Manual
Shown with Metal Base

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2
Identification of Parts / Motor . . . . . . . . 3 - 4
Table Assembly . . . . . . . . . . . . . . . . . . . . . . 5
Table Operation . . . . . . . . . . . . . . . . . . 11 - 12
office@ thulita b les.co m
youtube.com/thulit ab les
facebook.com/thu litab les
Accessories . . . . . . . . . . . . . . . . . . . . . . . 13
Care & Maintenance . . . . . . . . . . . . . . 14 -15
Motor Troubleshooting . . . . . . . . . . . . . . . 16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Overview of Products . . . . . . . . . . . . . Back
800-458-4854
www.thulitables.com
Crescent Arm Rest
(optional)
