Summary of Contents for AquaTerra Montecito

  • Page 1 OWNER’S MANUAL 110V / 230V 60Hz Models 303556.21 A (9/20)
  • Page 2 Be sure to check with your local agencies for specific requirements. If you need additional information and/or assistance, please contact Customer Service at 888-961-7727 Ext. 8440 or at ahsservice@watkinsmfg.com. Thank you for choosing an Aquaterra Spa. Visit our web site at www.Aquaterraspas.com.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS TITLE PAGE CONTENTS SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS ............................1 IMPORTANT SPA INSTRUCTIONS ............................4 INSTALLATION PLANNING A LOCATION FOR YOUR SPA ..........................5 PLACING THE SPA ..................................6 EQUIPMENT ACCESS EQUIPMENT ACCESS PANEL ..............................7 ELECTRICAL REQUIREMENTS ELECTRICAL REQUIREMENT ..............................8 CONFIGURING SYSTEM ................................9 ELECTRICAL WIRING DIAGRAM FOR 230V USE ........................10 CONTROL PANEL OPERATION TEMPERATURE ADJUSTMENT ................................11...
  • Page 4: Safety Information

    SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS AVOIDING THE RISK TO CHILDREN DANGER: • RISK OF CHILD DROWNING. Extreme caution must be exercised to prevent unauthorized access by children. To avoid accidents, ensure that children cannot use a spa unless they are supervised at all times.
  • Page 5 SAFETY INFORMATION 110 VOLT, CORD-CONNECTED MODELS: • The GFCI is located at the end of the power cord. Before each use, with the unit operat- ing, push the TEST button. The unit should stop operating and the GFCI power indicator will go out.
  • Page 6 SAFETY INFORMATION DON’T: • Use the spa with the equipment compartment door removed. • Place electrical appliances within 5 feet (1.5m) of the spa. • Use an extension cord to connect the spa to its power source. The cord may not be properly grounded and the connection is a shock hazard.
  • Page 7: Important Spa Instructions

    SAFETY INFORMATION AVOIDING THE RISK OF HYPERTHERMIA Prolonged immersion in hot water can result in HYPERTHERMIA, a dangerous condition which occurs when the internal temperature of the body reaches a level above normal 98.6°F (37ºC). The symptoms of hyperthermia include unawareness of impending hazard, failure to perceive heat, failure to recognize the need to exit the spa, physical inability to exit the spa, fetal damage in pregnant women, and unconsciousness resulting in a danger of drowning.
  • Page 8: Installation

    INSTALLATION PLANNING A LOCATION FOR YOUR SPA Consider these things when determining where to place your spa. SAFETY FIRST: Make sure your spa is positioned so access to the equipment compartment and side panels will not be blocked. Be certain your installation will meet all city and local safety codes and requirements.
  • Page 9: Placing The Spa

    INSTALLATION BE AWARE: Damage caused by inadequate or improper foundation support is not covered by the spa warranty. It is the sole responsibility of the spa owner to provide a proper foundation for the spa. Make sure the foundation where the spa is placed drains water away from the spa. Proper drainage will keep components dry from rain and wet weather.
  • Page 10: Equipment Access

    EQUIPMENT ACCESS EQUIPMENT ACCESS PANEL Topside Control Panel Slat Slat Screw Equipment Access Panel Door Foam or Plastic Electrical Recess & Drain Hose Door (Cut-Outs may also be located under door) To access the equipment compartment (if your spa has vertical slats): •...
  • Page 11: Electrical Requirements

    ELECTRICAL REQUIREMENTS ELECTRICAL REQUIREMENT DO NOT POWER THE SPA WITHOUT FIRST FILLING WITH WATER! DANGER – RISK OF ELECTRIC SHOCK Installations that do not conform to the following procedures and requirements may expose users to electric shock. Non-conforming installations will not be covered under warranty. If installed in the United States, the electrical wiring of this spa must meet the requirements of the National Electric Code (NEC) and any applicable state or local codes.
  • Page 12: Configuring System

    ELECTRICAL REQUIREMENTS CONFIGURING SYSTEM SELECTING THE SUPPLY VOLTAGE FOR YOUR SPA Your spa is designed to operate at either 110V 15 amp; 110V 30 amp, or 230V 50 amp circuit. • When the spa is setup for 110V 15 amp, the heater will provide approximately 1000 watts of heat only when the pump is operating in LOW speed and the thermostat is calling for heat (NOTE: The heater does not operate when the pump is on high speed).
  • Page 13: Electrical Wiring Diagram For 230V Use

    ELECTRICAL REQUIREMENTS ELECTRICAL WIRING DIAGRAM FOR 230V USE It is recommended that a licensed electrician install the power to your spa in accordance with the National Electric Code and/or any local electrical codes in effect at the time of installation. Power supply installation must include a properly rated GFCI circuit breaker.
  • Page 14: Control Panel Operation

    CONTROL PANEL OPERATION INITIAL START-UP - When the spa is first powered up the control system begins a 2 minute Startup Mode. Different codes will display on the screen. Once Startup Mode completes, the actual temperature is displayed Indicator Lights on the screen, and the spa will then begin to heat and maintain the water temperature and the...
  • Page 15: Operational Modes

    CONTROL PANEL OPERATION ADJUSTING PRESET FILTER CYCLES Filter duration is programmable between 0.5 and 6 hours in 30 minute increments (0.5 hours) for both filter cycles. To program the cycle times: 1. Press and hold Light button for 5 seconds until F1 is displayed. 2.
  • Page 16: Smart Winter Mode

    CONTROL PANEL OPERATION FAHRENHEIT/CELSIUS SETTING To change water temperature display to either Fahrenheit or Celsius, press and hold Light button for 5 seconds until F1... is displayed. Press the Light button several times until F or C is displayed. Press the Plus or Minus button to change.
  • Page 17: Component Operation

    COMPONENT OPERATION SPA COMPONENT OPERATION AIR CONTROL VALVE The air control valve serves to regulate the amount of air mixed with the water when the jets are operational. Turn the air control valves in one direction to increased jet action. Rotating the air control in the opposite direction to turn air off and allow the jets to work with water only.
  • Page 18: Fill-Up And Start-Up Instructions

    FILL-UP AND START-UP INSTRUCTIONS The following procedures should be followed on initial startup and whenever the spa is drained for routine maintenance. FILLING THE SPA WITH WATER 1. Clear all the debris from your spa. 2. Be sure to open all jets to allow as much air as possible to escape from the plumbing during the filling process.
  • Page 19: Adding Start-Up Chemicals

    ADDING START-UP CHEMICALS WATER CHEMISTRY GUIDELINES Spa water chemistry is ultimately the responsibility of the spa owner. Improper water chemistry may result in costly repairs not covered under the spa warranty. If unsure about any step in the process, please contact a Customer Care Associate at (888) 961-7727 Ext.
  • Page 20: Spa Maintenance

    SPA MAINTENANCE FILTER CARTRIDGE MAINTENANCE Every month, the filter cartridge should be cleaned to remove the objects and particles that have lodged in the cartridge pleats. Using household water pressure and a garden hose with a pressurized nozzle, push water from inside to outside of the pleats, forcing all the trapped particles out.
  • Page 21: Surface Care

    SPA MAINTENANCE SURFACE CARE Do not use solvents or abrasive cleaners to clean the spa. Typically, a mild detergent and water will resolve cleaning issues. COVER CARE Please keep your cover free from dirt at all times. Use a cover cleaner or a warm, mild soapy water to clean the surface.
  • Page 22: Draining Or Winterizing

    DRAINING OR WINTERIZING Every three to six months, depending upon the water condition, you need to renew your water. CAUTION: READ THIS BEFORE DRAINING YOUR SPA • To prevent damage to the spa’s components, UNPLUG GFCI CORD OR TURN OFF SUBPANEL BREAKER BEFORE DRAINING.
  • Page 23: Troubleshooting Procedures

    TROUBLESHOOTING PROCEDURES In the event the spa is not working the way it should, please first review all the installation and operating instructions in this manual and check the message on the panel display. If you are still not satisfied it is working properly, please follow the appropriate troubleshooting instructions. CAUTION! WARNING! SHOCK HAZARD! No User Serviceable Parts.
  • Page 24: Replacement Parts

    REPLACEMENT PARTS REPLACEMENT SPA PARTS PART NUMBER DESCRIPTION 78459 SPA FILTER – 25 sq. ft 78460 SPA FILTER – 50 sq. ft. 303298 ROUND FILTER WEIR 303299 FILTER BASKET SKIMMER 78361 TWIN PULSE JET 78419 MINI JET 303307 LED MULTI-COLOR LIGHT 77190 OZONE KIT (INCLUDES ALL MATERIALS)
  • Page 49 MANUAL DEL USUARIO Modelos de 110 V/230 V 60 Hz 303556.21ES A (9/20)
  • Page 50 Asegúrese de consultar en su oficina local con respecto a los requerimientos específicos. Si necesita información adicional y/o asistencia, comuníquese con el Servicio al cliente al 888-961-7727, extensión 8440 o a ahsservice@watkinsmfg.com. Gracias por elegir un spa Aquaterra. Visite nuestro sitio web en www.AquaTerraspas.com.
  • Page 51 ÍNDICE DE CONTENIDO TÍTULO PÁGINA CONTENIDO INFORMACIÓN SOBRE SEGURIDAD INSTRUCCIONES IMPORTANTES SOBRE SEGURIDAD ....................1 INSTRUCCIONES IMPORTANTES DEL SPA ..........................4 INSTALACIÓN DÓNDE COLOCAR EL SPA ...............................5 COLOCAR EL SPA ..................................6 ACCESO AL EQUIPO PANEL DE ACCESO AL EQUIPO ..............................7 REQUISITOS ELÉCTRICOS REQUISITOS ELÉCTRICOS ..............................8 SISTEMA DE CONFIGURACIÓN ..............................9 DIAGRAMA DE CABLEADO ELÉCTRICO PARA EL USO DE 230 V ..................10...
  • Page 52: Información Sobre Seguridad

    INFORMACIÓN SOBRE LA SEGURIDAD INSTRUCCIONES IMPORTANTES SOBRE SEGURIDAD LEA Y SIGA TODAS LAS INSTRUCCIONES EVITE CUALQUIER TIPO DE RIESGO PARA LOS NIÑOS PELIGRO: • RIESGO DE QUE LOS NIÑOS SE AHOGUEN. Extreme las precauciones para evitar el acceso no autorizado de los niños.
  • Page 53 INFORMACIÓN SOBRE LA SEGURIDAD 110 VOLTIOS, MODELOS CONECTADOS POR CABLE: • El GFCI se ubica en el extremo del cable de la corriente. Antes de usar, y con la unidad en funcionamiento, pulse el botón PRUEBA (TEST). La unidad debe dejar de funcionar y el indicador de encendido GFCI se apagará.
  • Page 54 INFORMACIÓN SOBRE LA SEGURIDAD QUÉ SE DEBE EVITAR: • No utilice el spa sin la puerta del compartimiento del equipo. • No coloque los aparatos eléctricos a 5 pies (1,5 m) del spa. • No utilice una extensión para conectar el spa a la fuente de corriente. La extensión podría no estar conectada a tierra debidamente, lo que representaría un peligro de descarga eléctrica.
  • Page 55: Instrucciones Importantes Del Spa

    INFORMACIÓN SOBRE LA SEGURIDAD • Limpie el cartucho de filtrado mensualmente para eliminar la suciedad y la acumulación de minerales que pueden afectar el rendimiento de los surtidores de hidromasaje, limitar el caudal, o desconectar el termostato de límite máximo, lo que apagará el spa. PARA EVITAR EL RIESGO DE HIPERTERMIA La inmersión prolongada en agua caliente podría producir HIPERTERMIA, que es un trastorno peligroso que se da cuando la temperatura interna del cuerpo alcanza un nivel por encima de lo normal (98,6 °F, 37 ºC).
  • Page 56: Instalación

    INSTALACIÓN DÓNDE COLOCAR EL SPA Tenga en cuenta estas cosas al determinar dónde colocar su spa. LA SEGURIDAD ES PRIMORDIAL: Asegúrese de que el spa está situado de modo tal que el acceso al compartimiento del equipo y a los paneles laterales no se bloquee.
  • Page 57: Colocar El Spa

    INSTALACIÓN TENGA EN CUENTA QUE: Los daños causados por el apoyo inadecuado o incorrecto de la base no están cubiertos por la garantía. Es responsabilidad exclusiva del propietario del spa proporcionarle una base adecuada. Asegúrese de que la base donde se coloca el spa drene el agua del spa. El drenaje adecuado mantendrá a los componentes aislados de la lluvia y el tiempo húmedo.
  • Page 58: Acceso Al Equipo

    ACCESO AL EQUIPO PANEL DE ACCESO AL EQUIPO Panel de control superior Listón Listón Tornillo Puerta del panel de acceso al equipo Puerta de espuma o de Parada eléctrica y manguera de desagüe (también puede haber recortes colocados plástico debajo de la puerta) Para acceder al compartimiento del equipo (si su spa tiene listones verticales): •...
  • Page 59: Requisitos Eléctricos

    REQUISITOS ELÉCTRICOS REQUISITOS ELÉCTRICOS ¡NO ENCIENDA EL SPA SIN ANTES HABERLO LLENADO DE AGUA! PELIGRO: RIESGO DE DESCARGA ELÉCTRICA Las instalaciones que no cumplan con los siguientes procedimientos y requisitos pueden exponer a los usuarios a una descarga eléctrica. Las instalaciones que no cumplan con los procedimientos y requisitos no estarán cubiertas por la garantía.
  • Page 60 REQUISITOS ELÉCTRICOS CÓMO CONFIGURAR EL SISTEMA SELECCIONE EL SUMINISTRO DE VOLTAJE PARA EL SPA Su spa está diseñado para funcionar con un circuito de 110 V 15 amperios; 110 V 30 amperios o 230 V 50 amperios. • Cuando el spa está configurado para 110 V 15 amp, el calentador proporciona aproximadamente 1000 vatios de calor solo cuando la bomba está...
  • Page 61: Diagrama De Cableado Eléctrico Para El Uso De 230 V

    REQUISITOS ELÉCTRICOS DIAGRAMA DE CABLEADO ELÉCTRICO PARA EL USO DE 230 V Se recomienda que un electricista autorizado haga la conexión eléctrica del spa de acuerdo al Código Nacional de Electricidad y/o los códigos locales sobre electricidad vigentes al momento de la instalación. La instalación de la fuente de alimentación debe incluir un disyuntor GFCI nominal adecuado.
  • Page 62: Funcionamiento Del Panel De Control

    FUNCIONAMIENTO DEL PANEL DE CONTROL ARRANQUE INICIAL - Una vez que el spa está conectado al sistema de control se inicia el modo arranque durante 2 minutos. La pantalla mostrará códigos diferentes. Una vez que el modo arranque se ha completado, verá en la pantalla la temperatura actual, el spa Luces indicadoras empezará...
  • Page 63: Modos De Funcionamiento

    FUNCIONAMIENTO DEL PANEL DE CONTROL AJUSTAR LOS CICLOS PREESTABLECIDOS DE FILTRADO Puede programar la duración del filtrado entre 0,5 y 6 horas en incrementos de 30 minutos (media hora) para ambos ciclos de filtrado. Para programar los tiempos del ciclo: 1.
  • Page 64: Mensaje Lcd De Diagnóstico

    FUNCIONAMIENTO DEL PANEL DE CONTROL AJUSTE DE LOS GRADOS EN FAHRENHEIT/CELSIUS Para cambiar la visualización de la temperatura a grados Fahrenheit o Celsius, pulse y mantenga el botón Light durante 5 segundos hasta que se muestre F1. Pulse el botón Light varias veces hasta que se muestre F o C .
  • Page 65: Funcionamiento De Los Componentes

    FUNCIONAMIENTO DE LOS COMPONENTES FUNCIONAMIENTO DE LOS COMPONENTES DEL SPA VÁLVULA DE CONTROL DE AIRE La válvula de control de aire sirve para regular la cantidad de aire mezclado con el agua cuando los surtidores están funcionando. Gire las válvulas de control del aire en una dirección y aumentará la acción del surtidor. Gire el control del aire en la dirección opuesta para apagar el aire y permitir que los surtidores trabajen sólo con agua.
  • Page 66: Cómo Llenar Con Agua El Spa

    INSTRUCCIONES DE LLENADO Y PUESTA EN MARCHA Se deben seguir los siguientes procedimientos en el encendido inicial y cada vez que el spa se vacíe para el manten- imiento de rutina. CÓMO LLENAR CON AGUA EL SPA 1. Retire todos los desechos de su spa. 2.
  • Page 67: Cómo Agregar Los Productos Químicos De Inicio

    CÓMO AGREGAR LOS PRODUCTOS QUÍMICOS DE INICIO GUÍA SOBRE PRODUCTOS QUÍMICOS DEL AGUA El mantenimiento de la composición química del agua del spa es responsabilidad única del propietario. Una composición química del agua incorrecta puede provocar gastos de reparación que no estén cubiertos por la garantía del spa.
  • Page 68: Mantenimiento Del Spa

    MANTENIMIENTO DEL SPA MANTENIMIENTO DEL CARTUCHO DEL FILTRO El cartucho del filtro debe limpiarse cada dos semanas para eliminar los objetos y partículas que se han acumulado en los pliegues del filtro. Use la presión del agua doméstica y una manguera de jardín con una boquilla a presión para empujar el agua desde el interior al exterior de los pliegues, y forzar la salida de todas las partículas atrapadas.
  • Page 69: Cuidado De La Superficie

    MANTENIMIENTO DEL SPA CUIDADO DE LA SUPERFICIE No utilice solventes ni limpiadores abrasivos para limpiar el spa. Por lo general, un detergente suave y agua resuelven los temas de limpieza. CUIDADO DE LA CUBIERTA Mantenga la cubierta limpia en todo momento. Use un limpiador para cubiertas o agua tibia y jabón suave para limpiar la superficie.
  • Page 70: Vaciado O Acondicionamiento Para El Invierno

    VACIADO O ACONDICIONAMIENTO PARA EL INVIERNO Se necesita renovar el agua cada tres - seis meses, dependiendo del estado del agua. PRECAUCIÓN: LEA ESTO ANTES DE VACIAR EL SPA • Para evitar que los componentes del spa se dañen, DESCONECTE EL CABLE GFCI O APAGUE EL DISYUNTOR DEL SUBPANELantes del vaciar el spa.No vuelva a encender el spa hasta haberlo llenado de agua.
  • Page 71: Procedimientos De Solución De Problemas

    PROCEDIMIENTOS DE SOLUCIÓN DE PROBLEMAS En el caso de que el spa no esté funcionando como debería, primero revise todas las instrucciones de instalación y funcionamiento en este manual y compruebe el mensaje en la pantalla del panel. Si aún no considera que esté...
  • Page 72: Piezas De Recambio

    PIEZAS DE RECAMBIO PARTES DE REEMPLAZO DEL SPA NÚMERO DE PARTE DESCRIPCIÓN 78459 FILTRO DEL SPA – 25 pies cuadrados 78460 FILTRO DEL SPA – 50 pies cuadrados 303298 VERTEDERO REDONDO DEL FILTRO 303299 CANASTILLA DEL VERTEDERO DEL FILTRO 78361 CHORRO DOBLE DE PULSO 78419 MINI JET...
  • Page 73 MANUEL DU PROPRIÉTAIRE Modèles 110 V / 230 V 60 Hz 303556.21FR A (9/20)
  • Page 74 Si vous avez besoin d'informations supplémentaires et/ou d'aide, veuillez contacter le Service Clientèleau 888-961-7727 poste 8440 ou à l'adresse ahsservice@watkinsmfg.com. Merci d'avoir choisi un spa AquaTerra. Consultez notre site Web à l'adresse www.Aquaterraspas.com.
  • Page 75 TABLE DES MATIÈRES TITRE PAGE CONTENU INFORMATIONS SUR LA SÉCURITÉ CONSIGNES DE SÉCURITÉ IMPORTANTES .........................1 CONSIGNES IMPORTANTES SUR LE SPA ..........................4 INSTALLATION CHOIX DE L'EMPLACEMENT DE VOTRE SPA ........................5 POSITIONNEMENT DU SPA ..............................6 ACCÈS À L'ÉQUIPEMENT PANNEAU D'ACCÈS À L'ÉQUIPEMENT ..........................7 INSTALLATION ÉLECTRIQUE EXIGENCES ÉLECTRIQUES ..............................8 CONFIGURATION DU SYSTÈME .............................9...
  • Page 76: Informations Sur La Sécurité

    INFORMATIONS SUR LA SÉCURITÉ CONSIGNES DE SÉCURITÉ IMPORTANTES LISEZ ET APPLIQUEZ L'ENSEMBLE DES CONSIGNES PROTECTION DES ENFANTS DANGER : • RISQUE DE NOYADE DES ENFANTS. Tout doit être mis en œuvre pour éviter l'utilisation abusive du spa par les enfants. Afin d'éviter tout accident, veuillez vous assurer que les enfants peuvent accéder au spa uniquement sous l'étroite surveillance d'une personne responsable.
  • Page 77 INFORMATIONS SUR LA SÉCURITÉ MODÈLES DE 110 VOLTS À CORDON D'ALIMENTATION : • Le disjoncteur différentiel est situé au bout du cordon d'alimentation. Avant chaque utilisation, lorsque ce- lui-ci est en fonctionnement, appuyez sur le bouton TEST. L'unité devrait s'arrêter de fonctionner et l'indica- teur d'alimentation du disjoncteur différentiel s'éteindra.
  • Page 78 INFORMATIONS SUR LA SÉCURITÉ CE QU'IL NE FAUT PAS FAIRE : • Utiliser le spa lorsque le panneau d'accès au bloc technique est retiré. • Positionner un appareil électrique à moins de 5 pieds (1,5 m) du spa. • Utiliser une rallonge pour relier le spa à une source d'alimentation. Ce câble pourrait ne pas être correctement relié...
  • Page 79 INFORMATIONS SUR LA SÉCURITÉ PROTECTION CONTRE LE RISQUE D'HYPERTHERMIE L'immersion prolongée dans l'eau chaude peut entraîner une HYPERTHERMIE, une situation dangereuse qui survient lorsque la température interne du corps humain dépasse la valeur normale de 98,6°F (37ºC). Les symptômes de l'hyperthermie comprennent notamment l'inconscience du danger imminent, l'incapacité à ressentir la chaleur, l'incapacité...
  • Page 80: Installation

    INSTALLATION CHOIX DE L'EMPLACEMENT DE VOTRE SPA Considérez les aspects suivants lors du choix de l'emplacement de votre spa. LA SÉCURITÉ AVANT TOUT : Positionnez votre spa de façon à libérer l'accès au bloc technique et aux panneaux latéraux. Assurez-vous que votre installation est conforme à...
  • Page 81: Positionnement Du Spa

    INSTALLATION ÉLÉMENTS À PRENDRE EN CONSIDÉRATION : Les dommages causés par des fondations inadéquates ou inappropriées ne sont pas couverts par la garantie du spa. Il relève de la seule responsabilité du propriétaire du spa de positionner celui-ci sur des fondations appropriées.
  • Page 82: Accès À L'équipement

    ACCÈS À L'ÉQUIPEMENT PANNEAU D'ACCÈS À L'ÉQUIPEMENT Panneau de commandes supérieur Lame Lame Porte du panneau d'accès à l'équipement Porte en mousse Logement électrique et tuyau de vidange ou en plastique (Des découpes peuvent également être située sous la porte) Pour accéder au bloc technique (si votre spa est équipé...
  • Page 83: Installation Électrique

    INSTALLATION ÉLECTRIQUE EXIGENCES ÉLECTRIQUES NE METTEZ PAS LE SPA SOUS TENSION AVANT DE L'AVOIR REMPLI D'EAU ! DANGER – RISQUE D'ÉLECTROCUTION Les installations non conformes aux procédures et aux exigences suivantes font courir à leurs utilisateurs un risque d'électrocution. Les installations non conformes ne seront pas couvertes par la garantie. Si installé...
  • Page 84: Configuration Du Système

    INSTALLATION ÉLECTRIQUE CONFIGURATION DU SYSTÈME SÉLECTIONNER LA TENSION POUR VOTRE SPA Votre spa est conçu pour fonctionner sur un circuit de 110 volts 15 ampères, 110 volts 30 ampères ou 230 volts 50 ampères. • Lorsque le spa est configuré pour 110 volts 15 A, le réchauffeur fournira environ 1000 watts de chaleur uniquement lorsque la pompe fonctionne à...
  • Page 85: Schéma De Câblage Électrique Pour Utilisation De 230 V

    INSTALLATION ÉLECTRIQUE SCHÉMA DE CÂBLAGE ÉLECTRIQUE POUR UTILISATION DE 230 VOLTS Nous vous recommandons de faire installer l'alimentation de votre spa par un électricien agréé, en conformi- té avec la norme électrique nationale et/ou locale en vigueur au moment de l'installation. L'installation de l'alimentation doit inclure un disjoncteur différentiel de capacité...
  • Page 86: Fonctionnement Du Panneau De Commandes

    FONCTIONNEMENT DU PANNEAU DE COMMANDES DÉMARRAGE INITIAL - Lorsque le spa est mis sous tension pour la première fois, le système de commande débute un mode de démarrage de 2 minutes. Différents codes s'affichent à l'écran. Une fois que le mode de démarrage est terminé, la température réelle est affichée à l'écran et le spa commence alors à chauffer et maintenir la température de Voyants d'indicateur l'eau et le premier cycle de filtre débute.
  • Page 87: Modes De Fonctionnement

    FONCTIONNEMENT DU PANNEAU DE COMMANDES RÉGLER LES CYCLES DE FILTRATION PRÉRÉGLÉS La durée de la filtration est programmable entre 0,5 et 6 heures en incréments de 30 minutes (0,5 heures) pour les deux cycles de filtration. Pour programmer les durées de cycle : 1.
  • Page 88: Mode Hivernal Intelligent

    FONCTIONNEMENT DU PANNEAU DE COMMANDES RÉGLAGE EN FAHRENHEIT/CELSIUS Pour modifier l'affichage de température de l'eau en Fahrenheit ou Celsius, appuyez et maintenez enfoncé le bouton Éclairage pendant 5 secondes jusqu'à ce que F1... s'affiche. Appuyez sur la touche Éclairage plusieurs fois, jusqu'à ce que F ou C s'affiche.
  • Page 89: Fonctionnement Des Composants

    FONCTIONNEMENT DES COMPOSANTS FONCTIONNEMENT DES COMPOSANTS DU SPA VANNE DE RÉGULATION D'AIR La vanne de régulation d'air sert à réguler la quantité d'air mélangée à l'eau lorsque les jets sont en marche. Tournez les vannes de contrôle d'air dans une direction pour augmenter la puissance des jets. Tournez les vannes de régulation d'air dans la direction opposée pour permettre aux jets de fonctionner uniquement avec de l'eau.
  • Page 90: Instructions De Remplissage Et De Démarrage

    INSTRUCTIONS DE REMPLISSAGE ET DE DÉMARRAGE Les procédures suivantes doivent être suivies lors de la première mise en route et après chaque vidange du spa, à l'occasion de son entretien de routine. REMPLISSAGE DU SPA 1. Nettoyez tous les débris présents dans votre spa. 2.
  • Page 91: Ajout De Produits Chimiques De Mise En Route

    AJOUT DE PRODUITS CHIMIQUES DE MISE EN ROUTE CONSIGNES POUR L'ÉQUILIBRE CHIMIQUE DE L'EAU C'est le propriétaire du spa qui est le responsable ultime de l'équilibre chimique de l'eau du spa. Un mauvais équilibre chimique de l'eau peut entraîner des réparations coûteuses qui ne sont pas couvertes par la garantie du spa.
  • Page 92: Entretien Du Spa

    ENTRETIEN DU SPA ENTRETIEN DE LA CARTOUCHE DE FILTRATION Une fois par mois, la cartouche de filtration doit être nettoyée afin d'en ôter les débris et les particules qui se sont déposés dans les plis de la cartouche. En utilisant la pression de l'eau domestique au moyen d'un tuyau d'arrosage équipée d'une buse sous pression, évacuez l'eau depuis l'intérieur vers l'extérieur des plis, en repoussant vers l'extérieur toutes les particules piégées.
  • Page 93: Nettoyage Du Revêtement

    ENTRETIEN DU SPA NETTOYAGE DU REVÊTEMENT N'utilisez pas de solvants ou de produits abrasifs pour nettoyer le spa. Dans la plupart des cas, un détergent doux et de l'eau permettront de procéder à son nettoyage. NETTOYAGE DE LA COUVERTURE Veillez à maintenir en permanence la propreté de votre couverture. Utilisez un produit nettoyant pour couverture ou de l'eau chaude savonneuse pour en nettoyer la surface.
  • Page 94: Vidange Ou Hivernage

    VIDANGE OU HIVERNAGE Tous les trois à six mois, vous devrez renouveler l'eau en fonction de son état. MISE EN GARDE : LISEZ CE QUI SUIT AVANT DE VIDANGER VOTRE SPA Afin d'éviter tout dommage aux composants du spa, DÉBRANCHEZ LE CORDON DU DISJONCTEUR •...
  • Page 95: Procédures De Dépannage

    PROCÉDURES DE DÉPANNAGE Dans le cas où le spa ne fonctionne pas correctement, veillez à vérifier d'abord l'intégralité des consignes d'installation et d'utilisation présentes dans ce manuel et contrôlez le message présent sur le panneau d'affichage. Si vous n'êtes toujours pas satisfait de son fonctionnement, veuillez suivre les instructions de dépannage appropriées.
  • Page 96: Pièces De Rechange

    PIÈCES DE RECHANGE PIÈCES DE RECHANGE DE SPA RÉFÉRENCE DESCRIPTION 78459 FILTRE DE SPA – 25 pieds carrés 78460 FILTRE DE SPA – 50 pieds carrés 303298 DÉVERSOIR DE FILTRE ROND 303299 PANIER D'ÉCUMAGE DU FILTRE 78361 JET DOUBLE IMPULSION 78419 MINI JET 303307...
