Maple Systems HMC7-MI-02 Quick Start Manual page 2

Con�iguration:
Use MAPware-7000 to assign input (XW) and con�iguration
(MW) memory addresses to the module. These addresses are
created according to the slot location of the module, where nn
refers to the slot number (ex. 01...05):
Register Description
XWnn00 Input Channel 1 Data
XWnn01 Input Channel 2 Data
XWnn02 Input Channel 3 Data
XWnn03 Input Channel 4 Data
MWnn00 Input Channel 1
Con�iguration Register
MWnn01 Input Channel 2
Con�iguration Register
MWnn02 Input Channel 3
Con�iguration Register
MWnn03 Input Channel 4
Con�iguration Register
Reference the table below when con�iguring each Input
Con�iguration Register (MWnn00-MWnn03):
Input Channel Value
Signal Type
mA (4-20mA) 0
Voltage (0-10V) 1
Voltage (-10 to +10V) 2
mA (0-20mA) 3
Phone: 425/745-3229 • Fax: 425/745-3429 • Email: maple@maplesystems.com • www.maplesystems.com
Doc. No. 1011-0702
Additional Resources:
Detailed instructions on the operation and installation of the
HMC7000 Series are available in the HMC7000 Programming
Manual that is included with the MAPware-7000 con�iguration
software. MAPware-7000 also includes help �iles, which
provide detailed information on using the con�iguration
software.
Access
Read Only
Read Only
Read Only
Read Only
WARNING: DO NOT REMOVE OR REPLACE WHILE CIRCUIT
Read/Write IS LIVE UNLESS THE AREA IS KNOWN TO BE FREE OF
IGNITIBLE CONCENTRATIONS OF FLAMMABLE SUBSTANCES.
Read/Write This equipment is suitable for use in Class I, Division 2, Groups
A, B, C and D or non-hazardous locations only.
Read/Write
WARNING – EXPLOSION HAZARD – Do not disconnect
Read/Write
equipment unless power has been removed or the area is
known to be non-hazardous.
WARNING – EXPLOSION HAZARD - Substitution of
components may impair suitability for Class I, Division 2.
It is recommended that the user periodically inspect the sealed
devices used, check for any degradation of properties, and
replace as necessary.
Page 2 of 2
Model: HMC7-MI-02
For Technical Support:
Please contact Maple Systems if you have any questions
regarding this product. We ask that you provide us with the
unit serial number and �irmware revision number written on
the product label of the unit.
Maple Systems Inc.
808 134 St. SW, STE 120
th
Everett, WA 98204
Tel: 425-745-3229
Fax: 425-745-3429
Email: support@maplesystems.com
Website: www.maplesystems.com
Rev. 03, 09/06/2012
.
