iCool 2020 Compact Series 3
Owners Manual
icoolsport.com
info@icoolsport.com
iCool Compact Series | Owners Manual
Page
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iCool 2020 Compact 3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iCoolsport iCool 2020 Compact 3 Series

  • Page 1 2020 Compact Series 3 Owners Manual icoolsport.com info@icoolsport.com iCool Compact Series | Owners Manual Page...
  • Page 2 iCool Compact Series | Owners Manual Page...
  • Page 3 Index Product Setting up Page 08 Page 05 Overview your iCool Problem Operating Page 12 Page 19 Resolution your iCool Important Troubleshooting Page 22 Page 26 Safety Warnings Recommended Specifications Page 30 Page 28 Pool Sizes iCool Compact Series | Owners Manual Page...
  • Page 4 Compact Series...

  • Page 5: Product Overview

    Product Overview Compact Cool Series 3 Compact XP Dual Temp Series 3 The Compact Cool is a popular lower cost system The Compact XP Dual Temp provides all the for fast cooling of a single person pool. It provides power and functions of the Compact XP with impressive cooling power of 5000 watts.
  • Page 6 “ The in ice ba iCool Compact Series | Owners Manual Page...
  • Page 7 ndustry leader in ” ath technology. iCool Compact Series | Owners Manual Page...

  • Page 8: Basic Setup

    Basic Setup Step 1: Connecting The Water Hoses to Your Pool Follow this illustrations and match the colours of the connectors as shown. GREEN to the TOP to the BOTTOM Alternative Hoses and Pumps Cool machines are sometimes delivered with different pumps, hose sets and water connectors depending on the owners intended use.
  • Page 9 Step 2: Connecting The Water Hoses* To Your Water Circulation Pump The shorter length of hose with RED connectors, connects between the BOTTOM fitting on the Compact and to the TOP fitting on your water circulation pump as shown below. The longer length of hose with RED connectors, connects between the BOTTOM fitting on the pool and the BOTTOM fitting on your water circulation pump.
  • Page 10 Basic Setup Step 3: Connecting Electric Power to your Compact machine and your water Pump Make sure that you do not connect your Compact machine to the wrong voltage. Please check the voltage on the name plate above the power IN socket. It is either a 220 volt model or a 110 volt model. You must not connect to the wrong voltage or this will cause serious damage.
  • Page 11 Step 4: The Touch Screen Controller The all new modern user interface has been completely redesigned to provide completely automatic start up and operational. Just set the temperature you need and touch the START Button. Intelligent Water Flow correction If the water does not flow steadily when you first start up due to air being trapped in the hoses to and from the pool or inside the water pump your iCool will attempt to clear it automatically 3 times.
  • Page 12 Starting Up Step 5: STARTING UP and Making your Settings Turn on the MAIN POWER SWITCH. The Touch Screen will be blank for a few seconds and then the iCool Logo will appear. This will continue until your machine has loaded its operating software and run a full system check. Do no touch the screen during this self test proceedure.
  • Page 13 Step 6: The Welcome Screen Appears A Welcome screen movie of ice and snow indicates that the machine has loaded the latest software and all safety checks have been completed successfully. The logo light bar located on the top of your machine will be white. TOUCH the screen anywhere and the Main Operating Screen will appear.

  • Page 14: Cold Setting

    Cold Setting Step 7: Setting the COLD Temperature You Need To SELECT the TEMPERATURE you require simply touch the buttons repeatedly until the large number above these buttons displays the COLD temperature you need. Quickly touch the SET button to lock it in. Your SET Temperature will now be displayed on the left side as the TARGET Temperature and the large numbers in the middle will now display the actual POOL WATER Temperature.
  • Page 15 Hot Setting Not Available on COLD ONLY Machines Step 8: Setting the HOT Temperature You Need To SELECT the TEMPERATURE you require simply touch the buttons repeatedly until the large number above these buttons displays the HOT temperature you need. Quickly touch the SET button to lock it in.

  • Page 16: Start Automatic Operation

    Start Automatic Operation Step 9: Touch the Green START BUTTON The Start button begins a Fully Automatic Start Up proceedure and controls all normal operations. A PROGRESS BAR will appear along the bottom of the screen to inform you of the start up progress. Your machine will first start the water pump.

  • Page 17: System Settings

    System Settings Step 10: Changing Basic System Settings Touch the Blue MENU Button to reveal all available options on your machine & choose SETTINGS from the list. You can change between Centigrade and Fahrenheit. You can select the volume of the System Sounds.
  • Page 18 System Settings Step 11: Built In SESSION TIMER Your iCool Compact has a built in SESSION TIMER. This allows you to pre set the amount of time athletes should remain in the pool. It provides a count down on the screen. It sounds a warning at the end of the session.
  • Page 19 Water Flow Problems Problem Resolution - Your Compact Machine will attempt to correct any water flow problems The most common issue that can prevent successful operation is lack of water flow. The light bar will turn ORANGE if this happens. It can occur if air is trapped in the water pipes or the pump, or if flow is restricted in the hoses.
  • Page 20 Water Flow Problems Fixed Automatically If your Compact can correct the lack of water flow itself it will do so and advise on the screen. No action is needed, it will continue to operate correctly. iCool Compact Series | Owners Manual Page...
  • Page 21 If the Compact Machine is Unable to Correct the Water Flow Problem Itself An explanation will appear in the middle of the screen and the light bar will flash to notify you the machine has stoppped. Your iCool machine can not continue until the reason for the lack of water is found. See page 27. This is important because such a powerful machine could easily freeze the remaining water in the titanium heat exchanger tank solid and that could cause serious damage.

  • Page 22: Important Safety Warnings

    Important Safety Warnings Power Supply Voltage An Approved Earth Connection Is Essential For Safe Operation iCools can only be connected to the voltage marked on the machine. They are manufactured To ensure safe operation the AC power but they as either 110v or 220v machines, connection you use must have an earth are not multi-voltage.
  • Page 23 Limits To The Electric Shock Protection System Emergency Stop The iCool residual earth leakage protection In an emergency touch the ORANGE system can only protect against devices button on the MAIN POWER SWITCH actually connected to the iCool. It can not or switch off the main power switch protect against faults in other unrelated electric and all high voltage electrical power...
  • Page 24 Important Safety Warnings Understanding Water Flow Problems Water Flow Can Also Stop If The Heat Exchanger Tanks are Frozen Solid A water flow warning will display if the water flow does not begin or if it fails for any reason. If you set the temperature below about 7ºC Running the iCool with no water flow can cause or 45ºF it is occasionally possible in certain...
  • Page 25 Do Not Operate The Spa Jets For After thawing, set a new temperature no lower Long Periods than 8 or 9ºC before restarting to prevent the tanks freezing again. If your pool has spa jets it is best not to leave If this becomes a problem then adding a little them running because spa jets inject the warm salt to the water will lower the temperature at...

  • Page 26: Troubleshooting

    Troubleshooting If Your Screen Freezes Or Fails To If The iCool Shuts Down And Displays Respond A “System Too Hot” Red Warning Screen This is a very rare issue. If the screen freezes while the iCool is running normally, the main Your Compact Cool can move large amounts computer will usually still carry on running the of heat per hour.
  • Page 27 Our Customer Support Is Screen Available 7 Days A Week To protect the pump and the Titanium heat Just email us at info@icoolsport.com exchanger tanks, the system will not allow and we will respond with assistance operation unless the water flows correctly. If usually the same day.

  • Page 28: Specifications

    Specifications* Compact Compact Compact XP Compact Specification Compact XP Cool Dual Temp Dual Temp Iceman Cooling Power 5000 Watts 5000 Watts 7200 Watts 7200 Watts 7800 Watts Heating Power Chill Only 5000 Watts Chill Only 7100 Watts Chill Only Run (& Max.) Power 5 Amps (12 Amps) 6.5 Amps (13 Amps) 7.5 Amps (14 Amps)
  • Page 29 We welcome your feedback and suggestions and we offer support for general inquiries and information for specific countries on our website at icoolsport.com iCool Compact Series | Owners Manual Page...
  • Page 30 Recommended Pool Sizes Compact XP Dual Temp Compact XP Pools from 300 to Pools from 300 to 2000 2000 litres. Pool cover litres, ideal for warmer necessary in heating weather or faster cooling. mode. IceMan 300 to 2000 litres, best model for fastest cooling and hot weather.
  • Page 31 iCool Compact Series | Owners Manual Page...
  • Page 32 +61 419 785 509 Burleigh Heads, Gold Coast, Australia Representatives around the world iCool Compact Series | Owners Manual icoolsport.com Page...
