SP16 SERIES PROGRAMMER
Before using the programmer, please read this manual carefully and operate the
programmer correctly as required. Failure to follow the instructions will result in
damage to the programmer and no warranty service!
USER MANUAL
深 圳 硕 飞 科 技 有 限 公 司
SHENZHEN SOFI TECHNOLOGY CO.，LTD.
WEB: WWW.SOFI-TECH.COM
硕飞科技
Revision B5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sofi SP16 Series
Summary of Contents for Sofi SP16 Series
- Page 1 硕飞科技 SP16 SERIES PROGRAMMER USER MANUAL Revision B5 Before using the programmer, please read this manual carefully and operate the programmer correctly as required. Failure to follow the instructions will result in damage to the programmer and no warranty service! 深...
-
Page 2: Table Of Contents
硕飞科技 User Manual SP16 Series programmer Contents Chapter1. Introduction into Products 3 Performance and Characters 3 Correlation Table of SP16 Performance 4 Chapter 2. Programmer Hardware 5 Chapter 3. Quick start 6 Programming steps for on-line mode 6 LED status for On-line programming mode 8 Chapter 4. -
Page 3: Chapter1. Introduction Into Products
硕飞科技 User Manual SP16 Series programmer Chapter 1. Introduction into Products Performance and characters ⚫ Designed specifically for serial EEPROM / SPI FLASH device, faster and more stable than general- purpose programmer ⚫ USB power supply and communication, no external power supply required. Small size (size: 103x71x23mm), easy to carry ⚫... -
Page 4: Correlation Table Of Sp16 Performance
Off-line programming means the model can program without computer, suitable for mass production. On-line mass production refers to connecting to a computer for batch programming. Note 2: One computer can maximum connect eight SP16 series programmers (need to work together with FlyPRO_MCP software, search Chapter 6 for specific usage); Note 3: Depending on the software function, not all the devices are supported;... -
Page 5: Chapter 2. Programmer Hardware
硕飞科技 User Manual SP16 Series programmer Chapter 2. Programmer hardware Programmer ZIF Socket PWR(Power) STA(State) USB Interface ISP/ATE Interface Accessories USB Cable ISP Cable 5V/1A Power adapter ⚫ The appearance of different models and batches may vary, please refer to the actual product;... -
Page 6: Chapter 3. Quick Start
硕飞科技 User Manual SP16 Series programmer Chapter 3. Quick start Programming steps for on-line mode 1. Install programmer control software: FlyPRO (Includes USB driver, single control software FlyPRO, multi-control software FlyPRO), software download website: www.sofi-tech.com 2. Connect programmer to USB port of computer with a USB cable. - Page 7 硕飞科技 User Manual SP16 Series programmer 5. Load programming file ，or menu [File] - [Load File] to load the data file of program. Click toolbar button 6. Set operation options ， or menu [Operation] - [Operational Options] to device Click the toolbar button programming settings.
-
Page 8: Led Status For On-Line Programming Mode
硕飞科技 User Manual SP16 Series programmer Automatic mode Select the "Automatic Programming" page in the command bar on the left side of the main software window. First set the operation content, and then click the "single program" button. The programmer then performs the steps set in "Operational Content"... - Page 9 硕飞科技 User Manual SP16 Series programmer Status LED (STA)： STA LED status Status description Programming device Orange Device programming completed, programming successfully Green Device programming failed ● The above operation is only a demonstration of the conventional programming steps of the general device，and the specific operation needs to be determined according to actual needs.
-
Page 10: Chapter 4. Off-Line Programming
硕飞科技 User Manual SP16 Series programmer Chapter 4. Off-line Programing SP16-F、SP16-FX supports off-line program. In this mode, programmers don't have to be connected to a computer. Programmer has a built-in 128Mbit data memory, eliminating the need for additional storage. Off- line program is easy and efficient. - Page 11 硕飞科技 User Manual SP16 Series programmer Controlled by ISP/ATE interface This option can be used only in SP16-FX. When this function is checked, SP16-FX works in the automatic control mode and works with automatic machine. If this function is not checked, SP16-FX works in manual mode.
-
Page 12: Off-Line Operation - Manual Mode
硕飞科技 User Manual SP16 Series programmer Off-line operation – automatic control mode The automatic control mode is only applicable to SP16-FX, which is used to cooperate with automatic equipment such as automatic programming machine and robot to realize automatic operation of devices. -
Page 13: View Off-Line Data
硕飞科技 User Manual SP16 Series programmer View off-line data Off-line data that has been downloaded to the programmer can be viewed with FlyPRO software. Click the menu [Device] - [Off-line Data Management] - [View Off-line Data] to open off-line data viewing dialog box, as shown below: ●... -
Page 14: Chapter 5. Isp Programming
Use ISP programming mode The SP16 series programmer only supports ISP mode programming of some devices. When the device model with the "[ISP]" suffix is selected in the software, it means that ISP mode is used for programming. -
Page 15: Target Devices Connections
硕飞科技 User Manual SP16 Series programmer The correspondence between the color of the connecting line and the pin number is as follows： Color Pin number Color Pin number brown Blue purple Orange(or pink) Gray Yellow White Green Black Target device connections... -
Page 16: Isp Power Supply Mode
硕飞科技 User Manual SP16 Series programmer ISP Power supply mode When using ISP program, there are two power modes available for the target device. The power mode can be set in the operating options of FlyPRO software. ⚫ Powered by programmer Programmer supplies voltage to the target board at a supply voltage of 1.8V, 2.5V, 3.3V, or 5V (set in... -
Page 17: Chapter 6. Flypro Mcp Multi-Machine Control Software
SP16 Series programmer Chapter 6. FlyPRO MCP multi-machine control software Function Introduction ● FlyPRO MCP is the multi-machine control software of SOFI SP16 series programmer ● Up to 8 programmers can be connected to a single computer ● Can support 8 programmers to work at the same time, including: automatic programming (single), mass production programming, download off-line data (SP16-F/SP16-FX) ●... - Page 18 硕飞科技 User Manual SP16 Series programmer Step 3: USB driver installation ● When using for the first time, the computer needs to install the driver for each USB interface programmer. Usually the computer will do this automatically. ● USB driver installation may take several minutes, please wait for the installation to complete ●...
-
Page 19: Flypro_Mcp Function Limitations
硕飞科技 User Manual SP16 Series programmer Step 6: Action FlyPRO_MCP function limitations Compared to the standard stand-alone software FlyPRO, the following functions are not supported in multi- machine software. ● Automatic serial number ● Manual operation (multi-machine software only supports automatic programming, mass production programming and off-line data download) ●... -
Page 20: Appendix I Faq20
硕飞科技 User Manual SP16 Series programmer Appendix I FAQ ☺ Why 24 series device does not have an erase function The device is based on EEPROM technology, device data can be directly rewritten without pre- ◼ erasing, so there is no erase operation available. - Page 21 硕飞科技 User Manual SP16 Series programmer ☺ How should the device configuration bit be set? All configuration options of the device are listed according to the specifications of the device manufacturer. The programmer is only responsible for writing data set by users to devices. The programmer’s manufacturer cannot tell users how to set it.
-
Page 22: Appendix Ii Disclaimer
SP16 Series programmer Appendix II Disclaimer Shenzhen SOFI Technology Co., Ltd. will do its utmost to ensure the correctness of the products and related software and materials. For the possible defects or errors of products (including software and related materials), the company will try its best to solve with commercial and technical means. The Company shall... -
Page 23: Appendix Iii Revision History
硕飞科技 User Manual SP16 Series programmer Appendix III Revision History Release Date Version Reviser Description 2019-06-27 LiuYX First English edition SHENZHEN SOFI TECHNOLOGY www.sofi-tech.com...
