INSTALLATION AND
OPERATION MANUAL
SWIMMING
POOL & SPA
HEATER D-2
D-2 POWER VENT
206A, 207A, 266A,
267A, 268, 336A, 337A,
406A, 407A, 408
(ELECTRONIC IGNITION
MODELS ONLY)
WARNING: If these instructions are not followed exactly, a fire or explosion may
result causing property damage, personal injury or death
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids or other combustible materials in the vicinity of this or any other appliance. To
do so may result in an explosion or fire.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
This manual should be maintained in legible condition and kept adjacent to the heater or in another safe place for
future reference.
APPROVED
UNCONTROLLED DOCUMENT IF PRINTED
.
Effective: 08-13-2021
Replaces: 06-15-2017
P/N 241243 Rev. 7
Advertisement
Table of Contents
Related Manuals for Rheem Raypak D-2 Power Vent
Summary of Contents for Rheem Raypak D-2 Power Vent
- Page 1 INSTALLATION AND APPROVED OPERATION MANUAL SWIMMING POOL & SPA HEATER D-2 D-2 POWER VENT 206A, 207A, 266A, 267A, 268, 336A, 337A, 406A, 407A, 408 (ELECTRONIC IGNITION MODELS ONLY) WARNING: If these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or death FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and liquids or other combustible materials in the vicinity of this or any other appliance.
- Page 2 APPROVED Revision 7 reflects the following changes: Reformatted to current standard. Revised Figure 1. Added "NOTE" after Figure 9. "Venting" text revised on page 10. Updated wire diagrams on pages 19 through 21. Figure in "Illustrated Parts List" revised on page 23. UNCONTROLLED DOCUMENT IF PRINTED...
-
Page 3: Table Of Contents
APPROVED TABLE OF CONTENTS 1. WARNINGS ............4 7. WIRING ..............16 Pay Attention to these Terms ........4 Wiring Diagram:Models 207a, 267a, 337a, 407a .. 19 Wiring Diagram:Models 206a, 266a, 336a, 406a .. 20 2. RECEIVING EQUIPMENT ........5 Wiring Diagram: Models 268, 408 ...... -
Page 4: Warnings
APPROVED 1. WARNINGS Pay Attention to these Terms Indicates the presence of immediate hazards which will cause severe personal injury, death or substantial DANGER property damage if ignored. ndicates the presence of hazards or unsafe practices which could cause severe personal injury, death or WARNING substantial property damage if ignored. -
Page 5: Receiving Equipment
APPROVED 2. RECEIVING EQUIPMENT 3. GENERAL SPECIFICATIONS On receipt of your equipment, it is suggested that you visually check for external damage to the carton. If the The D-2 Power Vent is tested and certified to the latest carton is damaged, it is suggested that a note be made edition of the American National Standard ANSI Z21.56 on the Bill of Lading when signing for equipment. -
Page 6: Installation
APPROVED 4" FLUE 18.13" (46 cm) COLLAR 7.91" (20 cm) 13.59" (34.5 cm) 1.88" (4.78 cm) 4.38" (11.13 cm) Figure 2. Dimensions 5. INSTALLATION 1. Start off by disconnecting main power to the heater. 2. Remove the front door from the heater. See Figure 3. Figure 4. - Page 7 APPROVED 7. If installing on a model 266, 267, 268, 406, 407 or 408 heater, skip step 8. 8. Turn the Power Vent upside down. Using a 5/16" nut driver, relocate the mounting brackets as shown in Figure 10. BEFORE Figure 6.
- Page 8 APPROVED 11. Push in all four bracket tabs, so the Power Vent locks into position. See Figure 13. POWER VENT POWER SUPPLY Figure 13. Tab Location 12. Using a 5/16" nut driver, remove the transformer Figure 15. Conduit Routing cover located on the right side of the heater. See Figure 14.
- Page 9 APPROVED D-2 POWER VENT 240VAC 009832 & 009833 ACCESS SCREW ACCESS FACTORY WIRED SCREW 240 VOLTS TO CONVERT FOR 120V OPERATION Figure 19. Control Panel Screw Location 18. Remove and replace the 7/8" plug with the provided 7/8" grommet (located on the left side of the control panel).
-
Page 10: Venting
APPROVED 6. VENTING The D-2 Power Vent operates with a positive vent static pressure and with a vent gas temperature that prevents excessive condensate production in the vent, and requires Category III venting. The 4" collar atop the D-2 Power Vent requires a gasket- to-gasket flue adapter in order to properly connect to your selected brand of 4"... -
Page 11: Venting Clearances
APPROVED Venting Clearances Figure 23. Minimum Clearances from Vent/Air Inlet Terminations – Indoor and Outdoor Installations U.S. Installations Canadian Installations Clearance above grade, veranda, porch, 1 ft (30 cm) 1 ft (30 cm) deck, or balcony 4 ft (1.2m) below or to side Clearance to window or door that may be of opening;... - Page 12 APPROVED 10' (3 m) 10' (3 m) OR LESS OR LESS 2' (61 cm) 2' (61 cm) MINIMUM MINIMUM 3' (91 cm) 3' (91 cm) MINIMUM MINIMUM 9" (22.9 cm) 9" (22.9 cm) MINIMUM MINIMUM 1' (30.5 cm) 1' (30.5 cm) ABOVE GRADE ABOVE GRADE OR NORMAL...
- Page 13 APPROVED 16" (40.6 cm) 19" (48.3 cm) MINIMUM ** MINIMUM ** 6" (15.2 CM) 6" (15.2 CM) 6" (15.2 CM) 6" (15.2 cm) 6" (15.2 CM) 12" (30.5 cm) 6" (15.2 cm) MINIMUM ** MINIMUM ** MINIMUM ** MINIMUM ** MINIMUM *** MINIMUM *** MINIMUM **...
- Page 14 APPROVED 9" (22.9 cm) 9" (22.9 cm) MINIMUM ** MINIMUM ** 6" (15.2 cm) 6" (15.2 cm) 6" (15.2 cm) 12" (30.5 cm) MINIMUM ** MINIMUM *** MINIMUM ** MINIMUM *** * 7' MIN. (1.2 m) ABOVE PUBLIC WALKWAYS * 7' MIN. (1.2 m) ABOVE PUBLIC WALKWAYS * 3' MIN.
- Page 15 APPROVED 9" (22.9 cm) MINIMUM ** FIELD-SUPPLIED CAT III FLUE 6" (15.2 cm) 6" (15.2 cm) MINIMUM ** *** MINIMUM * USE VERTICAL VENT PIPE TO MEET MINIMUM HEIGHT REQUIREMENTS ** MUST BE 4' (1.2 m) AWAY FROM ANY WINDOW, DOOR, OR GRAVITY AIR INLET *** RECOMMENDED SERVICE CLEARANCES IS 24"...
-
Page 16: Wiring
APPROVED 7. WIRING The D-2 Power Vent includes a wire harness which provides quick connections with the respective controls in the appliance control box. The harness is of sufficient length to fit the unit for which it is sized. Reference the connection diagrams Figure 29 and Figure 30 or the wiring diagrams on pages 19 through 21 for actual connections. - Page 17 APPROVED MODELS 207, 267, 337, 407 EQUIPPED WITH HONEYWELL GAS VALVE STEP 1 STEP 3 : VERIFY CURRENT CONNECTIONS : CONNECT THE RETURN LINES, FEMALE SPADES TO MALE SPADES AS SHOWN BELOW. AS SHOWN BELOW. RELAY D-2 POWER VENT RELAY R/BK P/PV R/BK...
- Page 18 APPROVED MODELS 206, 266, 268, 336, 406, 408 EQUIPPED WITH HONEYWELL GAS VALVE STEP 1 STEP 3 : VERIFY CURRENT CONNECTIONS : CONNECT THE RETURN LINE, FEMALE SPADE TO MALE SPADE AS SHOWN BELOW. AS SHOWN BELOW. D-2 POWER VENT R/BK P/PV R/BK...
-
Page 19: Wiring Diagram:models 207A, 267A, 337A, 407A
Wiring Diagram: Models 207A, 267A, 337A, 407A APPROVED UNCONTROLLED DOCUMENT IF PRINTED... -
Page 20: Wiring Diagram:models 206A, 266A, 336A, 406A
Wiring Diagram: Models 206A, 266A, 336A, 406A APPROVED UNCONTROLLED DOCUMENT IF PRINTED... -
Page 21: Wiring Diagram: Models 268, 408
APPROVED Wiring Diagram: Models 268, 408 UNCONTROLLED DOCUMENT IF PRINTED... -
Page 22: Sequence Of Operation
APPROVED 8. SEQUENCE OF 10. REPLACEMENT PARTS OPERATION NOTE: To supply you with the correct part, it is important that you supply the heater model number, serial number On call for heat, the PC board will go through its safety and type of gas when applicable. -
Page 23: Illustrated Parts List
APPROVED 11. ILLUSTRATED PARTS LIST CAT III VENT, 4" STAINLESS FIELD-SUPPLIED 4" GASKET-TO-GASKET VENT ADAPTER, FIELD-SUPPLIED UNCONTROLLED DOCUMENT IF PRINTED... - Page 24 APPROVED Raypak, Inc., 2151 Eastman Avenue, Oxnard, CA 93030 (805) 278-5300 Fax (805) 278-5468 UNCONTROLLED DOCUMENT IF PRINTED...
