A20h
使用说明书
深圳市大号科技有限公司

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A20h and is the answer not in the manual?

Questions and answers

Summary of Contents for Sabaj A20h

  • Page 1 A20h 使用说明书 深圳市大号科技有限公司...
  • Page 2 A20h 安全注意事项 请将本音响系统安装在通风良好、 阴凉、 干燥、 干净的位置, 远离直射阳光热源 、 振动、 灰尘、 潮湿或寒冷。 只能使用本机指定的电压。 使用高于指定数值的电压很危险, 而且可能导致火 灾, 损坏本机或造成人身伤害。 对于使用高于指定电压造成的任何损害, 深圳 市大号科技有限公司将不负任何责任。 不要试图自行改造或修理本机。 如果需要任何服务, 请就近与有资格的深圳市 大号科技有限公司维修人员联系。 不管有任何理由, 都没有打开机壳的必要。 如果打算长时间不使用本机 (比如度假时) , 请从墙壁交流电源插座上断开电 源线的连接。 保修条款 一、 服务期限 深圳市大号科技有限公司承诺产品的良好品质, 产品自售出之后7天内正常 使用情况下出现故障, 客户可以选择退货或者保修 (不影响二次销售才可退 货) 。 正常使用一年内出现故障可以免费保修。...
  • Page 3 A20h 产品特点 超低失真精密线性反馈电路(PLFC), 失真度低至0.00008%! 超低噪声电源设计, 使输出噪声低到1.3uV(APX555B实测值, 不是等效值!) 超紧凑设计, 非常适合桌面耳机系统 ; 高精度低温漂电阻,性能不受温度影响 ; 高品质继电器和无冲击声设计 ; 高精度低噪声256级继电器音量控制 ; *实际使用时为了音量更加线性, 屏蔽了多余的级数。 16欧姆输出功率达4W, 32欧时达到2W ; 20Hz至500kHz频率响应 ; 高中低三档可切换增益控制 ; 耳机放大器具有DC, 过压,过热保护等全面保护 ; 使用高效低噪声的电源系统 。...
  • Page 4 A20h 技术参数 输入方式: 平衡 x1 ; 非平衡 x1 输出方式: 平衡耳机x1 ; 4.4mm平衡耳机x1 ; 非平衡耳机x1 输出功率: 4W x 2 (16 Ω) 2W x 2 (32 Ω) 1W x 2 (300 Ω) 500mW x 2 (600 Ω) 信噪比: 137dB 剩余噪音: 1.3uV THD+N: -121dB, 0.00008% (1kHz , 32 Ω)
  • Page 5 A20h 关于遥控器 如果遥控器距离本机很近时操作仍无效, 请用新电池更换。 如果要长时间不使用遥控器, 请取出遥控器的电池。 按照电池处置的地方性法规处置废旧电池。 遥控器的使用 开关机 静音 音量加/向上 进入菜单/确认 功能菜单切换 返回 音量减/向下 增益控制 输入切换 无功能 切换至控制 A20h 注 意 1. 遥控器请使用2节7号(AAA)电池 2. 第一次操作 时, 先按 B 键 A20h...
  • Page 6 A20h 接口介绍 A20h H IGH RESOLUTION H EA DPHONE A MPLIFIER OUTPUT I NPUT 旋钮 6.35mm耳机插座 红外接收窗 4.4mm耳机插座 显示屏 RCA输入 平衡输入 电源输入 (DC 15V) 平衡耳机插座 注: 1.连接耳机前请调小音量, 以免音量过大损坏耳机; 2.根据健康专家的建议,请勿长时间聆听耳机以免影响听力。...
  • Page 7 A20h 功能菜单介绍 输入选择 In1 ( XLR平衡线路输入) In2 ( RCA非平衡线路输入) 增益控制 (低增益) (高增益 1 ) (高增益 2 ) 3种亮度 (亮度 1) (亮度 2 ) (亮度 3 )...
  • Page 8 A20h USER MANUAL Shenzhen DaHao Technology Co.,Ltd.
  • Page 9: Safety Notes

    Install this unit in a well ventilated, cool, dry, clean place-away from direct sunlight, heat sources, vibration, dust, moisture, or cold.. Do not attempt to modify or fix this unit. Contact qualified Sabaj service personnel when any service is needed. The cabinet should never be opened for any reason.
  • Page 10 A20h Features Ultra-low distortion precision linear feedback circuit (PLFC), distortion as low as 0.00008%! Ultra-low noise power supply design, so that the output noise is as low as 1.3uV (APX555B measured value, not equivalent); Ultra-compact design, suitable for desktop headphone system;...
  • Page 11: Specifications

    A20h Specifications Inputs: Balanced x1, Unbalanced x1 Outputs: Balanced x2, Unbalanced x1 Output Power: 4W x 2 (16 Ω) 2W x 2 (32 Ω) 1W x 2 (300 Ω) 500mW x 2 (600 Ω) SNR: 137dB Output Noise: 1.3uV THD+N: -121dB, 0.00008% (1kHz, 32 Ω)
  • Page 12: Remote Control

    Menu / OK Next level menu Return Volume - /down Gain control Input select Invalid Switch to control A20h Note 1. This remote controller use 2 x R03/AAA battaries. 2. When you first operate A20h, press the B key first.
  • Page 13: Parts Name

    A20h Parts name A20h H IGH RESOLUTION H EA DPHONE A MPLIFIER OUTPUT I NPUT 6.35mm headphone jack Knob Remote window 4.4mm headphone jack Display RCA input Power Supply(DC15V) XLR input Balanced headphone jack Note: Please turn down the volume before connecting the headphones to avoid excessive volume damage to the headset.
  • Page 14 A20h Setting Introduction Input In1 ( Balanced line in) In2 ( Unbalanced line in) Gain control (Low gain) (High gain 1) (High gain 2) Brightness (Brightness 1) (Brightness 2) (Brightness 3)...
