Summary of Contents for Coaster 722272
- Page 1 7 2 2 2 7 2 R E V I S I ON 0 : 0 5 / 3 1 / 2 0 1 8 R E V I S I ON 1 : 0 5 / 1 4 / 2 0 1 9 R E V I S I ON 2 : 1 0 / 2 9 / 2 0 1 9 C O A S T E R F U R N I T U R E .
- Page 2 722272 ITEM: ASSEMBLY INSTRUCTION ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
- Page 3 722272 ITEM: ASSEMBLY INSTRUCTION ATTENTION:Anti tipping safeguard Please install the Anti tipping hardware as shown in the drawing this can help to prevent any tipping issues. HARDWARE IDENTIFICATION DESCRIPTION FIGURE SIZE PLUG LARGE SCREW Ø8×2" TIGHTWIRE 280mm SHORT SCREW Ø8×3/4"...
- Page 4 722272 ITEM: ASSEMBLY INSTRUCTION PRODUCT/PART DIMENSIONS: ① W418mm*D356mm*H400mm/W16.5"*D14"*H15.75"(Storage cabinet Size) ② W667mm*D356mm*H146mm/W26.25"*D14"*H5.75"(Open shelves Size) ③ W419mm*D292mm*H70mm/W16.5"*D11.5"*H2.75"(Drawers Internal Size) Note:Dimension tolerance±5% PAGE 4 OF 4 COASTERFURNITURE.COM...
