Honeywell POL-200-TS User Manual

Analogue loop verification tool
Hide thumbs Also See for POL-200-TS:
Table of Contents

Advertisement

Quick Links

POL-200-TS User Manual
User Manual
POL-200-TS
ANALOGUE LOOP VERIFICATION
TOOL
1/16

Advertisement

Table of Contents
loading

Related Manuals for Honeywell POL-200-TS

Summary of Contents for Honeywell POL-200-TS

  • Page 1 POL-200-TS User Manual User Manual POL-200-TS ANALOGUE LOOP VERIFICATION TOOL 1/16...
  • Page 2 Dissasembling: In accordance with the regulations 2002/96/EG (WEEE), after being dis- assembled, electrical and electronic equipment is taken back by the manufacturer for a proper disposal. Set Language POL-200-TS language menu. To change, select the option and the corresponding language. Restart the device. 2/16...

  • Page 3: Table Of Contents

    POL-200-TS User Manual Contents Page 1. Introduction ..................4 2. Connection ..................5 3. Multi-meter ..................6 4. Loop....................7 5. Map ....................11 6. Events recording ................11 7. Configuration ..................13 8. Troubleshooting ................14 9. Technical Characteristics ..............15 10.

  • Page 4: Introduction

    POL-200-TS is designed to be used only by trained personnel in order to properly interpretation the information read. Please note that POL-200-TS is a device designed to help you check the quality of the line and signal in your installation. POL-200-TS is not a fire protection equipment, it only provides the necessary information of support for the identification and solution of faults to a qualified technician.

  • Page 5: Connection

    Shielded/screen cable should only be connected to ground, GND, at one point inside the fire panel. The POL-200-TS allows the user to confirm that the shield is continuous, so it should be approximately twice (2x) and three (3x) times the resistance of the negative conductor.

  • Page 6: Multi-Meter

    POL-200-TS User Manual 3. Multi-meter After the connection check that POL-200-TS has the correct load level, please note that batteries with an insufficient charge level can falsify the measurements. You will access the Multimeter function from the main screen. Verify that the line impedance conditions are adequate as described in the pre- vious section.

  • Page 7: Loop

    The tool recognizes the sensors and modules on the loop before powering the fire alarm control panel (FACP). The POL-200-TS unit is compatible with the CLIP (Classic Loop Interface Protocol) with 99 sensors and 99 modules and the new Ad- vanced or Opal protocol with up to 159 sensors and 159 modules.
  • Page 8 POL-200-TS User Manual CLIP PROTOCOL ADVANCED PROTOCOL • “O” Optical Sensor For advanced protocol loops, POL-200-TS also identifies the following elements: • “H” or “T” Heat/Thermal sensor • “S” SMART 4 • “I” ionization sensor • “B” Beam detectors • “M” Multi-Sensor. Optical/ thermal •...
  • Page 9 The PWs value is for Honeywell technical team references, PW1 should be around 150 +/- 10% in Honeywell and Morley while around 300 +/- 10% for Notifier / System Sensor. Other values outside these range should be reported to Honeywell technical support for advice.
  • Page 10 POL-200-TS User Manual Select one of the items within the sampling table with the help of the arrows (arrows in the right margin of the screen) or by clicking on the screen. Press the button to access the advanced user information screen.

  • Page 11: Map

    In case the installer has correctly wired the isola- tors using the +IN, +OUT terminals in the B501AP or in the module terminals the POL-200-TS will activate the isolator to show in a graphic. POL -200-TS provides a device map for any of the protocols, CLIP or Advanced.
  • Page 12 Once the computers are selected and the “only selected items” register op- tion is selected, the POL-200-TS will dis- play the following screen: Register through the configuration op- tion only the necessary information, consult with Honeywell’s technical de-...

  • Page 13: Configuration

    The ‘About’icon will indicate the software version of the computer, the Flash Format option should only be used if indicated by the Honeywell technical department. The ‘QR’ icon will allow you to access with a Smartphone the latest online version of the com- puter.

  • Page 14: Troubleshooting

    Verify that you have not selected Ad protocol instead of CLIP Check that the loop is connected to the input, “IN” of the POL-200-TS device. There is no data recorded in my * .MNA, * .MNC and / or * .DAT files: Remove or delete old files, they are taking up the available memory space.

  • Page 15: Technical Characteristics

    Black box with rubber protection in grey color. Weight: 550g (with batteries). POL-200-TS has an even power-off that can discharge the batteries if you do not use it for an extended period of time. Power ON/OFF button The package includes a USB cable type B to connect the unit to a PC to install a new version by copying it to the root folder in the POL-200-TS unit.

  • Page 16: Ce Conformity

    POL-200-TS User Manual 10. CE conformity This document is a declaration that the products listed below conform to the essential protec- tion requirements of the following European Directives: • RoHS - Restrictions on the Use of Certain Hazardous Substances in Electrical and Electronic •...
  • Page 17 Honeywell Life Safety Iberia C/Pau Vila 15-19 08911 Badalona Barcelona, Spain POL-200-TS Diagnostic tool Ref. doc.: MN-DT-963_EN Tel.: 93 497 39 60 Fax: 93 465 86 35 20/06/17 www.honeywelllifesafety.es © 2017 Honeywell International Inc.
