- Page 1 Assembly Instruction PINCH Dining table IDPI-16090 / IDPI-18090 / IDPI-200100 IDPI-220100 / IDPI-240100 160x90 cm x H:74 180x90 cm x H:74 200x100 cm x H:74 220x100 cm x H:74 240x100 cm x H:74 01.06.2021...
-
Page 2: Tools Needed
Mangler du enkeltdele, eller har du spørgsmål til If any parts are missing or you have questions for the Samlevejledningen kontakt kundeservice på ilva.dk. Assembly instruction contact support at ilva.dk. Venlig hilsen Best regards ILVA ILVA... - Page 3 Total material list, hardware M6x60/x8 Ø10x46/x8 Ø15x19/x8 Ø10x12/x8 Allen key/x1...
- Page 4 Total material list, furniture parts Tabletop/x1 Legs/x2 Plint/x2...
-
Page 5: Material List
Material list M6x60/x8 Ø10x46/x8 Ø15x19/x8 Ø10x12/x8 Allen key/x1 Tabletop/x1 Legs/x2 Plint/x2 Number/x0 Number/x0 Number/x0 Number/x0... -
Page 6: Assembly Instruction
ASSEMBLY INSTRUCTION 1 M6x60/x8 ASSEMBLY INSTRUCTION 2 M15x19/x8 Please ensure that the holes are lined up with the holes in the end of the plint, so the bolts in step 4 can be connected. - Page 7 ASSEMBLY INSTRUCTION 3 Ø10x46/x8 Mount the Ø10x46 screws in both legs. ASSEMBLY INSTRUCTION 4 Ø10x12/x8 Connect the legs to the plints. Please ensure that the holes allign, so the Ø10x12 screw can be inserted and tightened.
- Page 8 ASSEMBLY INSTRUCTION 5 (optional) If you have ordered end leaves for your table, this can be installed by mounting the 2 rails to the table with thumb screws. After that the leaves can be placed on top of the rails and mounted with the thumb screws.
- Page 9 Max load Evenly distribute the weight on the table!
