- Page 1 Assembly Instruction Jupiter 130x75 2-person handling L130 x W75 x H76cm 25-04-2018...
-
Page 2: Kære Kunde
Make sure to allocate good time or divide up the work. Mangler du enkeltdele, eller har du spørgsmål til samle- If any parts are missing or if you have questions for the vejledningen? Så kontakt kundeservice på ide.dk/ilva.dk assembly instruction, please contact costumer support at ide.dk/ilva.dk Venlig hilsen ILVA/IDEmøbler... - Page 3 Total material list, hardware A M8*60 C Ø20 For M8 B M8 Threaded rod x8 Nut X8 Spring X8 Washer X8 F L-shapped Stick with Wrench for E x15 Screw X20 M8 nut X1 Bracket X10 M8 holes X4 Ø30 fabric pad X4 Total material list, furniture parts ①...
-
Page 4: Material List
Material list A M8*60 C Ø20 For M8 B M8 Threaded rod x8 Nut X8 Spring X8 Washer X8 ③x4 ②x1 Stick with Wrench for M8 holes X4 M8 nut X1 Apron Frame Table Leg Ø30 fabric pad X4 Assembly instruction, 1 ③... - Page 5 Material list F L-shapped ① x1 E x15 Table top with MDF Screw X20 Bracket X10 Caution: Fragile! Assembly instruction, 1 Caution: Fragile!
- Page 6 Assembly instruction, 2 Caution: Fragile! 2-person handling...
