Summary of Contents for Daymak SASQUATCH JR
- Page 1 User Manual...
-
Page 2: Safety
Safety When operating the Sasquatch Jr. please make sure you adhere to the following: • Always wear a helmet when riding the Sasquatch Jr. • Have a parent or guardian assemble the unit to ensure security. • Do not operate without parental supervision •... -
Page 3: About Daymak
Daymak warranties, services, and stocks parts for everything it sells. We support our products. Please feel free to visit our website. You’ll find the latest in cool transportation... -
Page 4: Introduction
Introduction Liability Daymak does not assume any liability for damages, loss of profits, or claims from third parties due to improper use of this product. Daymak does not assume any liability for damages due to problems with the product resulting from service by a third party that is not certified by Daymak. -
Page 5: Table Of Contents
• PART DIAGRAMS • RIDING INSTRUCTIONS • ASSEMBLY • FUSE • THE BATTERY • CHARGING YOUR ATV • CHARGING THE SASQUATCH JR. • OPERATION • TECHNICAL DATA • VEHICLE IDENTIFICATION NUMBER (VIN) • MAINTENANCE AND TROUBLESHOOTING • MAINTENANCE • THANK YOU FOR CHOOSING DAYMAK... -
Page 6: Part Diagrams
Part Diagrams Diagram 1: Sasquatch Jr. This diagram illustrates the various parts of your unit. Please note that many of these parts are not user-serviceable and should be repaired only by trained professionals. This is especially true of the electrical systems and the mechanical components. -
Page 7: Riding Instructions
• Share the Road. Be careful in mixed traffic. Let vehicles that are faster than you Overtake you and give ample room for vehicles travelling slower. AsSEMBLY For a full guide on how to assemble the Sasquatch Jr. please go the following url or scan the QR Code: https://daymak.com/assembly/sasquatch-jr... - Page 8 Items to Carry with the Electric Bike It is a good idea to carry the following items with you at all times when you ride your atv. • The charger, to charge the bike in case the battery power runs out. •...
- Page 9 Warning When you activate the atv, the electrical system becomes live. Do not try to affect changes to the Atv (such as removing the battery or repairing electrical components) while the Atv is activated. Turn the Atv off and remove the key before you attempt to access any of the electrical components.
- Page 10 Riding in Wet Weather Your atv is designed to function in wet conditions, such as when it is raining. However, because the motor is on the rear wheel, it is easy to slip when moving at high speeds. If it is very wet, be sure to avoid high speeds. When you are traveling in wet weather, water may cause your brakes to function less effectively because it reduces friction between the brake pads and the wheels.
-
Page 11: Fuse
Fuse The Sasquatch Jr. requires a 30 Amp fuse to operate. Seen here: To put it in, look for the red fuse holder and open the top. Then put the fuse into the slot and close it again. -
Page 12: The Battery
The Battery This section details what you need to know about the battery that powers your atv. Always remember to treat your atvs electrical systems with respect. Battery Power The dashboard has a battery charge indicator. When the atv is activated, the guage will jump and indicate the currently available battery power. -
Page 13: Charging Your Atv
If your charger’s LED status light does not change from red to green over an extended period of time, for perhaps more than 14 hours, and the battery is very hot, the battery or charger may need replacing. Stop charging and bring both to your Daymak dealer immediately. Do not charge the battery. -
Page 14: Charging The Sasquatch Jr
Charging the Sasquatch Jr. The Sasquatch Jr. comes with a 36V battery pack. To charge the Sasquatch Jr. directly in the unit look for the charge port on the left hand side of the atv. It will be covered with a flap that you must lift up and then plug the female end into that port. - Page 15 Contact your local Daymak dealer to purchase a new battery. When replacing your battery, dispose of it at a proper municipal battery recycling facility.
-
Page 16: Operation
Operation Throttle On the right handle is the throttle. This is used to engage the motor. Twist this handlebar towards you to engage the motor. This must be used in conjunction with the foot pedal Warning Be sure to be sitting on it properly, with proper protective equipment (helmet, elbow pads, knee pads etc.) Brakes... - Page 17 When engaging the throttle one foot must be pressing the pedal for the ATV to activate. speed switch The Sasquatch Jr. comes with a speed switch to limit the top speed. Set it to 1 for low speed and set it to 2 for high speed.
- Page 18 6) Reverse switch - Press this in to have the ATV operate in reverse, or out to have it go forward. CONNECTING TO MP3 PLAYER The Sasquatch Jr. comes with a Bluetooth MP3 player that you link to your smartphone or smart device and play your music. To connect to it, search for M11 on your smart device in bluetooth settings and connect to it.
- Page 19 BRAke lock On the right brake lever you will find a brake lock. This is used to to lock the brakes while not in operation to prevent it from rolling away. To engage the brake lock, pull the brake lever towards the throttle, and while holding it, push the metal rivet down to lock the brake in place then release the brake lever.
-
Page 20: Technical Data
This section provides you with the technical specifications for your atv. The Motor and Wheel Assembly The Sasquatch Jr. has a 1000 Watt magnetic brushless DC. This type of motor has excellent low-end torque and high efficiency when working within its range. Note that while the motor is very quiet, it does produce some noise. -
Page 21: Vehicle Identification Number (Vin)
This is also required for registering your warranty on the warranty section of Daymak.com. To find the VIN on your Sasquatch Jr. look on the very front of the unit behind the front bumper, you will see a plate that... -
Page 22: Maintenance And Troubleshooting
Maintenance and Troubleshooting This section outlines problems you may have and solutions you may be able to use. Many of the parts in this product are not user-serviceable and should be repaired by trained professionals. This is especially true of the electrical systems and the mechanical components. - Page 23 If your atv is not performing properly, disconnect the circuit breaker or fuse and bring the atv to your local Daymak dealer. Do not store the atv without disconnecting the circuit breaker or fuse.
-
Page 24: Maintenance
Maintenance Cleaning Cleaning is extremely important this will ensure your atv will serve you for a long time. In the long run, it will save you money and a lot of time waiting for the atv to be repaired. You should clean your ebike weekly. Do not use aggressive power jets or water sprays when washing the ebike and keep water off the battery as much as you can. - Page 25 Schedule The frequency of maintenance depends on how much you ride and under which conditions. Recreational riders needs far less maintenance then off-road riders. The harder you ride, the more you have to take care of your bike if you want it to last. There are various time intervals for proper maintenance.
- Page 26 Specifications Name Sassquatch Jr. Motor 1000W Voltage Amp Hour 12AH Watt Hours 432WH Battery Life 300 Cycles Battery Lead Acid Removable Battery Only During Replacement Charger 36V 1.5A Charge Time 8 - 10 Hours Lights Max Load 175 lbs. Assembled Weight 120 lbs.
-
Page 28: Thank You For Choosing Daymak
Thank you for choosing Daymak...
