- Page 1 Electric Bike User Manual...
-
Page 2: Table Of Contents
Contents Attention .......................3 Check Before Use ....................3 Product Information ....................4 2.1 Product Performance .....................4 2.2 Product Specifications ...................4 Adjustments ......................5 3.1 Adjusting The Handlebar ..................5 3.2 Adjusting The Saddle .....................6 3.3 Adjusting The Wheels ....................7 3.4 Adjusting And Maintaining The Brakes ..............7 3.5 Adjusting The Gear-Change Rear Derailleur ............8 How To Use ......................10 4.1 Input The Battery ....................10... -
Page 3: Attention
Attention • Do not operate this electric bike without fully reading and understanding its opera- tion and limitations. • Before riding each time ensure that all parts are in good order. For any questions or concerns, please contact your Authorised Dealer’s Customer Service. •... -
Page 4: Product Information
This e-bike is fitted with a high quality brushless motor, intelligent operating system, high quality lithium battery, freewheel, power display unit and electric cut off when braking. 2.2 Product specifications Model AEC-TDE16Z Type Brushless 1830 x 650 x Dimensions Rated Power... -
Page 5: Adjustments
3. Adjustments 3.1 Adjusting the handlebar • Place the handlebar onto the handlebar stem, place on the cover, and fix with the two screws. The tighten torque should not be less than 18Nm. Handlebar Handlebar stem stem cover Hexagon socket screws •... -
Page 6: Adjusting The Saddle
• Tighten the screw that fixes the handlebar attachment to the frame. The tightening torque should not be less than 18Nm. Handlebar stem screw 3.2 Adjusting the Saddle • The saddle post must be inserted at least to the circular safety mark engraved on the tube. -
Page 7: Adjusting The Wheels
3.3 Adjusting the wheels • Tighten the screws to make sure the front and back wheels are fixed to the front fork and frame. • Recommended tightening torques are as follows: Front wheel hub: 18Nm Rear wheel hub: 30Nm 3.4 Adjusting and maintaining the brakes •... -
Page 8: Adjusting The Gear-Change Rear Derailleur
3.5 Adjusting the Gear-Change Rear Derailleur 3.5.1 instruction in use • To change into a higher gear (used for going uphill) press in the front leaver with your thumb. For a lower gear (for when there is low resistance going downhill) use your forefinger to press in the back leaver. - Page 9 3.5.2 Adjusting the Derailleur • Adjust the lower bolt to make the guide wheel move to the free-wheel; align the centre of the guide wheel and the outer line of the smallest sprocket. • Turning the front chain-wheel, operate the gear lever to shift to the lowest gear, then tighten the derailleur cable and fix it by the derailleur cable nut.
-
Page 10: How To Use
4 How to use 4.1 input the battery • Make sure the battery terminals are dry before inserting the battery. • Lift up the saddle using the leaver underneath. Battery guide board Seat lever Battery terminals • Slide in the battery, ensuring that the battery guide board slots into the grooves of the battery. -
Page 11: Turn On The Power
4.2 Turn on the power • Place the key into the lock and turn the key clockwise to turn the power on. • Press the ON/OFF button of the power display. If all the four light are on, it means the power is full. -
Page 12: Caution Whilst Riding
4.5 Caution while riding • Start slowly and speed up slowly. • The power will automatically cut out if the e-bike overloads and automatically cut back in after a short period if the e-bike is ridden normally. 4.6 Caution whilst parked •... -
Page 13: Battery And Charger Precautions
4.9 Battery and charger precautions 4.9.1 Battery • Never short circuit and discharge or charge terminals of the battery. • Keep the battery away from fire and excessive heat. Never put the battery into fire. • To avoid damage to the battery, never subject it to intense physical shock or severe vibration or impact. -
Page 14: Bicycle Inspection And Care
5 Bicycle inspection and care 5.1 Regular Cleaning • Remove the battery box from the e-bike before carrying out regular cleaning. • use water to clean the e-bike, as the electrical and electronic systems DO NOT may get wet, resulting in personal injury or malfunction of the bicycle. •... -
Page 15: Lubricating The E-Bike
5.3 Lubricating the e-bike To maintain your e-bike in proper working order, be sure to carry out regular lubrica- tion, as indicated in the following illustration: • Use specific transmission lubricants for the chain, freewheel and gears every 1–2 months, or if the driveline is dry. •... - Page 16 Need help? Contact us: West Hill, Nr Exeter, Devon, United Kingdom, EX11 1LQ 0800 328 5708 • sales@fw3group.com...
