Electric Bike User Manual
HAVE A QUESTION? NEED HELP?
Contact us on Facebook for a quick reply.
westhillbikes.com
CLASSIC / ENERGISE / VOGUE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENERGISE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WESTHILL BIKES ENERGISE

  • Page 1 Electric Bike User Manual HAVE A QUESTION? NEED HELP? Contact us on Facebook for a quick reply. westhillbikes.com CLASSIC / ENERGISE / VOGUE...
  • Page 2 WARRANTY Westhill bikes are covered by a limited 3-year warranty. Aside from general cycle maintenance, any work to the motor should be carried out by a Westhill technician or authorised dealer. 1. Warranty periods Spokes The statutory warranty valid at the time of...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INCLUDED IN THE BOX..................SPECIFICATIONS ....................ASSEMBLY....................... SAFE RIDING......................CHARGING THE BATTERY..................HOW TO USE THE BIKE CONTROLS..............A. Gears......................B. Turning the bike on and off................ C. Pedal assist....................D. Speedometer....................E. WALK MODE....................................
  • Page 4: Included In The Box

    Detachable Window for Battery removal Seat Rear Wheel Rear Brake fb.com/westhillbikes | westhillbikes.com...
  • Page 5: Specifications

    SPECIFICATIONS MODEL ENERGISE VOGUE CLASSIC Bike Dimensions 1800X640x995 1800X640x995 1830X630X1098 Wheel Diameter 683mm 683mm 697mm Wheelbase 1105mm 1105mm 1100mm Max Rider Weight 110kg 110kg 110kg Max Speed 25km/h 15.5mph 25km/h 15.5mph 25km/h 15.5mph Range Per Charge 40-100 Miles 40-100 Miles...
  • Page 6: Assembly

    Caliper , the Pedals and insert the Seat Post. 6-11 your bike. bike, call our team bike but assembly will still be the same. ASSEMBLING THE HANDLEBAR fb.com/westhillbikes | westhillbikes.com...
  • Page 7 Connect the wires by colour. colour. fb.com/westhillbikes | westhillbikes.com...
  • Page 8 ASSEMBLING THE FRONT DISC BRAKE CALIPER Caliper *This process will be the same for a Hydraulic Brake *Be careful when attaching the Brake not to crossthread the bolts. Loosen the Pin through the middle of the wheel to allow you to place the Fork onto it.
  • Page 9 Tighten the Nut and hold the Lever in an upright position as shown in the photo below. Once tight push the lever in to secure the wheel. TO CHECK Check your Tyre pressure - if they need pumping up, attach a Bike Pump to the Valve (shown in the photo below) and inflate to the recommended Tyre Pressure (this will be located on the Tyre).
  • Page 10 to identify The right Pedal is attached on the same side as the chain. Make sure you check the Pedals are tight and secure before riding. fb.com/westhillbikes | westhillbikes.com...
  • Page 11 ATTACHING THE SEAT Seat Seat Seat Line Seat Seat fb.com/westhillbikes | westhillbikes.com...
  • Page 12: Safe Riding

    SAFE RIDING suffient charge Avoid direct contact with water. -ion Bike is located at the bottom of the battery frame, by the detachable window (next page remove once completed. charged fb.com/westhillbikes | westhillbikes.com...
  • Page 13 In the unlikely event , step away from the Bike and contact Westhill Bikes for further assistance. fb.com/westhillbikes | westhillbikes.com...
  • Page 14: How To Use The Bike Controls

    or 7 or is turned off, the bike and gears can still be used as normal. fb.com/westhillbikes | westhillbikes.com...
  • Page 15: Pedal Assist

    Westhill Customer Service on +44 (0)1823 672 970. (4mph) fb.com/westhillbikes | westhillbikes.com...
  • Page 16: Motor Power Indicator

    Error Code Definition Current Abnormality Throttle Abnormality Motor Abnormality Motor Hall Abnormality Brake Abnormality Communication Abnormality fb.com/westhillbikes | westhillbikes.com...
  • Page 17: Care And Maintenance

    BATTERY RANGE The range of the battery is up to 100 miles per charge. of factors regular prolong the life of your battery. riding (15.5mph) 110kg (17 stone). limit can and will void your warranty. fb.com/westhillbikes | westhillbikes.com...
  • Page 18: Safety Warnings

    CLEANING THE BIKE Do not use excessive water to clean the bike as this could damage the components, resulting in personal injury or malfunction of the bicycle. Lubricate the chain after every wash if you can to keep it smooth and rust free. battery You can remove the battery but never disassemble it.
  • Page 19: Modifications

    any electrical parts without contacting the Customer Service (+44 (0)1823 672 970). the bike. fb.com/westhillbikes | westhillbikes.com...
  • Page 20 Westhill Bikes Warranty Register Now Through Our Website westhillbikes.com/warranty-registration Simply visit and fill in your information. Register Now Through Facebook The other way to register your new bike is through Facebook. Simply visit our page www.fb.com/westhillbikes or scan the QR code below with your mobile...
