Cordless lawn trimmer / edge trimmer

Advertisement

ORIGINAL INSTRUCTIONS
Cordless Lawn
Trimmer / Edge
Trimmer
RLT18X20M
OLT1825M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLT18X20M and is the answer not in the manual?

Questions and answers

Summary of Contents for Ryobi RLT18X20M

  • Page 1 ORIGINAL INSTRUCTIONS Cordless Lawn Trimmer / Edge Trimmer RLT18X20M OLT1825M...
  • Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modifications.
  • Page 3: Intended Use

    Safety, performance, and dependability have been given the area. top priority in the design of your cordless lawn trimmer or ■ Never use the product while tired, ill, or under the edge trimmer. influence of alcohol, drugs, or medication. ■ Keep in mind that the operator or user is responsible INTENDED USE for accidents or hazards occurring to other people or...
  • Page 4: Transportation And Storage

    ■ Keep proper footing and balance at all times, and be ■ Use only the manufacturer’s replacement cutting line. sure of proper footing on slopes. Do not use any other cutting attachment. ■ Do not walk backwards when using the product. Walk, ■...
  • Page 5: Symbols On The Product

    ■ After each period of operation, exercise to increase WARNING blood circulation. Servicing requires extreme care and knowledge ■ Take frequent work breaks. Limit the amount of and should be performed only by a qualified service exposure per day. technician. Have the product serviced by an authorised If you experience any of the symptoms of this condition, service centre only.
  • Page 6: Symbols In This Manual

    Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Guaranteed sound power level Regulatory Compliance Mark (RCM). Product meets applicable regulatory requirements. The following signal words and meanings are intended to explain the levels of risk associated with this product: Indicates an imminently hazardous situation, which, if not avoided, will...
  • Page 7 WHAT’S IN THE BOX OLT1825M...
  • Page 8 WHAT’S IN THE BOX RLT18X20M...
  • Page 9: Know Your Product

    KNOW YOUR PRODUCT 1. Lock-out trigger 8. Eyelet 2. Rear handle 9. Slider 3. On/Off trigger 10. Safety guard 4. Edging button 11. Cutting line 5. Upper shaft 12. Cut-off blade 6. Spool cover 13. Lower shaft 7. Spool 14. Front handle 11 10...
  • Page 10: Getting Started

    GETTING STARTED Install the safety guard to the trimmer head. Screw the safety Always wear safety goggles or safety glasses with side shields when operating the product. Wear non-slip, heavy-duty protective guard into place with a phillips screwdriver. gloves. Wear non-skid, protective footwear that will protect your feet and improve your footing on slippery surfaces.
  • Page 11 GETTING STARTED Attach the upper shaft to the lower shaft. Rotate the lower shaft counterclockwise until the lines on both the lower shaft and upper shaft are aligned. Insert the battery pack until the battery latch button clicks into Hold the lock-out trigger, and squeeze the on/off trigger to operate place.
  • Page 12 OVERVIEW Operating the trimmer Operating the edger p.14 p.11 Replacing the spool Cleaning the product Storing the product p.15 p.16 p.17...
  • Page 13: Operation

    OPERATION OPERATING THE TRIMMER WARNING: Always use two hands to operate the product. Hold the product with the right hand on the rear handle and the left hand on the front handle. WARNING: Beware of objects thrown by the cutting means. Clear debris like small stones, gravel, and other foreign objects from the work area before starting operation.
  • Page 14 OPERATION 2. Hold the lock-out trigger, and squeeze the on/off trigger to operate the product. NOTE: Holding and releasing both the lock- out trigger and the on/off trigger automatically releases a quarter inch of line. WARNING: Do not bump the spool head on the ground when operating the product.
  • Page 15 OPERATION NOTE: The line cut-off blade on the grass deflector cuts the line to the correct length for safe and optimum performance. NOTE: Cut tall grass from the top down. This prevents grass from wrapping around the shaft housing and bump head, which may cause damage from overheating.
  • Page 16 OPERATION OPERATING THE EDGER 1. Remove the battery pack. 2. Push the edging button. Rotate the upper shaft counterclockwise to turn to the edger position. 3. Insert the battery pack until the battery latch button clicks into place. Hold the lock-out 180°...
  • Page 17: Maintenance

    MAINTENANCE REPLACING THE SPOOL 1. Remove the battery pack. Push the slider on the side of the spool retainer, and remove the spool cover. 2. Remove the spool. 3. Thread the line of the new spool through the eyelet. Install the new spool with the line and slot aligned with the eyelet in the string head.
  • Page 18 MAINTENANCE CLEANING THE PRODUCT 1. Remove the battery pack. 2. Clean all foreign material from the product with a soft, dry brush. WARNING: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use.
  • Page 19 STORAGE STORING THE PRODUCT NOTE: Ensure that the product is clean before storing. 1. Remove the battery pack. 2. Store the product in a cool, dry, and well- ventilated place that is inaccessible to children and away from sources of ignition. Do not store the product outdoors.
  • Page 20: Product Specifications

    PRODUCT SPECIFICATIONS VIBRATION LEVEL Cordless Lawn Trimmer / Edge Trimmer WARNING Model RLT18X20M / OLT1825M The declared vibration value has been measured with a standard test method and may be used to compare one Voltage 18 V tool with another.
  • Page 24 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149, Melbourne, Australia Techtronic Industries N.Z. Limited RYOBI is a trademark of Ryobi Limited, Unit C, 70 Business Parade South, and is used under license. Highbrook, Auckland 2013, New Zealand ©...
